- Page 1 VIP-4060 Video Image Processor Operator’s Manual DD1804047 Rev 09—08 May 2015 201 Daktronics Drive PO Box 5128 Brookings, SD 57006 tel 800-843-5843 fax 605-697-4700 www.daktronics.com...
- Page 2 Daktronics is a registered trademark of Daktronics, Inc. Firefox is a registered trademark of Mozilla Foundation. Internet Explorer, Microsoft, Silverlight, and Windows are registered trademarks of Microsoft Corporation.
-
Page 3: Table Of Contents
Computer-to-VIP-4060 Communication ......................4 Downloading DisplayFind Application ....................5 Launching DisplayFind Utility ........................5 DisplayFind Utility ............................5 Finding the VIP-4060 Network Internet Protocol (IP) Address ............. 6 Computer System Requirements ........................6 Software Installation ............................7 Detecting & Installing Silverlight Application .................. - Page 4 Load Display Configuration Backup Icon ....................17 Retrieve Configuration Icon ........................17 Send Configuration Icon ..........................17 Using Primary & Backup VIP-4060 Systems ....................18 Section 4: VIP-4060 Configuration Tabs ......................19 Display Control Tab ............................19 Display Mode .............................. 20 Test Pattern ............................20 DVI ................................. 21 SDI ................................21 VMax ..............................
-
Page 5: Introduction
This manual is intended to help Daktronics customers operate the VIP-4060. Daktronics recommends reviewing all of the information in this manual in order to understand the features that the VIP-4060 offers. This manual assumes the user has a basic working knowledge of the Windows operating system, including ®... -
Page 7: First-Time System Setup & Launch
There are four video feed options - DVI, 720p SDI, 1080p @30fps SDI, or Daktronics V-Max signal - for ™ connecting a video feed to the VIP-4060 system. The type of video feed determines which will be used. In stand-alone systems, the options are generally 720p SDI or DVI. Daktronics-supplied control systems use V-Max 4 signal output to connect components. -
Page 8: Connecting Dvi Video
Connecting DVI Video To connect the DVI video to the VIP-4060 system, follow the steps below: 1. Insert a male plug into the female jack. 2. Turn the screws on the male plug clockwise to lock. Refer to Figure 3. Figure 3: DVI Input... -
Page 9: Downloading Displayfind Application
1. Open a web browser (i.e. Internet Explorer or Firefox browser). ® ® 2. Navigate to dakfiles.daktronics.com. 3. Click venus1500 > Utils > DisplayFind > DisplayFind.exe. 4. Select Run to download the DisplayFinder utility or Save to save the file to the computer for later use. Launching DisplayFind Utility Figure 8: DisplayFind Icon The DisplayFind file automatically opens if Run was selected in Step 4 above. -
Page 10: Finding The Vip-4060 Network Internet Protocol (Ip) Address
Figure 11: Display Finder Host Configuration Protocol (DHCP) name from the label on the back of the VIP-4060 to select the appropriate system. The address name begins with M4 or DAKT. Refer to Figure 12 and Figure 13 for examples. Figure 13: DAKT Address Name... -
Page 11: Software Installation
Silverlight application. ® Silverlight application version 2.0 or newer is required to use the VIP-4060. The VIP-4060 will indicate if the ® system needs to install the Silverlight application or perform an update (internet access required). -
Page 12: Installing Java ® Software
Language and Java Software ® ® JavaScript language must be enabled to use the VIP-4060 user interface. If JavaScript language is not ® ® enabled, a prompt will open or the user may be asked to install the Silverlight application when it has ®... - Page 13 2. Click the drop-down arrow for the Show list and select All add-ons. Refer to Figure 22. Figure 22: View All Add-Ons 3. Navigate to Oracle America, Inc. in the results window using the scroll bar on the right. 4. Select the line for Java Plug-in 1.60_xx and click the Enable button in the lower-right corner of the window.
