DIGITIZE Desplex 32 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Digitize, Inc
158 Edison Road
Lake Hopatcong, NJ 07849
Tel: (973) 663-1011
Fax: (973) 663-4333
http://www.digitize-inc.com
UM-32
User Manual
Desplex Series 32 (v3.0A)
TM5-32 Transmission Module
TM5-10 Receiver Module
RP-10 Remote Panel
August 2002
And
Part Number: 700815-0001
Issue Revision: A
Issue Date: 08/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Desplex 32 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DIGITIZE Desplex 32 Series

Summary of Contents for DIGITIZE Desplex 32 Series

  • Page 1 UM-32 User Manual Desplex Series 32 (v3.0A) TM5-32 Transmission Module TM5-10 Receiver Module RP-10 Remote Panel August 2002 Digitize, Inc 158 Edison Road Lake Hopatcong, NJ 07849 Tel: (973) 663-1011 Part Number: 700815-0001 Fax: (973) 663-4333 Issue Revision: A http://www.digitize-inc.com...
  • Page 3 Standards). The DES algorithm is in the public domain, and the security of its use is dependent in the secrecy of the DES key variable used. While the Digitize, Inc. DEPLEX line of security products provide easy and flexible key management, the user is totally responsible for implementing a secure DES key variable management scheme.
  • Page 5 GLOSSARY' The following terms shall be used In describing the components to be Installed throughout this manual. Figure 1 Illustrate* how the various components fit together to form a complete, alarm monitoring system. Control Unit - Secured area housing containing circuit card, transmission modules, standby battery and keyswitch or keypad arming / disarming control.

  • Page 9: Table Of Contents

    TABLE OF CONTENTS SECTION TITLE PAGE INTRODUCTION ASSUMPTIONS PIN DEFINITION KEYPAD FUNCTIONALITY KEYPAD SIGNON DURESS PIN ENTRY COMMAND ENTRY PROCEDURE & SUMMARY SECURE (ARMING SYSTEM) MODE CHANGE ACCESS (DISARMING SYSTEM) MODE CHANGE INSPECT ALARM LOOPS/POINT & POWER STATUS NOT DEFINED SETUP DELAY TIMER SHUNTING SECURED AREA ALARM LOOP CANCEL PIN...
  • Page 11 TABLE OF CONTENTS CON’T SECTION TITLE PAGE APPENDIX A RECEIVER MODULE (MP5-10)/REMOTE PANEL (RP5-10) OPERATIONAL SUMMARY APPENDIX B TRANSMISSION MODULE (TM5-10) OPERATIONAL SUMMARY APPENDIX C FACILITY (SITE) CODE MANUAL SETUP APPENDIX D SECURED AREA (TRANSMISSION MODULE) EVENT LOGGING OPTION APPENDIX E FIRST USAGE AFTER INSTALLATION APPENDIX F NOT DEFINED...

  • Page 13: Introduction

    Section 1.0 Introduction The operation of the Digitize, Inc high security DESPLEX 32 Series alarm monitoring equipment is relatively easy and straightforward. The actual day-to-day operation usually requires simple arming/disarming of the system via a PIN based keypad/LCD display (KEYPAD) in the secured area, and monitoring of the arming/disarming at the central monitoring facility.

  • Page 14: Assumptions

    PIN storage operations. As shipped from the factory, or as a result of the full erasure or “purge” of the PIN/DES key memory (Section 3.1) the only PIN that will operate AT THAT point is PIN #01 (MASTER). It is setup as all zeros (i.e., 0,0,0,0,0). Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 15 Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 16: Keypad Functionality

    ASSUMES the ID #70 PIN has been previously defined (see Section 2.9). NOTE: The transmission module will NOT send a specific DURESS message to the local printer, but if the printer is setup to run continuously, “KEYPAD 70” message WILL sent printer. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 17: Command Entry Procedure & Summary

    8. Enter a VALID 2 character command followed by a “*” (SELECT key). The LCD bottom line will respond with an appropriate command feedback display if the 2 character command was VALID, and will respond with the following if the command was invalid: REQUEST NOK Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 18 This will assure the time between keypad keystrokes (see Section 1.4) is not so great as to cause the keypad to return to the idle state because greater than 10 seconds elapsed between keystrokes. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 19: Secure (Arming System) Mode Change

    6. Press the “#” (Enter) key, and the LCD bottom line will display the following if no alarm loops are SHUNTED: DIG DESPLEX The LCD bottom line will display the following PULSATING LINE: ************** If the following condition exists: Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 20 ACCESS/SECURABLE SECURE ALARM annunciation (see APPENDIX A) that will override the MODE CHANGE ALARM. When the alarm device “clears” the RECEIVER MODULE will then annunciate a SECURED NON-ALARM state upon MODULE reset (push-button as SCT control). Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 21: Access (Disarming System) Mode Change

