OWNER'S MANUAL
MEDICAL MONITOR
Please read this manual carefully before operating your set and retain it for future reference.
27HK510S
www.lg.com
Copyright
2022 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading

Related Manuals for LG 27HK510S-W.AWP

Summary of Contents for LG 27HK510S-W.AWP

  • Page 1 OWNER’S MANUAL MEDICAL MONITOR Please read this manual carefully before operating your set and retain it for future reference. 27HK510S www.lg.com Copyright 2022 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    CONTENTS ON CLEANING ............3 LICENSE ..............4 OPEN SOURCE SOFTWARE NOTICE INFORMATION ..4 ASSEMBLY AND PREPARING ........5 USER SETTINGS ............14 TROUBLESHOOTING ..........29 PRODUCT SPECIFICATIONS ........31 EXTERNAL CONTROLLER SETUP ......... 38...

  • Page 3: On Cleaning

    ON CLEANING Please note that this information is for proper use and safety of the equipment. The following symbols may indicate a hazardous situation in which, if not heeded, may result in serious injury or even death to the user or others, or damage to the equipment.

  • Page 4: License

    . registered trademarks of HDMI Licensing Administrator, LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of Inc. performing such distribution (such as the cost of media, shipping, and handling) upon email request to ...

  • Page 5: Assembly And Preparing

    ASSEMBLY AND PREPARING Product Composition Please check whether all the components are included in the box before using the product. If there are any missing components, contact the retailer where you purchased the product. Note that the product and related components may look different from those shown here. Owner's Manual/Regulatory Manual/Cards Power Cord DVI Cable...
  • Page 6 • It is recommended to use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Drivers and Software Installation Priority • Only use components listed below that meet the listed standard. Unauthorized components may cause Recommended damage to and malfunction of the product.
  • Page 7 Product and LED Control buttons Front Bottom...
  • Page 8 LED Control button Functions • Selects the input mode. • Adjusts display mode for 2 or more screens. • Opens the [Hot key Settings] menu. • Adjusts the screen brightness. • Selects and confirms menus or options - Automatically sets screen to optimal settings in analog video signal. •...
  • Page 9 Connectors Back D-SUB / DVI IN DVI OUT SDI IN SDI OUT HDMI IN SERVICE ONLY COMPONENT IN D-SUB / DVI IN DVI OUT SDI IN SDI OUT HDMI IN SERVICE ONLY COMPONENT IN...
  • Page 10 Potential Equalization Conductor • Connect an equipotential plug. • This USB port is used only for service. (USB Connector) • Connect the RS-232C terminal with an external device to control the monitor. • Used for HW Calibrator (Optional Accessory) connection. •...
  • Page 11 Installing the Monitor Cable connection and organize Before connecting the connectors, remove the back door as shown below. CAUTION • When the back door is attached to the monitor, the monitor meets water resistance standards. Do not use the monitor with the back door detached, as the water resistance capability is not guaranteed without the door. •...
  • Page 12 NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not To install the monitor to a wall, attach a wall mount plate (optional) to the back of the monitor. liable for any accidents relating to the use of non-standard screws.
  • Page 13 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions.

