Summary of Contents for TCL BOOK 14 Go
-
Page 3: Table Of Contents
Table of Contents Your device ..............4 Front view ............4 Bottom view ............6 Left-side view ............ 7 Right-side view ..........8 Getting started ............10 Power your laptop with power adapter ..10 Power on your laptop ........10 Configuring the operating system .....10 Power off your laptop .......... -
Page 4: Your Device
Your device 1.1 Front view... - Page 5 Camera indicator light Indicator will turn white when the camera is active. Camera High definition camera, supports 720p video. Digital Microphones Dual built-in microphones LCD Screen Internal display/panel Fn indicator light Caps Lock indicator light Power indicator light Keyboard Fully QWERTY keyboard Touchpad The touchpad functions as a conventional mouse.
-
Page 6: Bottom View
Right-click area: Clicking in this area corresponds to the functions of clicking the right button on a conventional mouse. Power Button If the your laptop is powered off or in sleep mode, press once to power on. If the laptop is powered on, press once to enter sleep mode. -
Page 7: Left-Side View
1.3 Left-side view A USB Type-A Port Connect any USB devices into this port such as a USB flash drive, keyboard, or mouse. B USB Type-C Port For charging, data transmission or DisplayPort output. C Charging indicator light When you connect the power adapter to your laptop to charge the battery, the indicator light will be on. -
Page 8: Right-Side View
1.4 Right-side view A Headphone Jack Connect amplified speakers or headphones into this jack. B USB Type-C Port For charging or data transmission. C SIM and microSD tray Insert your Nano SIM or microSD card (up to 1TB) here. -
Page 9: Getting Started
Getting started 2.1 Power your laptop with power adapter Insert one end of the charging cable into the Power Connector Type-C port, and the other end of the charging cable into power adapter, then plug Power adapter into a power outlet. 2.2 Power on your laptop Press the Power button to start your laptop until the Power indicator is on. - Page 10 • Enter your account name and password and then click Sign in, Create your account if have no Microsoft account. • Set a PIN and confirm it. When your account cannot be identified by the laptop, try using the PIN to unlock your device.
-
Page 11: Power Off Your Laptop
Power off your laptop To prevent hardware/software system from damage, do not arbitrarily use the power button to shut down the laptop Instead, shut down the laptop as follows. 1. Click Start → Power → Shut down. 2. Wait for the laptop to shut down and then close the display panel. - Page 12 Choose Start > System > Power & battery, click Screen and sleep and set a sleep timer. To wake up your laptop, do one of the following: • If the display panel is closed, simply open it to wake up your laptop. • If the display is already open, press the power button or any key on the keyboard.
-
Page 13: Home Screen
Home screen You can customize your desktop. Choose Start > Settings > System from the menu bar. Windows Search Type what you are looking for in the search bar to get search results from your laptop or the web. Multiple-window view Touch to display all open windows and you can toggle between them. - Page 14 Touch to quick acess files and folder stored on your laptop. Build-in Browser Touch to surf on the internet. Start Touch to start working with your laptop, your laptop comes with software applications for sending email, surfing the Internet, and chatting online. It also includes the Microsoft Office software such as Word, Excel, Powerpoint to get your work done easily.
-
Page 15: Using The Touchpad
4.1 Using the Touchpad Use the touchpad to move the pointer and to perform a variety of Multi-Touch gestures. Frequently used gestures on touchpad: • Click anywhere on the touchpad with one finger to perform an action, such as starting an app, opening a link, or performing a command. - Page 16 The following touchpad gestures work in certain applications. When you perform these gestures, slide your fingers lightly on the surface of the touchpad. • Two-finger pinching lets you zoom in or out on PDFs, images, photos, and more. • Move items to other location. select an app with one finger, press and hold down the Left-click area with the other finger, and then drag the app to the desired location.
-
Page 17: Settings
Settings ........5.1 Connect to Wi-Fi Networks You can connect to the internet when your laptop is within range of a wireless network. To turn Wi-Fi on and connect to a wireless network • Touch Start > Settings > Network & internet > Wi-Fi. -
Page 18: Bluetooth
• Enter the name of the network and any required network information. • Touch Save. To forget a Wi-Fi network The following steps prevent automatic connections to networks which you no longer wish to use. • Turn on Wi-Fi, if it’s not already on. • On the Wi-Fi screen, touch Manage known networks. - Page 19 To pair/connect your laptop with a Bluetooth device To exchange data with another device, you need to turn Bluetooth on and pair your laptop with the Bluetooth device with which you want to exchange data. • Choose Start > Settings > Bluetooth & devices. • Choose Add device >...
-
Page 20: Windows Upgrade
Windows Upgrade .... You can connect to the Internet and download and install the latest free software versions, drivers, and other enhancements. When you’re connected to the Internet, Software Update checks to see if any updates are available. Choose Start >... -
Page 21: Troubleshooting
Troubleshooting ....Before contacting the service center, here are some instructions to help you troubleshoot your device: • For optimal operation, fully charge the battery. • To improve the laptop’s performance, remove unnecessary files or apps on your laptop. • Update your laptop's software via the Updates application. - Page 22 2. The laptop is not responding • Hold down the power button for 8 seconds or longer. If the laptop is still not responding, unplug the power adapter. • Laptop may be locked when they go into sleep mode during communication operations. When working online, disable the sleep timer.
- Page 23 • If the laptop is in sleep mode, connect the power adapter to the laptop and press the power button. • If the system still does not return from sleep mode and the laptop is unresponsive, or you cannot shut down the laptop, Please restart the laptop.
- Page 24 • Do not connect or disconnect the cables of non-USB ports when the device is powered on. Otherwise, the laptop may be damaged. • When using external devices with high power consumption such as USB OPTICAL disk drives, please use the power adapter of external devices. Otherwise, the device may not be recognized or the system may shut down.
-
Page 25: Specifications
Specifications ...... Chipset : Snapdragon 7C Gen 1 (SC7180) Platform : Windows 11 Home Memory : 4GB RAM + 128GB ROM Dimensions (LxWxT) : 323.7*214.5*13.95mm Weight : 1280g Display : 1366*768 Network : 3G Network: B1/3/5/8 4G Network: B1/3/5/7/8/20/28/38/39/40/41 (Band frequency and data speed are operator dependent.) GPS : Connectivity :... - Page 26 TCL Communication Ltd. shall not be held legally responsible for such differences, if any, nor for their potential consequences, which responsibility shall be borne by the carrier exclusively.
