Summary of Contents for AMAREW XM180
- Page 2 E M P O W E R S Y O U Thank you for choosing our XM-series. www.amarew.com...
- Page 3 Amarew XM-series product manual Extendable tiller Figure A Battery indicator Power cord plugs Depth adjustment collar Counter force bold Transom mount screws Angle adjustment lever Propeller Battery cable Anode...
-
Page 4: Table Of Contents
Amarew XM-series product manual Table of contents General information p. 4 Safety information p. 4 Benefits p. 4/5 AMAREW® XM Technology p. 5 Usage instructions p. 6/7 Advanced features p. 8 Replacing the propeller p. 8 Calibrating the tiller p. 9 Maintanence p. -
Page 5: General Information
General information Congratulations! Thank you for choosing an AMAREW® electric outboard motor. We hope you will love using it. AMAREW® electric outboard motors are designed and developed by our specialized engineering team. After years of effort, we have succeeded in producing superior electric outboard motor series that fit various customers’... -
Page 6: Amarew® Xm Technology
6. Robust mounting system: AMAREW® XM-series are designed with durability in mind. Especially the mounting system, which we have introduced, is very strong. 7. Stall protection: AMAREW® XM-series are unlike many others on the market, because they come fitted with the latest AMAREW® XM stall protection technology. -
Page 7: Usage Instructions
Amarew XM-series product manual Usage instructions Figure B Propeller installment: Make sure the propeller and the pin are aligned correctly. Otherwise the propeller cannot be properly fixed. Place the propeller, washer and locknut respectively. Then hold the propeller with one hand and use a wrench or a spanner to tighten the locknut with your other hand, by turning it clockwise (see figure B). - Page 8 Amarew XM-series product manual Then connect the red battery cable to the positive (+) terminal and the black battery cable (see figure A) to the negative (-) terminal and check that the wiring is connected correctly. Make sure that all battery connections are tighted with at least 10Nm of torque by applying a torque wrench.
-
Page 9: Advanced Features
Amarew XM-series product manual Advanced features 1. Low voltage protection: When the voltage displayed is below 10V (XM80) or 20V (XM120 or higher), the motor will enter the low voltage protection mode: power output will be reduced to 50% in order to protect the battery. -
Page 10: Calibrating The Tiller
Amarew XM-series product manual Calibrating the tiller If the “dido” sound does not go off when the motor and the battery(ies) are connected, even with the tiller handle in the zero position, open the top cover and check if the screw of the potentiometer is loose. -
Page 11: Trouble Shooting
Amarew XM-series product manual Trouble shooting Problem Solution 1. Check for line of weed on the propeller 2. Check the battery status. Speed loss 3. Check the battery terminals, the battery cable and power cord plugs. 1. Check for line or weed on the propeller. -
Page 12: Technical Data
Amarew XM-series product manual Technical data Amarew ® electric XM80 XM80R XM120 XM120R XM160 XM160R XM180 XM180R outboard motor 1470 2000 2722 Input power in W 1000 1365 1700 Propulsive power in W Stactic thrust in lbs Efficiency at maximum thrust in % ≥83... -
Page 13: Year Warranty
3 Year warranty Limited warranty coverage (1 year) AMAREW® warrants its products against defects in material or workmanship. This warranty offers coverage for one year from the date of purchase, depending on the specific parts for which warranty is requested (see the table below). The reference for the coverage period is the product serial number together with your original proof of purchase. - Page 14 AMAREW®, or the modification and/or removal of parts. The following table provides information about which parts are covered by warranty...