-
Page 14: Firefox ® Browser
VIP-4060 System Login Figure 24: Enable JavaScript Language ® To log in to the VIP-4060, follow the steps below: 1. Locate the system’s Dynamic Host Configuration Protocol (DHCP) name on the label on the back of the VIP-4060. This label will begin with either M or DAKT. -
Page 15: Choosing A Configuration Port
If the login was unsuccessful, an error message will appear in the Log In box. Refer to Figure 27. Try logging in again or contact Daktronics for assistance. Note: If Java software was installed just prior to login, a ® series of warning security alerts will open: • For the Java has discovered application... -
Page 16: Display Adjustments
3. Select the Monitor drop-down list. Click Input or Output to enable easier configuration. Refer to Figure 31. 4. Click the Source & Target sub-tab and select Source to choose the video signal. Refer to Figure 32. 5. Choose a fill mode for the display from the Full, Figure 31: Monitor Drop-Down List Pillar, and Letterbox icons located above the Source tab. -
Page 17: Display Backup
Display Backup Display backup clones all configuration files and the current translation table. It is highly recommended that the system configuration is cloned prior to making any changes. Each machine that accesses the VIP-4060 should include a saved working copy of the controller files. Note: The Backup display configuration function will duplicate all settings and Media Access Control (MAC) addresses and overwrite low-level configuration. To back up the configuration files, follow the steps below: 1. Click the Backup display configuration icon to open the Save As window. Refer to Figure 36. Backup display configuration 2. Choose the Save As storage location by using the Look In drop-down list or the folder presentation pane. -
Page 19: User Interface Basics
Section 3: User Interface Basics The VIP-4060 system’s application windows share common elements that are always visible to the user, including a basic header bar, presentation area, right column, and left column. Refer to Figure 38. Window Basics • Header Bar contains the application title Daktronics Remote Display Configuration. -
Page 20: Failed & Pending Communication
Adjust the Communication Timeout setting by increasing or decreasing the length of time (in seconds) that is allowed Send configuration to pass before the VIP-4060 reports a connection problem. Refer to Figure 42. Figure 41: Left Column Application Menu Buttons Monitor time limit controls how long the monitored stream is presented. -
Page 21: Backup Display Configuration Icon
When the Communication Settings icon is selected, followed by the Configuration tab, the Retrieve Configuration icon becomes visible in the left column. Refer to Figure 41. This feature can be used to quickly back up current VIP-4060 configuration settings. Send Configuration Icon When the Communication Settings icon is selected, followed by the Configuration tab, the Send Configuration icon becomes visible in the left column. -
Page 22: Using Primary & Backup Vip-4060 Systems
Using Primary & Backup VIP-4060 Systems Displays can be configured to use primary and backup VIP-4060 systems. Both primary and backup systems cannot be Active at the same time. To change which VIP-4060 system is active, follow the steps below: 1. Log into the web interfaces of the primary VIP system and the backup VIP system. -
Page 23: Vip-4060 Configuration Tabs
Section 4: VIP-4060 Configuration Tabs Display Control Tab The Display Control tab includes tools for setting video sizes and adjusting dimming, display mode, and video appearance controls. Refer to Figure 48. Note: Any changes made in the Display Control tab are automatically stored and applied to the display. -
Page 24: Display Mode
Displays green on every pixel of the display. All On Blue Displays blue on every pixel of the display. All On White Displays white on every pixel of the display. Module Id Displays a pattern that numbers each display module. 20 VIP-4060 Configuration Tabs... -
Page 25: Dvi
VMax connects the VIP-4060 to Daktronics control system devices such as VIP-4500 and DMP-7000. V-Max 4 is a proprietary Daktronics data language that may be used to control dimming, gamma, color ™ correction, and other configuration settings. When VMax is selected, it takes precedence over all other dimming modes except for ERTD dimming. - Page 26 ProLink 5 SATA Port B on the PLR. ProLink 5 Ports If there is connection where needed, all the modules will turn green. Figure 55: PLR Fail from SATA Ports If there is no connection where needed, all the modules will turn red. 22 VIP-4060 Configuration Tabs...
-
Page 27: Dimming Mode
(Auto), manually (Manual), by the display’s location (GPS), or according to Enhanced Real-Time Data (Ertd). Refer to Figure 58. Note: Although Schedule is an option in the Dimming mode drop-down list, it is not supported by the VIP-4060 system. Figure 58: Dimming Options VIP-4060 Configuration Tabs... -
Page 28: Auto
Figure 61: Configuration GPS Settings ERTD Enhanced Real-Time Data (ERTD) is a communication protocol which uses scripts to define how the VIP-4060 system controls display dimming. Ertd overrules all other dimming modes except when thermal dimming is active. Refer to Section 5 for additional information. 24 VIP-4060 Configuration Tabs... -
Page 29: Color Adjustment
For example, over-saturated skin tones appear redder. The default is a neutral 50 percent. Adjusts the detail of content edges. Raising the sharpness level adds artificial edges to Sharpness objects and increases contrast along the edges. The default is 5 percent. VIP-4060 Configuration Tabs... -
Page 30: Source & Target
Indicates the height and width dimensions of the active TotalSize portion of the video input. Shows the height and width of the selected portion of the ActiveSize input source. Frequency Indicates horizontal, vertical, and pixel refresh frequency. Figure 65: Input Video Status Information 26 VIP-4060 Configuration Tabs... -
