Copyright The design of this product (including so�ware) and its accessories is under tutelage of laws. Any ac�on to violate relevant right of our product will be penalized through law. Please consciously observe relevant local laws in the use of this product. Symbols and conven�ons Thank you for purchasing this soldering sta�on product.
1 Unit Product overview ST 60/ST 80/ST 100 is a new designed digital soldering sta�on which got be�er performance and is more convenient and safer to use. And it has been widely used in colleges & universi�es, ins�tutes, industrial produc�on line and so on.
ST 60 ST 80 ST 100 Temperature Stability in s�ll air, without load Automa�cally stand by �me 1 120 minutes Standby temperature Automa�cally shut down �me 1 120 minutes Temperature regula�on 5 digits(default)/1digit (fine tuning) High performance High end quad wire Hea�ng element...
1 seconds, then LCD display panel will show last set temperature value and show "SET" simultaneously(Figure 1).3 seconds later, display panel will show soldering iron real �me temperature value and "REAL" at the same �me(Figure 2). ST 60 Version Display ST 80 Version Display ST 100 Version Display...
Page 7
(Figure 4),"SET" will show on LCD display panel simultaneously. Pressing and holding adjust temperature quickly. Stop pressing will cause soldering sta�on store se�ng value automa�cally and exit from temperature se�ng mode. Figure 3 Figure 4 4. Storing and retrieving temperature values quickly Retrieve temperature values: in normal working state, press 1, 2, 3(Figure 5) to retrieve temperature values stored in memory and set retrieved value as current working temperature.
Page 8
7. Manually temperature calibra�on 7.1 In first system se�ng page ,press 1 to enter temperature calibra�on mode, and "CAL" will show on display panel on which also shows last calibra�on value(Figure 10,calibra�on value is 0 ). 7.2 In calibra�on mode, press to set calibra�on temperature values whose range is 50 ~ 50 90 ~+90...
Page 9
stand by �me se�ng mode and display panel will show current stand by �me. Press to set stand by �me and press #1 to save it. Note: Stand by time can be set between 1 minute and 120 minutes and stand by function will be disabled as setting content is "OFF"(Figure 15).After enabling stand by function, soldering station will enter stand by state if no soldering work or any other control panel operations taken throughout during stand by time, and the temperature will decline to 150...
touchtone se�ng mode and display panel will show current touchtone se�ng status. Press to set touchtone state and press #3 to save it. Note: Beeping function is enable as setting content is "ON”, and now there will arise short beep for each operation on control panel to call your attention.
Fault Code Or Malfunc�on Descrip�on Causes For Malfunc�on Short circuit for heater or soldering iron wires E 1: Abnormal hea�ng up alarming Open circuit for hea�ng element. Connec�on error for hea�ng element. E 2: Open circuit alarming for sensors Heater damaged. Wiring error of hea�ng element.
Page 12
Parts List Number Material name Number Material name Power cord Key group 1 Fuse(T1.0A|220V/230V240V),(T2.0 Key group 2 A|100V/110V/120V) Male socket Power switch Soldering iron stand Output receptacle Cleaning sponge Soldering iron handle cables Housing Soldering iron handle end sleeve PCBA fixing screws Soldering iron handle end Soldering iron handle sleeve PCBA board...
Page 14
Interchangeable soldering p (AT800 series)
Page 15
Warranty Cer�ficate of Product This product warranty period cover 12 months from the day this Model ______________Product NO. ___________ product purchased. We will make free maintenance for any quality problem itself if this card and receipt provided. We will repair and QC _________________Produc�on date ________ return your device within 2 workdays a�er receiving repairing req device.
Page 16
SHENZHEN ATTEN TECHNOLOGY CO., LTD. Soldering Iron Soldering Sta n Hot Air Rework Sta func n Rework System BGA Rework System Regulated DC Power Supply Switching DC Power Supply Programmable Power Supply RF Microwave Instruments RF Microwave Components A enuator Amplifier Coaxial Load SHENZHEN ATTEN TECHNOLOGY CO., LTD.
