Summary of Contents for Toolshop 240-2093
- Page 1 Operator’s Manual...
- Page 2 : When using electric tools, machines or equipment, basic safety shock, and personal injury. Cluttered areas can cause injuries. Don’t use power tools in damp, wet, or poorly lit locations. Don’t expose tools to the rain. Keep the work area away from the work area.
- Page 3 or coarse dust. Be sure the switch is in the posi if the tool would accidentally start. any tool when you are tired. center. Don’t use the tool if switch does not turn it on and off properly. parts. shock or injury. injury.
- Page 4 cause injury. Voltage: 120 volts AC, 60Hz Current rating: 15 Amps Blade Speed: 5000 RPM(No-Load Speed) Blade Diameter: 10" 40 tooth carbide tipped Arbor Size: 5/8" Positive Miter Stops: 0, 15, 22.5, 30 & 45 degree Miter Angle: 45 degree Left/ 45 degree Right Bevel cuts up to 45 degree Left Power Cord: 6 ft Weight: 27.5 lbs...
- Page 5 Be sure the saw is disconnected from its power source before making any repairs or performing maintenance! no part of the tool contacts the hold-down clamp. After unpacking, reading the instructions, attaching the machine to the workbench, and checking that all attachments are correctly installed, you can use your saw. Be sure to wear the appropriate protective equipment.
- Page 6 lower blade cally. cally. side of the table to prevent interfering with the movement of the cutting head. Always check before making the cut if there is any potential interference from the clamp or any other part of the machine. Even though the angles are marked on the machine, it is always a good idea to check them by making a trial cut.
- Page 7 Make sure the Fence is perpendicular (at a 90° angle) to the Saw Blade,using carpenter square (can be purchased at any hardware store, and comes in various sizes.). , using a small carpenter square; the screws and adjust the needle. , using a small carpenter square;...
- Page 8 1.When replacing the saw blade, make sure the new saw blade has a diameter of 10”, an RPM rating of at least 6,000, and an arbor hole of 5/8” diameter. 2.When mounting the new saw blade, the direction arrows on the blade should correspond with the arrow on the upper guard.
- Page 9 5.Rotate the lower blade guard (B) out of the way. (see Figure 4.) FIG.4 6.Depress the spindle lock (F) to keep the saw blade from turning.(See Figure 5.) FIG.5 FIG.5 FIG.5 7.Use the wrench to unscrew and remove the spindle bolt.NOTE: The Spindle Bolt unscrews in a clockwise direction.Then,remove the Outer Flange.
- Page 10 Please refer to the schematic drawing on page 11.
- Page 11 Repairs should be made by an authorized repair center. Do not this power tool . Contact at 1-866-915-8626 open or disassemble for questions regarding this power tool.
- Page 12 10" 15 AMP SLIDING MITER SAW WARRANTY TOOL SHOP® This brand power tool carries a 1-Year Limited Warranty to the TOOL SHOP® original purchaser. If the tool fails within one (1) year from the date of purchase, simply bring this tool with your original sales receipt back to your nearest retail store.
