BIOS User Guide
Hi-Fi Z170Z5 / Hi-Fi B150Z5
BIOS Update ������������������������������������������������������������������������������������� 2
UEFI BIOS Setup �������������������������������������������������������������������������������� 6
1� Main Menu ����������������������������������������������������������������������������������� 7
2� Advanced Menu ���������������������������������������������������������������������������� 8
3� Chipset Menu �������������������������������������������������������������������������������17
4� Boot Menu �����������������������������������������������������������������������������������21
5� Security Menu ������������������������������������������������������������������������������24
6� O�N�E Menu����������������������������������������������������������������������������������27
7� Exit Menu�������������������������������������������������������������������������������������36

Advertisement

Table of Contents
loading

Summary of Contents for Biostar Hi-Fi Z170Z5

  • Page 1: Table Of Contents

    BIOS User Guide Hi-Fi Z170Z5 / Hi-Fi B150Z5 BIOS Update ������������������������������������������������������������������������������������� 2 UEFI BIOS Setup �������������������������������������������������������������������������������� 6 1� Main Menu ����������������������������������������������������������������������������������� 7 2� Advanced Menu ���������������������������������������������������������������������������� 8 3� Chipset Menu �������������������������������������������������������������������������������17 4� Boot Menu �����������������������������������������������������������������������������������21 5� Security Menu ������������������������������������������������������������������������������24 6� O�N�E Menu����������������������������������������������������������������������������������27...
  • Page 2: Bios Update

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIOS Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 3 Hi-Fi Z170Z5 / Hi-Fi B150Z5 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the <Y> key to restart system. 8. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 4 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 5 Hi-Fi Z170Z5 / Hi-Fi B150Z5 6. After the BIOS Update process is finished, click on “OK” to reboot the system. 7. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 6: Uefi Bios Setup

    UEFI BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM. UEFI BIOS determines what a computer can do without accessing programs from a disk.
  • Page 7: 1� Main Menu

    Hi-Fi Z170Z5 / Hi-Fi B150Z5 1� Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information It shows system information including UEFI BIOS version, Project Code, Model Name, Build Date and etc.
  • Page 8: 2� Advanced Menu

    2� Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note   » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. ACPI Settings Enable ACPI Auto Configuration This item enables or disables BIOS ACPI auto configuration function.
  • Page 9 Hi-Fi Z170Z5 / Hi-Fi B150Z5 Enable Hibernation This item enables or disables system ability to hibernate (0S/S4 sleep state). This option may be not effective with some OS. Options: Enabled (Default) / Disabled ACPI Sleep State This item selects the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.
  • Page 10 SMART FAN Control CPU Smart Fan1 System Smart Fan1/2 This item allows you to control the CPU/System Smart Fan function. Options: Disabled (Default) / Auto Note   » The following items appear only when you set the Smart Fan function to [Auto]. CPU Fan Calibrate Press [ENTER] to calibrate CPU Fan speed.
  • Page 11 Hi-Fi Z170Z5 / Hi-Fi B150Z5 Super IO Configuration Serial Port 2 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item selects an optimal setting for Super IO device. Options: Auto (Default) / IO=2F8h; IRQ=4 / IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=2F8h;...
  • Page 12 H/W Monitor Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. Options: Disabled (Default) / 70°C/158°F / 75°C/167°F / 80°C/176°F / 85°C/185°F / 90°C/194°F CPU Configuration This item shows CPU Information Hyper-threading This item enables for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and disables for other OS(OS not optimized for Hyper-Threading Technology).
  • Page 13 Hi-Fi Z170Z5 / Hi-Fi B150Z5 Active Processor Cores This item sets number of cores to enable in each processor package. Options: All (Default) / 1 / 2 / 3 Overclocking lock This item sets Overclocking lock. Options: Disabled (Default) / Enabled...
  • Page 14 SATA Controller(s) This item enables/disables Serial ATA Device. Options: Enabled (Default) / Disabled SATA Mode Selection This item determines how SATA controller(s) operate. Options: AHCI (Default) / RAID SMART Self Test This item runs SMART Self Test on all HDDs during POST. Options: Disabled (Default) / Enabled SATA Express 1L SRIS This item sets SATA Express SRIS.
  • Page 15 Hi-Fi Z170Z5 / Hi-Fi B150Z5 PXE boot wait time Wait time to press ESC key to abort the PXE boot. Media detect time Wait time in sec to detect media. NVMe Configuration The item shows NVMe controller and driver information.
  • Page 16 XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. Options: Disabled (Default) / Enabled USB Mass Storage Driver Support The item allows you to enable or disable USB Mass Storage Driver Support. Options: Enabled (Default) / Disabled Port 60/64 Emulation The item allows you to enable or disable I/O port 60h/64h emulation support.
  • Page 17: 3� Chipset Menu

