Clas Ohlson 31-8215 Manual

12 V 20 l Warmer/Cooler
Art.no 31-8215
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our
Customer Services.
Safety
• Use the cooler/warmer in an area where there is constant free
airflow available.
• Never cover the cooler during use.
• Always place the cooler/warmer on a flat, stable surface.
• Do not subject the cooler/warmer to blows or impacts.
• Do not attempt to open the housing or modify the cooler/warmer in any way.
• All repairs must only be carried out by qualified service technicians.
• This cool box contains electronic components and must only be used
indoors, under cover or in such conditions that it is not exposed to
moisture, water or other liquid.
• The cool box is only intended for temporary cooling/warming. It is not
intended for continuous use over an extended period.
Responsible disposal
This symbol indicates that this product should not be disposed
of with general household waste. This applies throughout the
entire EU. In order to prevent any harm to the environment
or health hazards caused by incorrect waste disposal, the
product must be handed in for recycling so that the material
can be disposed of in a responsible manner. When recycling
your product, take it to your local collection facility or contact the place of
purchase. They will ensure that the product is disposed of in an environ-
mentally sound manner.
Specifications
Connection 12 V DC
Fuse (8 A, 6 × 32 mm)
Cooling capacity 46 W (cools to max. 15–18 ºC below
the ambient temperature)
Warming capacity 43 W (warms up to max. 65 ºC)
Capacity 20 l
Dimensions (W × D × H) 39 × 28.5 × 42.5 cm
Weight 3.9 kg
Buttons and functions
1 2 3
1. Carrying handle (the handle 3. Handle to open the lid
locks the lid in position as
4. Fan
shown in the picture, unclip
5. Function selector with LED display
the handle to open the lid)
2. Cord storage
Operating instructions
Note: The LED display shows the approximate temperature of the warmer/
cooler. Several factors affect the temperature, such as the ambient
temperature, how much is stored in the box, and how it is packed.
1. Connect the warmer/cooler to a 12 V socket.
2. Select the desired function, (HOT) or (COLD) using the function
switch (5). There are LED indicators above each of the two functions.
Green = cooler, red = warmer.
3. Turn the selector switch to OFF to turn the warmer/cooler off.
Note:
• Turn off the warmer/cooler off and let it rest for 5 min before changing
functions from either heat to cold or vice versa.
• The warmer/cooler has an automatic fan which turns on and off
automatically during heat mode to regulate the temperature.
Care and maintenance
• Always turn off the warmer/cooler and make sure it is unplugged from
4 5
the 12 V socket before cleaning.
• Never pour water directly into the warmer/cooler during cleaning.
Wipe the interior and exterior with a damp cloth. Use a mild
cleaning agent. Never use solvents or corrosive cleaning products.
• Turn off the warmer/cooler and remove the cable from the 12 V
socket in the car/caravan when it is not being used.
• Once cleaned, the warmer/cooler should be stored in a dry, dust-free
environment and out of children's reach.
Replacing the fuse
The plug also doubles as a fuse holder. For fuse replacement, do the following:
1. Unscrew the tip of
the plug where the fuse
holder is located.
Troubleshooting guide
The warmer/cooler
won't turn on.
The warmer/cooler's fan
turns on and off regularly
when using heat mode.
English
2. Pull out the fuse holder and replace
the damaged fuse (8 A, 6 × 32 mm)
when necessary. Screw the fuse
holder back into place to complete
the procedure.
• Make sure that the power lead is fully
connected to the 12 V socket.
• Check that the 12 V socket is live.
• Check the fuse in the plug of
the connection cable. Change if necessary,
see the Changing the fuse section above.
The automatic fan may turn on and off
sporadically in order to maintain proper
temperature regulation. This is completely
normal.