    NOTE: The “SECURE OK” message is a result of the printer not printing the previous mode change to SECURE because printing can not occur while the SECURED AREA is in SECURE (i.e., ONLY in ACCESS). Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 22 The above would appear on the local printer as follows: 04/04/94 15:26:29 ttttttttALARM Zone xxLyPx Where Ly is the loop #1 (1-8) & are the point # (s) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 23 8. The RECEIVER MODULE will respond with an ACCESS MODE change ALARM as follows: AUDIBLE goes ON SECURE LED remain SOLID GREEN ACCESS LED go to BLINKING YELLOW ALARM LED go to BLINKING RED COMM STATUS LED remains UNCHANGED Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 24 FIGURE 1.1 Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 25: Inspect Alarm Loops/Point & Power Status

    T= loop is defined as a SECURED 24 hours TAMPER loop S = loop is defined as ACCESS/SECURABLE presently SHUNTED D = loop is defined as ACCESS/SECURABLE with a DELAY timer, either 2 man reset or entry/exit Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 26 A = point is OPEN (i.e., in an alarm state if the LOOP was switched from ACCESS to L SECURE) Blank = point is NOT defined via the ALARM POINT DEFINITION (see Section 2.17). Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 27 11. DES Encryption key signature designator (“KY”). 12. DES Encryption key signature used to determine if a communications problem is related to a problem with an encryption key at this, or any other CU5-32 configured with an accompanying RECEIVER module. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 28: Not Defined

    Both Entry and Exit DELAY time setup involves setting up the delay time for a value representing a delay of from 4-63 seconds, accurate to about +/- 3 seconds. The delay time can be entered while the SECURE AREA is in ACCESS as follows: Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 29 2 man rule for resetting an alarm on the loop specified. The delay is defined as an EXIT delay for the 2 man reset function: 8. Press the “#” (ENTER) key, and the LCD bottom line will display: REQUEST YY Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 30 Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 31: Shunting Secured Area Alarm Loop

    2. Enter the 5 digit PIN associated with the ID#73. The LCD bottom line will display the following as the digits are entered: PIN = X {up to 5 “X”} 3. If the PIN is VALID, the LCD bottom line will display the following after the 5 PIN digit is entered: Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 32 SECURE to ACCESS. Also, when the transmission module is in ACCESS and a request to shunt loop is performed, the receiver module SECURE LED and audible will pulsate for about 3 seconds. Also, when the SECURED AREA is in SECURE and a loop was setup SHUNTED (while previously in Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 33: Cancel Pin

    6. Press the “#” (ENTER) key, and the LCD bottom line will MOMENTARILY display: REQUEST The LCD bottom line will then change the display (“XX” is the ID# entered in Step 5): CANCEL ID#XX Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 34: List Pin Status

    3. If the PIN is VALID, the LCD bottom line will display the following after the 5 PIN digit is entered. REQUEST The local printer will respond with: 04/04/94 13:45:01 KEYPAD ID #01 Zone xx 4. Enter the following 3 characters: L, P, * The LCD bottom line will display: Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 35: Define And Store Pin

    1. Enter a 2 digit MASTER ID# (01-74). The LCD bottom line will display the following as the digits are entered: ID#X {up to 2 “X”} 2. Enter the 5 digit PIN associated with the ID#. The LCD bottom line will display the following as the digits are entered: Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 36 9. Press the “#” (ENTER) key. The transmission module will then store the data just entered and the PIN is now available for use. The local printer will respond with: ???? {DATE/TIME} REQUEST ID# Zone xx 10. The LCD bottom line will display: MASTER ID#XX LIMITED ID#XX TEST ID# XX Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 37: Alarm Loop Definition On Powerup

    3. If the PIN is VALID, the LCD bottom line will display the following after the 5 PIN digit is entered: REQUEST The local printer will respond with: 04/04/94 13:45:01 KEYPAD ID#01 Zone xx Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 38 NOTE: Just after the “#” is pushed, the transmission module to receiver module communications will momentarily re-synchronize. The effect observed will be the COMM STATUS LED on the receiver module will flicker for about a second. NO ACTION is required by operator. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 39: Setup Secured Area Date-Time

    Enter a 2 digit hour (00-23) Enter a 2 digit minute (00-59) Enter a 2 digit second (00-59) Press the “#” (ENTER) key The local printer will respond with: {DATE/TIME} DTG = MMDDYYHHMMSS Zone xx Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 40: Secured Area Reprot Generation