    Hi-Fi Z170Z5 / Hi-Fi B150Z5 3� Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
  • Page 18 PCI Express Configuration PEX16_2/PEX1_1 Options: Auto(Default) / Gen1 / Gen2 / Gen3 HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be enabled. Options: Auto (Default) / Disabled / Enabled EuP Control When EuP is enabled, the system will meet EuP requirement.
  • Page 19 Hi-Fi Z170Z5 / Hi-Fi B150Z5 VT-d This item enables or disables VT-d capability. Options: Enabled (Default) / Disabled Max TOLUD Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Options: Dynamic (Default) / 1 GB / 1.25 GB / 1.5 GB / 1.75 GB / 2 GB / 2.25 GB / 2.5 GB / 2.75 GB / 3 GB / 3.25 GB / 3.5GB...
  • Page 20 Onboard Device Onboard LAN1 This item enables/disables Onbaord LAN1. Options: Enabled (Default) / Disabled Onboard LAN1 Option ROM This item enables/disables Onboard LAN1 Option ROM. Options: Disabled (Default) / Enabled 20 | 3. Chipset Menu...
  • Page 21: 4� Boot Menu

    Hi-Fi Z170Z5 / Hi-Fi B150Z5 4� Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 1 (Default) Bootup NumLock State This item selects the keyboard NumLock state.
  • Page 22 SATA Support Options: All Sata Devices (Default) / Last Boot HDD Only VGA Support If Auto, only install Legacy OpRom with Legacy OS and logo would NOT be shown during post. EFI driver will still installed with EFI. Options: EFI Driver (Default) / Auto USB Support If Disabled, all USB devices will NOT be available until after OS boot.
  • Page 23 Hi-Fi Z170Z5 / Hi-Fi B150Z5 Video This option controls the execution of UEFI and Legacy Video OpROM Options: Legacy (Default) / UEFI / Do not launch Other PCI device For PCI devices other than Network, Mass storage or video defines which OpROM to launch.
  • Page 24: 5� Security Menu

    5� Security Menu Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Menu 24 | 5. Security Menu...
  • Page 25 Hi-Fi Z170Z5 / Hi-Fi B150Z5 Secure Boot Secure Boot can be enabled if 1. System running in user mode with enrolled Platform Key(PK) 2.CSM function is disabled. Options: Disabled (Default) / Enabled Secure Boot Mode Secure Boot mode selector. ‘Custom’ mode enables users to change Image Execution policy and manage Secure Boot Keys.
  • Page 26 Forbidden Signature Delete Key – Allows you to delete the DBX file from your system. Set new Key – Allows you set new DBK file. Append Key – Allows you append Var to DBX. Authorized Timestamps Set new Key – Allows you set new DBT file. Append Key –...
  • Page 27: 6� O�N�E Menu

    Hi-Fi Z170Z5 / Hi-Fi B150Z5 6� O�N�E Menu This submenu allows you to change voltage and clock of various devices. Note   » We suggest you use the default setting. Changing the voltage and clock improperly may damage the device.
  • Page 28 28 | 6. O.N.E Menu...
  • Page 29 Hi-Fi Z170Z5 / Hi-Fi B150Z5 CPU Ratio Mode This item sets CPU Ratio Mode. Options: Auto (Default) / ALL Cores / Per Core / Fixed Ring Max OC Ratio This sets the maximum overclocking ratio for the Ring Domain. Options: 41 (Default) Ring Min OC Ratio This sets the minimum overclocking ratio for the Ring Domain.
  • Page 30 Memory Timing Configuration Note   » The following items appear only when you set the Memory Profiles function to [Manual] This item allows you to select CAS Latency, 0: AUTO, max: 31 Options: Auto (Default) tRCD/tRP This item allows you to select RAS to CAS delay time and Row Prechrge delay time, 0: AUTO, max: 63 Options: Auto (Default) tRAS...
  • Page 31 Hi-Fi Z170Z5 / Hi-Fi B150Z5 tRTP This item allows you to select Read to Precharge Delay, 0: AUTO, max: 15. DDR4 legal values: 5, 6, 7, 8, 9, 10, 12 Options: Auto (Default) This item allows you to select Internal Write to Read Command Delay, 0: AUTO, legal values: 5, 6,...
  • Page 32 Note   » The following items appear only when you set the CPU Vcore Over Voltage to [Override] CPU Vcore Adjust Voltage Options: 1.270V (Default), Range: 1.000V-1.800V Note   » The following items appear only when you set the CPU Vcore Over Voltage to [Adaptive] CPU Vcore Offset Prefix Options: + (Default) / - CPU Vcore Offset Voltage...
  • Page 33 Hi-Fi Z170Z5 / Hi-Fi B150Z5 CPU Power Management Intel(R) SpeedStep(tm) This item enables/disables Enhanced Intel SpeedStep Technology. Options: Enabled (Default) / Disabled Turbo Mode This item enables/disables CPU Turbo Mode. Options: Enabled (Default) / Disabled Package Power Limit MSR Lock This item enables or disables locking of Package Power Limit settings.
  • Page 34 Enhanced C-states This item enables or disables C1E. When enabled, CPU will switch to minimum speed when all cores enter C-State. Options: Enabled (Default) / Disabled C-states Auto Demotion This item sets C-State Auto Demotion. Options: C1 and C3 (Default) / C1 / C3/ Disabled C-states Un-demotion This item sets C-State Un-demotion.
  • Page 35 Hi-Fi Z170Z5 / Hi-Fi B150Z5 Memory Insight DIMM Profile These items display memory information. 6. O.N.E Menu | 35...
  • Page 36: 7� Exit Menu

    7� Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup. Save Changes and Reset Reset the system after saving the changes.

This manual is also suitable for:

Hi-fi b150z5