  • Page 14: User Settings

    USER SETTINGS Activating the Quick Menu Press to activate the LED Control Button. When the LED Control button is activated, press to show the OSD Quick Menu. Among the LED Control Button, press to move to the left or right or to move to the bottom or top or to set options.
  • Page 15 [Quick Settings] Press to activate the LED Control Button. When the LED Control Button is activated, press and select [All Settings] to show the complete OSD Menu. Among the LED Control Button, press to move to the left or right or to move to the bottom or top to go to the [Quick Settings].
  • Page 16 [All Settings] > [Quick Explanation Settings] [User Preset] User Preset allows the user to save or load up to 10 picture quality settings for multiple connected devices in each preset. NOTE • You can use User Preset to import or save items in [Picture Adjust] and [Color Adjust] of the [Picture] menu. [User Name] Allows the user to change and register a user name (Preset 1 ~ Preset 3, User 1 ~ User 7) as the user wants.
  • Page 17 [Input] Press to activate the LED Control Button. When the LED Control Button is activated, press and select [All Settings] to show the complete OSD Menu. Among the LED Control Button, press to move to the left or right or to move to the bottom or top to go to the [Input].
  • Page 18 [All Settings] > [Input] Explanation [Aspect Ratio] Adjusts the aspect ratio of the screen. ([Full Wide], [Original], [Just Scan]) NOTE • The display may look the same for [Full Wide], [Original] and [Just Scan] options at the recommended resolution (1920 x 1080). [Main Aspect Ratio] [Full Wide] Displays the image to fit the PBP / PIP screen, regardless of the video signal input.
  • Page 19 [Picture] Press to activate the LED Control Button. When the LED Control Button is activated, press and select [All Settings] to show the complete OSD Menu. Among the LED Control Button, press to move to the left or right or to move to the bottom or top to go to the [Picture].
  • Page 20 Explanation [All Settings] > [Picture] [Brightness] Adjusts screen brightness. [Picture Adjust] NOTE • Press the button to toggle between [Turn on 'Brightness Stabilization']/[Turn off 'Brightness Stabilization']. • When [Brightness Stabilization] is [On], the [Brightness] adjustment function is deactivated. • When [Brightness Stabilization] is [On], [SMART ENERGY SAVING] and [DFC] functions are deactivated. •...
  • Page 21 Explanation [All Settings] > [Picture] [Picture Adjust] [DFC] [On] Automatically adjusts brightness depending on the screen. [Off] Deactivates the [DFC] function. [Response Time] Sets a response time for displayed pictures based on the movement of the picture on the screen. In a normal environment, it is recommended that you set [Fast].
  • Page 22 Explanation [All Settings] > [Picture] [Color Adjust] [Gamma] Set your own gamma value. ([Gamma 1.8], [Gamma 2.0], [Gamma 2.2], [Gamma 2.4], [Gamma 2.6], [DICOM Gamma Curve]) Higher gamma settings mean a darker image is displayed or vice versa. [Color Temp] Set your own color temperature.
  • Page 23 Explanation [All Settings] > [Picture] [Resolution] A user can set the desired resolution. This option is available only when the screen resolution of the computer is set as below (only for the D-SUB). NOTE • When the resolution selected by a user is different from the resolution outputted by the PC per computer, the function will be deactivated. [1024 x 768], [1280 x 768], [1360 x 768], [1366 x 768], [Off] [1280 x 960], [1600 x 900], [Off] [1440 x 900], [1600 x 900], [Off]...
  • Page 24 [General] Press to activate the LED Control Button. When the LED Control Button is activated, press and select [All Settings] to show the complete OSD Menu. Among the LED Control Button, press to move to the left or right or to move to the bottom or top to go to the [General].
  • Page 25 [All Settings] > [General] Explanation [LED Control Button] Adjusts the ON time of the Control Button. ([Always On], [20Sec Time Out], [10Sec Time Out], [5Sec Time Out]) [DVI Power Supply] Supplies power to a device used by connecting to a DVI input terminal in the form of dongle without power. [On] Activates the [DVI Power Supply] function.
  • Page 26 [All Settings] > [General] Explanation [User Preset] User Preset allows the user to save or load up to 10 picture quality settings for multiple connected devices in each preset. NOTE • You can use User Preset to import or save items in [Picture Adjust] and [Color Adjust] of the [Picture] menu. [User Name] Allows the user to change and register a user name (Preset 1 ~ Preset 3, User 1 ~ User 7) as the user wants.
  • Page 27 [All Settings] > [General] Explanation [Auto Screen Off] Automatically turns off the screen when there is no monitor signal for a set time period. [On] Activates [Auto Screen Off] function. [Off] Deactivates [Auto Screen Off] function. A function for restricting menu configuration and adjustment. [OSD Lock] [On] Turns on [OSD Lock].
  • Page 28 [Auto Configuration] Press to activate the LED Control Button. When the LED Control Button is activated, press and select [All Settings] to show the complete OSD Menu. Among the LED Control Button, press to move to the left or right or to move to the bottom or top to go to the [Auto Configuration].

  • Page 29: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. Problem Action Is the monitor's power cord plugged in? • Check if the power cord is correctly plugged into the power outlet. Is the power indicator on? • Check the power cable connection and turn on the power switch. Is the power indicator displaying as green? •...
  • Page 30 The screen is unstable and shakes. / There are shadowy traces left on the screen. Problem Action Did you select the appropriate resolution? • If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the resolution to 1080p or the recommended resolution. The display color is abnormal.

  • Page 31: Product Specifications

    PRODUCT SPECIFICATIONS Specifications are subject to change without notice. The symbol ~ means alternating current, and the symbol means direct current. LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.3114 mm x 0.3114 mm Resolution Max Resolution 1920 x 1080 @ 60 Hz...
  • Page 32 Environmental Conditions Operating Conditions Temperature 0 °C to 40 °C (32 °F to 104 °F) Humidity 0 % to 80 % Pressure 700 hPa to 1060 hPa Storage / Transport Conditions Temperature -20 °C to 60 °C (-4 °F to 140 °F) Humidity 0 % to 85 % Pressure...
  • Page 33 IP35...
  • Page 34 Support Mode (Preset Mode - PC) D-SUB / DVI / HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 720 x 400 31.468 70.08 640 x 480 31.469 59.94 640 x 480 37.5 720 x 480 31.47 59.94 HDMI only 800 x 600 37.879...
  • Page 35 Support Mode (Video) Vertical dimensions Vertical Frequency (Hz) HDMI Remarks 480i 59.94/60 480p 59.94/60 576p 576i 720p 59.94/60 720p 1080i 59.94/60 1080p 59.94/60 1080i 1080p 1080p 29.97/30...
  • Page 36 Support Mode (Component) NOTE • Vertical Frequency: In order to display an image, the screen must be refreshed dozens of times per second, like a fluorescent lamp. The number of times the screen is refreshed per second is called vertical frequency, or Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
  • Page 37 Power indicator Mode LED Color On Mode Green...

