Toolshop 240-2078 Operator's Manual

7-1/4" compound miter saw
Hide thumbs

Advertisement

Table of Contents

240-2078
7-1/4" COMPOUND MITER SAW
Operator's Manual
SAVE THIS MANUAL
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
For questions about this product, please call 1-866-915-8626

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 240-2078 and is the answer not in the manual?

Questions and answers

kasmer
May 21, 2025

where dose linkage a hook up came unhook

0

Related Manuals for Toolshop 240-2078

Summary of Contents for Toolshop 240-2078

  • Page 1 240-2078 7-1/4" COMPOUND MITER SAW Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference. For questions about this product, please call 1-866-915-8626...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING : When using electric tools, machines or equipment, basic safety shock, and personal injury. READ INSTRUCTIONS BEFORE USING THIS TOOL 1. KEEP WORK AREA CLEAN. Cluttered areas can cause injuries. 2. CONSIDER WORK AREA ENVIRONMENT. Don’t use power tools in damp, wet, or poorly lit locations.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS 15. USE EYE PROTECTION. or coarse dust. 16. SECURE WORK. 17. DON’T OVERREACH. 18. MAINTAIN TOOLS. 19. AVOID UNINTENTIONAL STARTING. Be sure the switch is in the OFF posi 20. ALWAYS CHECK AND MAKE SURE TO REMOVE ANY ADJUSTING KEYS OR WRENCHES 21.

  • Page 4: Functional Description

    SAFETY PRECAUTIONS FOR COMPOUND MITER SAW 8. ALWAYS USE TABLE EXTENSIONS AND CLAMPS to support the material 9. THE MATERIAL SHOULD BE PLACED FIRMLY AGAINST THE FENCE AND TABLE kick back. 10. DO NOT START THE SAW WITH THE BLADE IN CONTACT WITH ANY SURFACE.

  • Page 5: Specifications

    SPECIFICATIONS Current rating: 7.5 Amps No load speed 5,500 RPM Blade Size: 7-1/4" Cutting Capacity 90° Cross cut: 2" x 4" 45° Miter cut: 2" x 2-1/4" 45° Bevel cut: 3/4" x4" 45° Miter/Bevel cut: 3/4" x 2-1/4" Contents: Miter Saw, (1)7-1/4"x24 Tooth Carbide Blade, Blade Wrench, (1) Hold-Down Clamp, Dust Collection Bag &...

  • Page 6: Maintenance

    OPERATING PROCEDURES REMEMBER: Before use, release the head lock button(#10 on page 4) and raise the handle. the hold-down clamp at any position. operation. MODES OF USE Crosscut: Miter cut: miter lock knob(# 7 on page 4). Move the table rotation to the left or right, up to 45°, either way. Quickly locate 0°, 15°, 22.5°, 30°...
  • Page 7 MAINTENANCE ALIGNING MITER AND BEVEL Aligning Miter Angle 1. Lower the head assembly and push in the lock pin to lock in the lower position. Make sure table is in 0° detent and tighten miter lock knob. Place a combination square (1) against the fence(2) and next to the blade (3) as illustrated.
  • Page 8 MAINTENANCE MAINTENANCE REPLACING SAW BLADE power cord of the miter saw 1. When replacing the saw blade,make Arrow sure the new saw blade has a diameter of 7-1/4", RPM rating of at least 5,500 and arbor hole of 5/8" diameter. 2.

  • Page 9: Parts List

    P ARTS LIST Please refer to the schematic drawing on page 10.

  • Page 10: Schematic Drawing

    SCHEMATIC DRAWING WARNING Repairs should be made by an authorized repair center. Do not this power tool . Please contact 1-866-915-8626 open or disassemble for questions regarding this power tool.
  • Page 11 TOOL SHOP® 7-1/4" 7.5 AMP COMPOUND MITER SAW WARRANTY 1-YEAR LIMITED WARRANTY: This brand power tool carries a 1-Year Limited Warranty to the TOOL SHOP® original purchaser. If the tool fails within one (1) year from the date of purchase, simply bring this tool with your original sales receipt back to your nearest retail store.
