Overhead door CodeDodger 2 Operating Instructions

2
This Wireless Keypad is compatible with all CODEDODGER® 1
and CODEDODGER® 2 radio equipped GENIE® products.
OPERATING INSTRUCTIONS
A Moving Door can cause serious injury or death.
1 Keep people clear of opening while Door is moving.
2 Do Not allow children to play with Wireless Keypad.
3 Wall Control should be mounted within sight of door, at least 5 feet above floor and clear of moving parts.
4 During programming, the Door Opener could begin to run, so stay away from the moving Door and its parts. To keep
the Door from moving, close the Door and disconnect it from the Opener by pulling the Emergency Release Cord.
CODEDODGER® 2 MODE OF TRANSMISSION
This page is for CodeDodger® 2 Only:
If you have an CodeDodger® 1 opener
or openers, go to the reverse side
of this instruction.
SECTION
B P
ASIC ROGRAMMING FOR
1
D CODEDODGER®
O OR
FOR CONVENIENCE
Program Keypad BEFORE mounting.
S 1:
C Y W K
TEP
REATING OUR IRELESS
(P I N )
ERSONAL DENTIFICATION UMBER
Press in order .
3 5 7
Press .
PROGRAM
Enter your PIN (3 to 8 characters).
Press .
PROGRAM
Close keypad cover and wait 30 seconds.
S 2:
TEP P S D
ROGRAMMING INGLE OOR
PROGRAM
Press and hold until both LEDs turn BLUE.
SET
ON THE OPENER
PROGRAM
ROUND LED
Figure 1
SET
LONG LED
Close
Travel
Figure 1
Button
Release button. Only round LED will be BLUE.
PROGRAM PROGRAM
Press , release again. Long LED should blink PURPLE.
SET SET
On the Wireless Keypad—enter your PIN.
Press . LEDs will stay on solid.
Press again. LEDs will turn off.
Press again. Door opener should run.
Press any key to stop opener. (It will automatically
stop at the fully open or fully closed position.)
Wait until Keypad Backlight turns off (approximately 30 seconds).
S 3: O O D O
TEP
PERATING NE OOR PENER
A To open or close the Garage Door.
Enter your PIN.
Press .
NOTE
If the Door does not move,check the LED on Keypad.
If the LED is blinking rapidly,the PIN was entered
incorrectly. After the LED stops blinking,re-enter
your PIN and try again.
Any Keypad Button will control the Door for 30 seconds
after the Door starts moving.
Rapid blinking of the red LED indicates an error. After a
few seconds the LED will turn off. Start over.
Proceed to Section 3 - Mounting Instructions.
For answers to questions, call 1-800-275-6187 , or visit
www.overheaddoor.com
Overhead Door Corp., 2501 S State Hwy.,Suite 200, Lewisville, TX
75067. Additional products can be ordered through local
Overhead Door® Professional Dealers. To locate a dealer near you,
call 1-800-929-DOOR.
ATTENTION
If your garage door opener has a Serial Number
sticker which looks like this, in which the
first two numbers are 10 or higher, your opener
is equipped with CODEDODGER®2.
MODEL AC SR3 OVERHEAD DOOR CORP.
FCC ID: B8Q AC SR3 Residential Door Operator
IC: 2133A-CSD1D 120V. 60HZ. 5A
S/N:10XXXXXXXXXXXX
FOR HELP CALL 1-800-275-6187 OR WWW.OVERHEADDOOR.COM
Follow the instructions on this page.
Otherwise, follow the instructions on back.
(KEEP FOR FUTURE REFERENCE)
WARNING
SECTION
P
ROGRAMMING FOR
2
D CODEDODGER®
O OR
FOR CONVENIENCE
Program Keypad BEFORE mounting.
S 1:
S 1:
C Y
TEP
TEP
REATING
(P I
ERSONAL DENTIFICATION
O
NE
Press in order
3
O
PENERS
Press .
PROGRAM
Enter your PIN (3 to 8 characters).
Press .
PROGRAM
Close keypad cover and wait 30 seconds.
PIN
EYPAD
S 2:
P
TEP
ROGRAMMING
All Door Openers will use the same PIN.
On your keypad:
Enter your PIN and press
Press again.
PROGRAM
Press the number of Doors (total) you wish
to control ( or
2 3
Press .
PROGRAM
O
PENER
On your opener's power head:
Select first opener and press and hold
both LEDs turn BLUE.
Release button. Only round LED will be BLUE.
PROGRAM
Press and release again. LEDs should blink PURPLE.
SET
Decide which Door will be Door #1,#2 and #3.
On your Wireless Keypad:
Open
Enter PIN and press
Travel
Button
Press the number that you have picked for
this door or
1 2
Press 3 times — opener will run.
Repeat procedure below dotted line for remaining openers.
