- Page 1 14-Slot Media Converter Chassis Instructions Model 507356 ( IMCC-14 ) Important: Read before use. Importante: Leer antes de usar. For additional benefits: Scan to register your product warranty or go to: register.intellinet-network.com/r/507356...
- Page 2 Instructions Product Information Product Overview The Intellinet Network Solutions Media Converter Chassis (Model # 507356) accommodates up to 14 media converters in a single unit. The media converter Chassis allows hot-swapping the media converters and provides strong redundancy due to its two integrated power supplies.
- Page 3 Instructions Installation 1 Remove the slot cover by turning the screw counter clockwise. 2 Attach the carrier bracket to the media converter. First, unscrew the two screws on the side of the media converter housing, as indicated by the circles. 3 Next, use these screws to affix the bracket to the media converter...
- Page 4 Instructions 4 Insert Media Converter into the chassis, and then tighten the screw by turning it clockwise. 5 Install the chassis in a standard 19” rack or cabinet. Connect both power supplies with a power outlet and set them both to the On position. Maintenance •...
- Page 5 Instructions WASTE ELECTRICAL & ELECTRONIC EQUIPMENT DISPOSAL OF ELECTRIC AND ELECTRONIC EQUIPMENT (Applicable In The European Union And Other European Countries With Separate Collection Systems) ENGLISH: This symbol on the product or su punto de venta o a un punto de its packaging means that this recolección municipal para su reciclaje.
- Page 6 GARANTIE À : | GWARANCJA NA: | GARANZIA A: intellinet-network.com EN MÉXICO: Póliza de Garantía Intellinet — Datos del importador y responsable ante el consumidor IC Intracom México, S.A.P.I. de C.V. Av. Interceptor Poniente # 73, Col. Parque Industrial La Joya, Cuautitlán Izcalli, Estado de México, C.P. 54730, México.
- Page 7 : Urządzenie spełnia wymagania CE 2014/30/EU I / lub 2014/35/EU. Deklaracja zgodności dostępna jest na stronie internetowej producenta: ITALIANO : Questo dispositivo è conforme alla CE 2014/30/EU e / o 2014/35/ EU. La dichiarazione di conformità è disponibile al: support.intellinet-network.com/barcode/507356 North & South America Asia & Africa Europe...
- Page 8 © IC Intracom. All rights reserved.Intellinet Network Solutions is a trademark of IC Intracom, registered in the U.S. and other countries. Printed on recycled paper. INT_507356_UM_0723_REV_5.11...
