Lager Trolley

Assembly manual

Table of Contents

Need help?

Do you have a question about the Lager Trolley and is the answer not in the manual?

Page 1 Lager Trolley Assembly manual...
Page 3: General Instructions
General Instructions PLEASE READ BEFORE INSTALLATION WARNING: The safety of this fitting can only be guaranteed if the following instructions are observed during both installation and use. Please retain these instructions safely after installation. PLEASE OBSERVE THE FOLLOWING GUIDELINES: – Ensure that all screws are firmly tightened before using the couch. MORE INFORMATION: To access further information such as product overview and material descriptions, please visit our website at www.fermliving.com.
Page 4: Box Content
Box Content 18 x Washer 18 x Bolt 1 x Bottom tray 1 x Top tray 18 x Screw 1 x Allen Key 1 x Side panel (B) 1 x Side panel (C) 1 x Side panel (A)
Page 5: Assembly Process
Assembly Process Assembly applies to all screws! Place the top tray on its side on a soft surface on the floor. Fit the side panel (A) with 3 screws, washers and bolts as shown. Use the Allen key and tighten with a spanner...
Page 6 Assembly Process Mount the bottom tray with 3 screws, washers and bolts. (Follow step 1 for screw assembly)
Page 7 Assembly Process Mount the side panel (B) with 6 screws, washers and bolts. (Follow step 1 for screw assembly)
Page 8 Assembly Process Mount the side panel (C) with 6 screws, washers and bolts. Tilt (Follow step 1 for screw assembly)
Page 9 Assembly Process TWO PERSON LIFT REQUIRED Tilt the trolley up. Requires two people...
