- Page 1 Manual Cordless 40 V Chain Saw MAX-40M Applies for: Code Model 102491 MAX-40M Read the user’s manual thoroughly CAUTION before operating this tool.
-
Page 2: Table Of Contents
The illustrations in this manual are for reference Oil Supply only. They might be different from the real tool. Bar and Chain Assembly Start Up Cutting Operation Felling and Bucking Cutting Branches and Pruning Adjustments and Maintenance Troubleshooting Notes Authorized Service Centers Warranty policy MAX-40M ENGLISH... -
Page 3: Technical Data
Technical Data MAX-40M Code 102491 Description Cordless Chain Saw Voltage 40 V Motor speed 11 000 RPM Chain speed 62 ft/s Bar length 16” Oil tank for the chain 4.7 oz Weight (without bar) 8.1 lb Print sprocket 6 sprockets... -
Page 4: General Power Tools Safety Warnings
General power tools safety warnings WARNING! Read carefully all safety warnings and instruction listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Using Chainsaws
When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws, or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. Service Under abusive conditions, liquid may be ejected from the Repair the tool in a... - Page 6 Safety warnings for Using Chain saws Before operating the chain saw DANGER • Never use the chain saw when tired, sick or under the effects of drugs, alcohol o medication. • Wear clothes adequate for chain saw operation: tight fitting clothes, thick slacks, safety non-skid boots, heavy-duty protective gloves, safety goggles or protective lenses with side protection compliant with the ANSI Z87.1 Standard, head and hearing protectors.
- Page 7 Safety warnings for Using Chain saws Batteries and charger • Use only Truper Max chargers to charge DANGER the tool battery. Using any other charger may result in fire or risk of injury. • Use only batteries specifically designed DANGER for the tool.
-
Page 8: Parts
Parts Front Guard / Chain Brake Battery receptacle (right) Rear Handle Low Kickback Guide Bar saw chain Chain Chain Cover Chain Tension Cover Locking Lever Knob Front Battery Switch Handle receptacle (left) Lock Bar cover Oil Deposit Power Switch Motor Rear Handle Cover Base... -
Page 9: Preparation
Preparation Considerations for the use of batteries Batteries • Once the batteries are charged, insert them into their • The batteries come DISCHARGED from the factory. They respective receptacles on both sides of the tool. will need to be charged for approximately 1.5 hours before •... -
Page 10: Safety Devices
Safety Devices Chain Brake Changing Direction • The chain brake (A) function is to stop quickly the chain of the Left Hand to Activate the movement and protects the hand in case of kickback. Chain Brake (See page 5). It is designed taking in consideration the predictable movement of kickback, which sends the cut bar upwards and towards the operator, so when the brake is pushed with the left hand, the chain stops immediately. -
Page 11: Oil Supply
Oil Supply Oil Supply for Cut Bar and Chain • Use oil for bars, chains and their lubrication systems, specially designed to work in a wide range of temperatures without any dilution. Using SAE 10W30 oil is recommended. • Oil level should be checked every 20 minutes through the oil level window (A). - Page 12 Bar and Chain Assembly WARNING • Never start the motor before having first assembled the cut bar, chain and chain cover. Otherwise, the operator would be exposed to severe personal injury. • Remove the batteries. • Pull back the chain brake to be sure it is in the operating position (see page 10).
- Page 13 Bar and Chain Assembly • Lift the bar with the chain and set it into the saw. Pass the mounting knob (F) through the bar groove and the loose space between the bar and the chain around the sprocket wheel (G). •...
-
Page 14: Start Up
Start Up Turning ON • Double check the chain is not making contact with any object. • Keep the switch lock pressed (C) to unblock it (B). The switch block prevents accidental startups. • Press the switch lock (B) so that the chain starts advancing. -
Page 15: Cutting Operation
Cutting operation Cutting Correct Position Basic Cutting Procedures • Both feet should be evenly set on firm ground. Your If you lack of previous experience using chain saws and to body weight well balanced. The left foot should be slightly get familiar with its use, it is recommended to practice forward from your right foot. -
Page 16: Felling And Bucking
Felling and Bucking Felling Restrictions. Do not attempt this EVER! • Do not cut down trees under heavy rain or while strong winds are blowing. Wait for suitable weather. • Do not cut down trees when people or animals are in the area. The safe distance standards for passersby are explained in “When Using the Chain saw”... - Page 17 Felling and Bucking Anchor Root Cutting • Anchor roots are those roots that stick out too much from the ground. When they are too big may make the felling job too difficult. They must be removed before felling. • First, make a horizontal cut through the root, some Anchor Root centimeter up the ground.
-
Page 18: Cutting Branches And Pruning
Felling and Bucking Bucking the Top of the Trunk Bucking the Bucking Below • Setting the lower side of the bar against the trunk, start Top of the Trunk the Trunk cutting the upper side of the trunk. • Apply pressure downwards. CAUTION •... -
Page 19: Adjustments And Maintenance
Adjustments and Maintenance • Shut off the chain saw before maintenance and service. Top Plate Top Plate Top Plate Top Plate Cutting Edge Cutting Edge • Use heavy-duty protective gloves. Depth Depth Gauge Gauge Chain saw Chain Maintenance Rivet • To make smooth and fast cuts, the cutting chain needs maintenance periodically. - Page 20 Adjustments and Maintenance Chain Depth Gauge 0,6 mm Depth Cutting Link (0,025”) Gauge Depth Gauge • The chain has cleaning teeth (Depth Gauge) placed in front of each tooth. Their design avoids getting too deep into the wood getting pinched and causing kickback. •...
-
Page 21: Troubleshooting
Adjustments and Maintenance Lubrication • Remember to disconnect the tool before cleaning or maintenance. • TAll the tool components are an important part of the The tool bearings have high grade lubricant and when insulating system and should only receive maintenance in used under regular conditions it lubricates for life. -
Page 22: Notes
Notes ENGLISH... -
Page 23: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center. -
Page 24: Warranty Policy
06060, where you can also purchase parts, components, consumables and accessories. The costs of transportation of the product that derive from its fulfillment of its service network are included. Truper will not require any proof of purchase to make the warranty effective. Phone number 800-018-7873. Made in China.