    The procedure for getting a report to the printer is as follows: 1. Enter a 2 digit MASTER ID# (01-74). The LCD bottom line will display the following as the digits are entered. ID#X {up to 2 “X”} Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 41 USER ID#. Specifically, after the “LK” is entered, enter a 2 digit (01-74) USER ID# TWICE (i.e., 0101 for user ID# 01) & then go to Step 6. MODE change events POWER change (AC or DC) events TAMPER ALARM events Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 42 Re-enter a report generation request with the TYPE OF EVENT (Step 4 above) being the “LO (digit 0)” type with the MONTH = 13, and the DAY = 32. The printing will stop after the next printable line has been printed. 10. The printer will then print the specified report. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 43 3. If the PIN is VALID, the LCD bottom line will display the following after the 5 PIN digit is entered: REQUEST The local printer will respond with: 04/04/94 13:45:01 KEYPAD ID#01 Zone xx 4. Enter the following 3 characters: W,T,* The LCD bottom line will display: REQUEST TEXT Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 44 NOTE: Just after the “#” is pushed, the transmission module to receiver module communications will momentarily re-synchronize. The effect observed will be the COMM STATUS LED on the receiver module will flicker for about a second. NO ACTION is required by the operator. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 45 TEXT 2 DIGIT TEXT 2 DIGIT CHAR CODE CHAR CODE “ & ‘ < > bell Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 46: Event Logging Memory Shutdown Prior To Powerdown

    5. Press the “#” (ENTER) key and the local printer will respond with: ************ The 30-second time-out starts now. 6. The LCD bottom line will display: DIG DESPLEX 7. The RECEIVER MODULE will NOT respond. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 47: Not Defined

    2-5 to change mode, then the “TM5#1” flag for TRANSMISSION MODULE numbers 2-5 must be SET = 1 and the 8 flag sequence would be defined as follows for TRANSMISSION MODULE numbers 2, 3, 4 & 5. Flag Data Flag Defined TM5#5 TM5#4 TM5#3 TM5#2 TM5#1 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 48 5. Enter the 8 digit flag sequence described above for the desired multi TRANSMISSION MODULE mode changing for TRANSMISSION MODULE numbers 1-5. 6. Press the “#” (ENTER) key. The TRANSMISSION MODULE will then store the enabling flags and the LCD bottom line will display. REQUEST YY Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 49 TRANSMISSION MODULE numbers 1-5. Specifically, instead of the TRANSMISSION MODULE #1-5 enabling flags, the following flags for TRANSMISSION MODULE numbers 6-10 are used. ORDER OF SETUP OF MULTI TRANSMISSION MODULE MODE CHANGING FLAGS DEFINITION OF FLAGS TM5#10 TM5#9 TM5#8 TM5#7 TM5#6 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 50 7. The local printer will respond with: ???? {Date/Time} REQUEST YY ZONE XX Where “YY” is the same HEX value display on the LCD bottom line in Step 6. 8. The LCD bottom line will display: DIGITIZE DESPLEX Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 51: Or Central Station Mode Control Enable

    TM5#10 TM5#9 TM5#8 TM5#7 TM5#6 The first & second group of flags for TM5#3 is as follows: Flag Group Flag Defined TM5#5 TM5#4 TM5#3 TM5#2 TM5#1 Flag Data Flag Defined TM5#10 TM5#9 TM5#8 TM5#7 TM5#6 Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 52: Alarm Point Definition On Powerup

    (“0” defines the point for this loop as “DISABLED” AND “1” defines the point as ACTIVE/ENABLED): ORDERS OF 0/1 FLAGS ENTERED ALARM POINTS (P1-P4) PER CHOSEN LOOP DEFINED NOTE: The 1 flags must always be “0” because only 4 points/loops can be defined. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 53: (Off-Line) Users Definable Options

    NOTE: These procedures bring the system OFF-LINE. The transmission module keypad and local printer, and, the receiver module front panel LED’s and receiver rack audible are irrelevant during the PURGE procedures. Therefore, these peripheral devices and indicators should be ignored during the PURGE procedure. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 54: 3.1.1 Purge Transmission Module Procedure

    10. Setup the DIP SWITCHES as recorded in Step 1. 11. Remove the DES KEY/PURGE JUMPER and store it on 1 of 2 J1 connector posts. 12. Re-Connect the local printer cable and keypad cable (Figures 1, 1.0 and D.O) Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 55: Purge Receiver Module Panel