Wait until Keypad Backlight turns off (approximately 30 seconds).
S 3:
O
TEP
PERATING
Following programming—
On your Wireless Keypad:
Enter your PIN.
Press .
Press the number of the door you wish to
operate or
1 2
Press any key to operate the door.
NOTE
If the Door does not move,check the LED on Keypad.
If the LED is blinking rapidly,the PIN was entered
incorrectly. After the LED stops blinking,re-enter
your PIN and try again.
Any Keypad Button will control the Door for 30 seconds
after the Door starts moving.
Rapid blinking of the red LED indicates an error. After a
few seconds the LED will turn off. Start over.
Proceed to Section 3 - Mounting Instructions.
FCC and IC CERTIFIED
This device complies with FCC Part 15 and RSS 210 of Industry Canada. This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which may be determined by turning the equipment OFF and ON, the user is
encouraged to try to correct the interference by one or more of the following measures:
Re-orient or relocate the receiver antenna.
Increase the separation between the opener and receiver.
Connect the opener into an outlet on a circuit different from that to which the receiver is connected.
Consult your local dealer.
F :
EATURES
Ability to Control up to three
Overhead Door®CODEDODGER®1
or 2 Openers
Simple to Program and Install
PIN Codes can be up to 8 Characters
Low Battery Power Indicator
Stays Programmed During
Battery Change
Temporary PIN for Special
Purpose Access
T N
OOLS EEDED
Drill with 1/16" Drill Bit
Phillips Screwdriver
Pencil
Mounting Screws INCLUDED
If Safety Reverse does not work properly:
1 Close Door and disconnect the opener using Emergency Release Cord.
2 Do not use Door Opener, Remote , or Wireless Keypad.
3 Refer to Door and Door Opener Owner's Manuals before attempting
any repairs.
SECTION
M
ULTIPLE
3
O
P ENERS
The Keypad must be mounted in sight of the Door(s), at
least 5 feet above the ground and clear of any moving
Door parts.
A Mount Keypad.(Mounting screws located inside
Battery Compartment.)
W K PIN
OUR IRELESS EYPAD
N )
UMBER
.
5 7
M D O
ULTIPLE OOR
PENERS
.
PROGRAM
SECTION
4
).
C
HANGING
Enter your current PIN and press
PROGRAM
until
Enter your NEW PIN and press
SET
U
SING A
A temporary PIN allows temporary access to your home by
repair persons, meter readers, etc.if you so desire.
Enter your current PIN and press
.
Enter your TEMPORARY PIN and press
.
3
DO NOT reprogram the Door Opener (s).
Temporary PIN remains active only until the next time
your ormal PIN is entered.
M D O
ULTIPLE
OOR PENERS
F
ORGOT
If you have forgotten your PIN or you fear it may have fallen
into unauthorized hands, you must erase the old programming.
Press and hold
Wile holding
5 seconds.
.
3
Release both buttons. You must now start from the
beginning and reprogram your Wireless Keypad.
C
HANGING
If the Keypad backlight does not come on, this indicates the
need to replace the batteries.
Press in on the front of the battery cover and slide it down
off of the Keypad.
Remove used batteries and replace
with "AAA." Make sure the
batteries are inserted properly
using the polarity markings.
No programming is lost during
replacement of batteries.
Interchangeable 37257501192
Flip-up Cover
available in 3
optional Classic
Colors to match
your home' s PROGRAMMING
INSTRUCTION
exterior decor
Backlit
Program
Keypad
Button
for Ease
of Use
PROG
:
GREEN LED
at Night
ABC DEF
2
1 3
indicates Pre-Set
GHI JKL MNO
4 5 6
Battery
toIntellicode® 2 PQRS TUV WXYZ
7 8 9
Compartment
0
2 AAA Batteries
(included)
M I
OUNTING NSTRUCTIONS
Remove Battery Cover and batteries. (See Figure 3).
Drill a 1/16"pilot hole for the top mounting screw.
Install a screw into the drilled
Figure 2
hole,leaving a 1/8" gap
between the screw head
and the wall. (See Figure 2.)
Wall
Hook the Keypad over
the screw.
Mark and drill pilot hole and
fasten bottom screw.
screw head gap
I nstall Batteries and Cover.
A O
DDITIONAL PERATIONS
Y PIN
OUR
.
PROGRAM
.
PROGRAM
T PIN
EMPORARY
3 times.
PROGRAM
.
PROGRAM
NOTE
n
Y PIN (R W K )
OUR ESETTING IRELESS EYPAD
.
PROGRAM
press and hold for
PROGRAM
B
ATTERY
Polarity
markings
Covers available in:
Press
Tan - P/N 37227T
here
Almond - P/N 37227U
Figure 3
Gray - P/N 37227S
White - - P/N 37227R
Battery
Cover
