- Page 1 Ver. 1.0 XNET (IJB2000) Installation Manual...
- Page 2 Important Notices The copyright of this manual is owned by CNB Technology Inc. It is illegal to copy and distribute this manual without permission. Damages caused by use of not suggested parts and misuse will not be applicable for support.
-
Page 3: Table Of Contents
Network Video Server Installation Manual Index 1. About XNET ..............................4 1.1. About XNET ............................4 1.2. Features of XNET ..........................4 1.3. Applications ............................4 2. About the Product ..........................5 2.1. Contents ............................... 5 2.2 Product Information ..........................5 2.3. -
Page 4: About Xnet
XNET Network Video Server Installation Manual 1. About XNET XNET is an internet based security and surveillance system that is compatible with various network conditions through easy installation and user interface as well as multi-functional compressor Codec such as MJPEG, MPEG-4, and H.264. -
Page 5: About The Product
XNET Network Video Server Installation Manual 2. About the Product Please make sure the following contents are included when you open the package Contents Description Additional info. XNET Product Network Video Server Input: 100~240VAC 50-60Hz Power adapter Output : 12VDC, 5A AC power Cord 3 jack cable Software and User’s manual... -
Page 6: Functions And Designations
XNET Network Video Server Installation Manual Cover Screw Camera Cable Feed In Power/Video/ Control Camera Mount Hole Cable Feed In Network/Power/Alarm/Audio Figure 2-1. IJB2000 Outer Audio Input/ Output Connection Terminal to Camera Alarm Input/ Output Restart Button Restarts the network Server. Status LED Network Terminal Factory Reset Button... - Page 7 XNET Network Video Server Installation Manual Video In Control RS485+ Control RS485- +12VDC Audio In(Mic/Line) Audio GND Audio Out (Line) Audio GND Alarm Sensor In + Alarm Sensor In - Alarm Out Alarm Out +12Vdc Figure 2-3. Connection Terminal Block MIC/LINE IN : Connects to auxiliary Audio Device or microphone.
-
Page 8: Connecting To Alarm Devices
XNET Network Video Server Installation Manual Power INPUT: Connect 12V DC Power to this terminal. Please use the power adapter came in the package. STATUS LED : Indicates the operation status - CPU LED : Green light will blink after 50 seconds on power. - Video Loss LED : Red light indicates that there is no Video Input signal. -
Page 9: Product Installation
XNET Network Video Server Installation Manual 3. Product Installation This section provides brief guidelines to install the XNET quickly and to monitor XNET’s Video and Audio signals easily. If you have questions about details not explained in this section or if the product is not functioning as described, please refer to FAQ before contacting the store. -
Page 10: Connecting The Cable
Connect the wires according to the detail shown in the table below. (Cut wires if necessary.) YELLOW BLACK GREEN BROWN ORANGE This Junction box is designed to be used with specific cameras. Please contact CNB dealer to ask about purchasing 10 / 18... - Page 11 XNET Network Video Server Installation Manual A PC or a laptop computer is required to set up an IP address. Compatible operating system: Windows 2000/ Windows XP/ Windows Vista Since the default IP address of the device is 192.168.123.100, set up the IP address of the computer like the following: IP Address : 192.168.123.101 Subnet Mask : 255.255.255.0 Connect LAN cable to the Network Terminal of the product.( Use a crossover cable when...
-
Page 12: Installing Ip-Installer Software And Configuring Ip Address
XNET Network Video Server Installation Manual A unique IP address has to be configured in order to connect network device and monitoring PC to a network. IP-Installer software provided in the Installation CD (included in the package and also available to download from our website http://www.cnbtec.com) will configure IP address easily. - Page 13 XNET Network Video Server Installation Manual 2. Select the device of which you wish to change the IP address and click (Set IP Address) button to bring up the following box in Figure 3-3. Figure 3-3. IP Address box 3. When you enter the IP address and click Set button, the box shown in Figure 3-4 will appear. Figure 3-4.
-
Page 14: Using Web Viewer
XNET Network Video Server Installation Manual 4. Using Web Viewer Connecting to network devices can be done using internet web browser or “XNET-CMS” software. This manual explains about using internet web browser only. For instructions on how to configure network connection using XNET-CMS software, please refer to XNET-CMS Manual, which can be found in the installation CD. - Page 15 XNET Network Video Server Installation Manual Web viewer page consists of Video monitor screen and menu option buttons. Figure 4-2. Web Viewer Page 15 / 18...
- Page 16 XNET Network Video Server Installation Manual Item Sub Item Description Captures and saves the current image as a still picture. Capture The image is saved as jpeg file in the following folder: C:₩xNetCapture Brings up Menu screen. Setup page for each XNET feature can be opened from this Menu screen. Setting Please refer to [XNET Owner’s Manual] for detail.
-
Page 17: Specifications
Local storage (Internal memory : JPEG image) Browser Internet Explorer 6.0 over Applications Monitoring Application XNET NVR, CNB CMS and Utility (IP-Installer, etc), 3rd party SW System Upgrade Firmware upgrade over HTTP Maintenance PTZ control (RS-485) PTZ Protocol Service (User define update) Operating Temperature -10℃... - Page 18 XNET Network Video Server Installation Manual 18 / 18...