    The following procedure assumes the receiver module/remote panel is properly installed in receiver racks and the receiver racks are appropriately powered up. Also, a Digitize ED20 extender board (Figure 1, 3.1) must be used to allow access to the receiver module/remote panel DIP switches while the module is powered up in the receiver rack.
  • Page 56 14. Insert the receiver module/remote panel into the receiver rack (see Figure 1). The receiver module is in an ON-LINE state. NOTE: At this point the receiver module will probably NOT be communicating with the transmission modules and remote panels unless ALL had previously been purged. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 57 FIGURE 3.1 RECEIVER/TRANSMISSION MODULE AUTOMATED DES KEY SETUP Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 58: Des Key Generation

    4096 transactions/events for report generation to the local printer upon request by the keypad. If it is required to PURGE (erase entirely) this memory, the system is brought OFF-LINE and the memory is PURGED as described. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 59: 3.4.1 Purge Transmission Module Transaction Buffer

    1 2 3 4 5 6 7 8 6. Insert the transmission module TB1 barrier strip first section into the CU5-32 as shown in Figure 1.0. 7. The STATUS INDICATOR LED should be pulsating RED & GREEN. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 60: Receiver Module Dip Switch Options

    PANEL and the switches are shown as follows): 2 3 4 5 6 7 NOTE: For RP5-10 REMOTE PANELS, only DIP switch #1, 2, 6-8 positions are defined, and positions 3-5 should always be in the ON position. Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 61: Transmission Module Dip Switch Options

    The lever DIP switches should be configured according to system requirements as follows (Figure 1.0 shows the locations of DIP switches on the TRANSMISSION MODULE and the switches are shown below): 1 2 3 4 5 6 7 8 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 62 Multi TRANSMISSION MODULE mode changing setup (see UM-32, Section 2.16) disabled. 4 OFF (Open) Multi TRANSMISSIN MODULE mode changing setup (see UM-32, Section 2.16) enabled RECEIVER MODULE to TRANSMISSION MODULE addressing (see APPENDIX “G”). Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 63: Periodic Maintenance

