- Page 1 Digital/Network Video Recorder Quick Start Guide...
- Page 2 Digital Video Recorder Quick Start Guide Quick Start Guide COPYRIGHT © 2017 Hangzhou Hikvision Digital Technology Co., Ltd. ALL RIGHTS RESERVED. Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 Digital Video Recorder Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 4 Digital Video Recorder Quick Start Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
-
Page 5: Chapter 1 Rear Panel Interfaces Description
Digital Video Recorder Quick Start Guide Chapter 1 Rear Panel Interfaces Description The rear panel interfaces vary with different models. Refer to Table 1-1 for the common interfaces description of rear panels. Table 1-1 Common Interfaces Description of Rear Panels Item Description Item... -
Page 6: Chapter 2 Installation And Connections
Digital Video Recorder Quick Start Guide Chapter 2 Installation and Connections 2.1 Installation During installation of the DVR/NVR: Use brackets for rack mounting. Ensure ample room for audio and video cables. When routing cables, ensure that the bend radius of the cables are no less than five times than its diameter. -
Page 7: Chapter 3 Menu Operation
Digital Video Recorder Quick Start Guide Chapter 3 Menu Operation 3.1 Startup Proper startup is crucial to expanding the life of the DVR/NVR. Step 1 Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an Uninterruptible Power Supply (UPS) be used in conjunction with the device. -
Page 8: Using The Unlock Pattern For Login
Digital Video Recorder Quick Start Guide 3.3 Using the Unlock Pattern for Login Purpose For the Admin user, you can configure the unlock pattern for device login. After the device is activated, you can configure the device unlock pattern. Step 1 Use the mouse to draw a pattern among the 9 dots on the screen. - Page 9 Digital Video Recorder Quick Start Guide 3.5 User Logout, Shutdown and Reboot Purpose You can log out of the system, shut down, or reboot the device on your demands. Step 1 Go to Menu > Shutdown. Step 2 Click Logout, Shutdown, or Reboot. After you have logged out of the system, menu operation on the screen is invalid.
-
Page 10: Network Settings
Digital Video Recorder Quick Start Guide 3.7 Adding IP Cameras(NVR) Purpose Before you can get live video or record the video files, you should add the network cameras to the connection list of the device. Before you start Ensure the network connection is valid and correct, and the IP camera to add has already been activated. Please refer to the User Manual for activating the inactive IP camera. - Page 11 Digital Video Recorder Quick Start Guide The HiLookVision can be enabled via operation on SADP software, GUI and Web browser. We introduce the operation steps on GUI in this section. Step 1 Go to Menu > Configuration > Network > Platform Access.
-
Page 12: Recording Settings
Digital Video Recorder Quick Start Guide In the live view mode, there are icons at the upper-right corner of the screen for each channel, showing the status of the record and alarm in the channel for quick reference. Alarm (video loss, tampering, motion detection, VCA or sensor alarm) Record (manual record, continuous record, motion detection, VCA or alarm triggered record) Alarm and Record Event/Exception (event and exception information, appears at the lower-left corner of the screen.) - Page 13 Digital Video Recorder Quick Start Guide 3.11 Playback Purpose The recorded video files and pictures on the hard disk can be played back in the following modes: instant playback, all-day playback for the specified channel, and playback by normal/event/smart/tag/system logs/sub-periods/external file search/picture. Step 1 Go to Menu >...
-
Page 14: Chapter 4 Accessing By Web Browser
Digital Video Recorder Quick Start Guide Chapter 4 Accessing by Web Browser You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center. - Page 15 Digital Video Recorder Quick Start Guide Use only power supplies listed in the user instructions. Adapter: NVR-104-B/4P, NVR-104-B/4P/M,NVR-104-B, NVR-104-B/M, NVR-108-B, NVR-108-B/M, NVR-108-B/8P, NVR-108-B/8P/M MSA-C1500IC12.0-18P-D, MSP-Z1360IC48.0-65W , MOSO Adapter: NVR-104MH-C/4P MSP-Z1360IC48.0-65W , MOSO Adapter: NVR-108MH-C/8P 2AAL090R , CHANNEL WELL TECHNOLOGY CO.,LTD. Adapter: NVR-104MH-C, NVR-108MH-C, NVR-116MH-C EU：...
- Page 16 Digital Video Recorder Quick Start Guide UD10852B...