  • Page 38: External Controller Setup

    EXTERNAL CONTROLLER SETUP Set ID Function This function allows you to assign a unique ID to the monitor to control it remotely from your PC. The actual product may differ from the picture shown. Please refer to the "Transmission/Reception Protocol". Connect the RS-232C (serial connector) of the PC to the RS-232C IN connector at the back of the monitor.
  • Page 39 Command Reference List Data Command Command1 Command2 (Hexadecimal) 21. [Gamma] 00 ~ 05 Data Command Command1 Command2 22. [Color Temp] 00 ~ 04 (Hexadecimal) 23. [Red] 00 ~ 64 01. Power 00 ~ 01 24. [Green] 00 ~ 64 02. Screen Mute 00 ~ 01 25.
  • Page 40 Transmission/Reception Protocol Error Acknowledgment (Command2)( )(Set ID)( )(NG)(Data)(x) Transmission When the set receives an abnormal piece of Data for an unsupported function or there is a communication error, (Command1)(Command2)( )(Set ID)( )(Data)(Cr) it returns ACK in the format above. (Command 1): j, k, m, x, d Data 00: Illegal code (Command 2): This command is used to control the monitor.

  • Page 41: Power

    01. Power (Command: k a) 04. Input select (Sub) (Command: k y) ʢ Controls the On/Off of the power supply to the monitor. ʢ Controls the input mode of the Sub. Transmission (k)(a)( )(Set ID)( )(Data)(Cr) Transmission (k)(y)( )(Set ID)( )(Data)(Cr) Data Data 00: Power Off...

  • Page 42: Aspect Ratio] (Sub) K O 00

    06. [Aspect Ratio] (Sub) (Command: k o) 09. [Main/Sub Screen Change] (Command: m a) ʢ Adjusts the Aspect Ratio of the Sub. ʢ Controls the Swap in the PBP mode. Transmission (k)(o)( )(Set ID)( )(Data)(Cr) Transmission (m)(a)( )(Set ID)( )(Data)(Cr) Data Data 00: [Full Wide]...

  • Page 43: Brightness Stabilization]

    12. [Contrast] (Command: k g) 15. [SUPER RESOLUTION+] (Command: m c) ʢ Adjusts the color contrast of the screen. ʢ Controls the SUPER RESOLUTION+ function. Transmission (k)(g)( )(Set ID)( )(Data)(Cr) Transmission (m)(c)( )(Set ID)( )(Data)(Cr) Data Data Min: 00 - Max: 64 00: [High] 01: [Middle] 02: [Low]...
  • Page 44 18. [Response Time] (Command: m g) 21. [Gamma] (Command: m j) ʢ Controls the Response Time. ʢ Adjusts the Gamma settings. Transmission (m)(g)( )(Set ID)( )(Data)(Cr) Transmission (m)(j)( )(Set ID)( )(Data)(Cr) Data Data 00: [Faster] 01: [Fast] 00: [Gamma 1.8] 01: [Gamma 2.0] 02: [Normal] 03: [Off]...

  • Page 45: Smart Energy Saving]

    24. [Green] (Command: j y) 27. [SMART ENERGY SAVING] (Command: m k) ʢ Adjusts the green. ʢ Adjusts the SMART ENERGY SAVING. Transmission (j)(y)( )(Set ID)( )(Data)(Cr) Transmission (m)(k)( )(Set ID)( )(Data)(Cr) Data Data Min: 00 - Max: 64 00: [High] 01: [Low] 02: [Off] Ack (y)( )(Set ID)( )(OK/NG)(Data)(x)

  • Page 46: Auto Screen Off] M N 00

    30. [Auto Screen Off] (Command: m n) 33. [Auto Configuration] (Command: j u) ʢ Adjusts the time to automatically turn the screen off when there is no monitor signal for a set period of ʢ Performs the Auto Configuration. time. Transmission (j)(u)( )(Set ID)( )(Data)(Cr) Transmission (m)(n)( )(Set ID)( )(Data)(Cr) Data...

  • Page 47: Failover Input Switch]

    34. [Failover Input Switch] (Command: k z) 36. [Failover Input] (Command: k w) ʢ Controls the Failover Input Switch function. ʢ Controls the input of the Failover. Transmission (k)(z)( )(Set ID)( )(Data)(Cr) Transmission (k)(w)( )(Set ID)( )(Data)(Cr) Data Data 00: [Off] 01: [On] 00: SDI 01: DVI-D...
  • Page 48 Trade Name The model and serial number of the product are located on the back and on one side of the product. Responsible Party LG Electronics USA, Inc. Record them below in case you ever need service. Address 111 Sylvan Avenue, North Building, Englewood...