Page 31: Tools Tab
The Set Time/Date feature synchronizes the display time with the system’s (host computer) time. Click the Set Time/Date button to perform the time synchronization. All time settings are time zone independent. Run File Check The Run File Check feature is used to troubleshoot corrupted files on the VIP-4060 system. If prompted to run the file check when logging in to the VIP-4060, the check should be performed as soon as possible. The display will be blank while the check is running. To perform a file check, follow the steps below: 1. Click Run File Check while on the Tools tab. The File system check window opens. -
Page 32: Reset Display
Shows the temperature and connection state of each sensor within or connected to the Temperature controller. The Onboard reading shows the operating temperature of the VIP-4060. Shows the current date and time, selected time zone, daylight-savings time (DST) status, and Clock clock source (Network Time Protocol or Real-Time Clock). -
Page 33: Additional Tabs
Configuration and Advanced tabs. However, users should contact Daktronics Technical Services before modifying the settings in these tabs. Note: Changes made under the Panel Adjustment, Configuration, and Advanced tabs may adversely affect display operation and image quality. Improper configuration may also result in connectivity loss to the VIP-4060. Changes to these settings should be made only with instruction from Daktronics Technical Services. VIP-4060 Configuration Tabs... -
Page 35: Exchange/Repair & Return Programs
Repair & Return Program. Exchange Program Daktronics unique Exchange Program is a quick service for replacing key parts in need of repair. If a part requires repair or replacement, Daktronics sends the customer a replacement, and the customer sends the defective part to Daktronics. -
Page 36: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: 1. Call or fax Daktronics Customer Service. Refer to the telephone number listed on the previous page. Fax: 605-697-4444 2. Receive a Return Materials Authorization (RMA) number before shipping. -
Page 37: Glossary
BNS Cable: Common type of RF (radio frequency) connector used for terminating coaxial cable. Boot loading: Process that allows changes to the firmware. Calibration: Process of adjusting the intensity level of each pixel in a Daktronics LED video display as needed to improve the uniform intensity of the entire display. -
Page 39: Appendix A: Technical Specifications
Appendix A: Technical Specifications Refer to the table below for technical specifications of the VIP-4060. Specification VIP-4060 8.89 cm (3.5") high Physical Size 22.23 cm (8.75") wide 31.12 cm (12.25") deep Weight 3.24 kg (7.15 lb) Video Compatibility DVI/VGA, VGA-SXGA, HD-SDI, full 720p, 1080p @ 30fps Display Inputs DVI-I, HD/SDI-SDI, V-Max 4, Analog Inputs ™... -
Page 41: Appendix B: Supplementary Documents
Appendix B: Supplementary Documents This section includes the following: • DD1733958 VIP-4060 Quick Guide Supplementary Documents... -
Page 43: Appendix C: Daktronics Warranty & Limitation Of Liability
VIP-4060 Quick Guide 1 of 6 The VIP-4060 is the interface that drives video to the display and meets operational needs such as dimming, displaying test patterns, and adjusting gamma and color controls. This quick guide explains basic VIP-4060 connections and setup as shown in Figure 1. - Page 44 Note: If multiple displays are found, use the IP address or name to confirm the identity of the correct display. Figure 9: Daktronics Display Finder DD1733958 Rev 05 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 02 March 2015 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
- Page 45 ® 1. Click the Java is not installed notification. 2. Follow the instructions on the page to complete the installation. The JavaScript application must be enabled to use the VIP-4060 Configuration Utility. If the JavaScript application is ® ® not enabled, follow the steps below to enable it on a specific web browser:...
- Page 46 This includes basic identifying information such as the table’s author, ED number, contract, title, and task. Refer to Figure 15. Contact Daktronics Technical Services before uploading a translation table. Navigate to the Configuration tab and click the Display sub-tab.
- Page 47 1. Click the Load Display Configuration Backup icon. Refer to Figure 18. 2. Navigate to the file’s storage location. Select the file and click Open to reload the configuration. DD1733958 Rev 05 201 Daktronics Dr. P.O. Box 5128 Brookings, SD 57006 02 March 2015 tel: 800-325-8766 fax: 605-697-4700 www.daktronics.com...
- Page 48 Contact Info and Where to Get Help Access the VIP-4060 Operator’s Manual via the blue question mark button in the top-left corner of the configuration utility screeen. Refer to Figure 19. If further assistance is required, Daktronics Customer Service is also available 24/7 via phone or online connection.
- Page 49 Appendix C: Daktronics Warranty & Limitation of Liability This section includes the Daktronics Warranty & Limitation of Liability statement. Daktronics Warranty & Limitation of Liability...
- Page 50 ...
- Page 51 DAKTRONICS WARRANTY & LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser agrees to be bound by and accept these terms and conditions. Unless otherwise defined herein, all terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
- Page 52 In no event shall Daktronics be liable to Purchaser or any other party for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the purchase price of the Equipment actually delivered to and paid for by the Purchaser. The Purchaser’s remedy in any dispute under this Warranty shall be ultimately limited to the Purchase Price of the Equipment to the extent the Purchase Price has been paid.