    Therefore, the TRANSMISSION MODULE should be brought ON-LINE with the RECEIVER MODULE such that total OFF-LINE time is NOT greater than the time it takes to accumulate an overflow buffer condition at the TRANSMISSION MODULE. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 64 The following procedure should be performed on at least a semi-annual basis. DES ENCRYPTION KEY CHANGE The procedure for updating the DES key for the receiver module, remote panel and TRANSMISSION/RECEIVER MODULES is described in Section 3.2. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 65 NOTE: If the LED is a steady GREEN WITHOUT any flickering at all, the RECEIVER MODULE may be locked up and the TROUBLESHOOTING section (2.0) of the IM-32 should be referred to for assistance. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 66 This state is NOT defined at this time. g. FLICKERING RED/GREEN As mentioned, this indicates the Receiver Module to Transmission Module communications are in the process of synchronization at the time the LED FLICKERING is occurring. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 67 SEL function can also be more easily done via the SCT I or IIe terminal option at the receiver rack. The SEL functions would typically be used by service and maintenance personnel where the receiver rack may/may not be configured with an SCT I or IIe. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 68 REPEAT the 8 pulsations sequence as long as the DATA pushbutton switch is held down. 5. To exit the examine data state, just release the DATA pushbutton and the RECEIVER MODULE front panel will resume displaying NON-SELECT function data (i.e., Figure A.1) after a few seconds. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 69 Step 3 will vary from 1 to 7, with the SEC and ACC LED’s indicating which information will be displayed via the ALM LED in the 8 pulsation sequence (see TABLE A.0). Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 70 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 71 FIGURE A.0 MP5-10 RECEIVER MODULE/RP5-10 REMOTE PANEL JUMPER CONTROLS INDICATORS DIAGRAM Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 72 2 man reset (see UM-32, section 2.5) then for the ALARM LED to go OFF, the secured area MUST have been put into ACCESS and then BACK into SECURE for the above scenario to occur. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 73 PULSATING GREEN @ 1 PULSE/SECOND (Alarm condition CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @ 1 PULSE/4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 74 (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) SEC LED SOLID GREEN (NO loops were setup SHUNTED when BLINKING GREEN (At least 1 alarm loop is shunted) ACC LED ⇒ OFF Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 75 CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @ 1 PULSE/ 4 SECOND (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) SEC LED ⇒ OFF ACC LED SOLID YELLOW Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 76 NOT DEFINED Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 77 NOT DEFINED Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 78 PULSATING GREEN @ 1 PULSE/ SECOND (Alarm condition CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @ 1 PULSE/4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 79 PULSATING GREEN @1 PULSE/SECOND (Alarm condition CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @1 PULSE 4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 80 TRANSMISSION MODULE OFF-LINE so that any other MODULES may continue to communicate with the RECEIVER MODULE. ALSO, if NO TRANSMISSION MODULE communicates with the RECEIVER MODULE, it may be the RECEIVER that lost its DES key. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 81 PULSATING GREEN @ 1 PULSE/SECOND (Alarm condition CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @ 1 PULSE/ 4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 82 PUSLATING GREEN @ 1 PULSE/SECOND (Alarm condition CLEARED and AC loss, but DC OK in SECURED AREA) PUSLATING GREEN @ 1 PULSE/4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 83 PULSATING GREEN @ 1 PULSE/SECOND (Alarm condition CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @ 1 PULSE/4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 84 PULSATING GREEN @ 1 PULSE/SECOND (Alarm condition CLEARED and AC loss, but DC OK in Secured Area) PULSATING GREEN @ 1 PULSE/4 SECONDS (Alarm condition CLEARED and AC OK, but DC loss in Secured Area) Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 85 Note: The KEYPAD at the specific TRANMISSION MODULE MUST be restored to normal operation AND a valid PIN entered on the keypad before the KEYPAD HARDWARE ALARM condition can be reset (cleared) at the RECEIVER MODULE. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 86 AC & DC OK in Secured area. Remains PULSATING GREEN @ 1 PULSE/SECOND if AC loss, but DC OK in Secured area. Remains PULSATING GREEN @ 1 PULSE/4 seconds if DC NOK COMM LED remains unchanged AUDIBLE remains OFF Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 87 Secured area. Remains PULSATING GREEN @ 1 PULSE/ SECOND if AC loss, but DC OK in Secured area. Remains PULSATING GREEN @ 1 PULSE/4 seconds if DC NOK COMM LE remains unchanged AUDIBLE remains OFF Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 88 & DC OK in SECURED area. REMAINS PULSATING GREEN @ 1 PULSE/SECOND if AC loss, but DC OK in Secured Area. Remains PULSATING GREEN @ 1 PULSE/4 seconds if DC NOK. COMM LED remains unchanged AUDIBLE remains OFF Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 89 AC & DC OK in SECURED area. REMAINS PULSATING GREEN @ 1 PULSE/SECOND if AC loss, but DC OK in Secured Area. Remains PULSATING GREEN @ 1 PULSE/4 seconds if DC NOK. COMM LED remains unchanged AUDIBLE remains OFF10 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 90 Remains PULSATING GREEN @ 1 PULSE/ SECOND if AC loss, but DC OK in Secured area. Remains PULSATING GREEN @ 1 PULSE/4 seconds if DC NOK COMM LED remains unchanged AUDIBLE remains OFF Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 91 TRANSMISSION MODULE are connected, but faulty in some way, and must be corrected. Besides the signal pair interfacing the modules, there may be either a DES key mismatch or software version mismatch (i.e., V3.0 versus V4.0) between the RECEIVER and TRANSMISSION modules. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 92 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 93 Throughout the actual ENTRY/STORAGE procedure, the STATUS LED will indicate if the module is requesting entry of a segment number (blinking RED) or entry of data (blinking GREEN). The easiest way to illustrate the facility code is by the following examples: Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 94 FACILITY CODE DATA SEGMENT= 1 0 1 0 1 0 1 1 FACILITY CODE DATA SEGMENT= 1 1 0 0 1 1 0 1 FACILITY CODE DATA SEGMENT= 1 1 1 0 1 1 1 1 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 95 8. Remove the plug in jumper residing on either one of the 2 pins of the J1 DES KEY/PURGE JUMPER array. 9. Insert the plug in jumper across both of the 2 pins of the J1 jumper array. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 96 DIP switches 5,6,7,8 setup as ON, ON, ON, OFF where “0” = ON, “1” = OFF. 17. The DES KEY/PURGE PUSHBUTTON should again momentarily be pushed and released. The LED indicator will go to blinking GREEN. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 97 27. Insert the transmission module TB1 barrier strip first section into the CU5-32 as shown in Figure D.0. The transmission module is in an ON-LINE state (i.e., the keypad LCD date and time will start running, starting at all “zeros”). Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 98 4. Insert the plug in jumper across both of the 2 pins of the J1 jumper array. 5. Using Figure A.0 as a guide, locate the DIP SWITCHES and set up the switches as shown below. 2 3 4 5 6 7 8 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 99 CODE, when updating either, only PART of the FACILITY CODE need be changed, as long as the “PART” changed is kept UNDISCLOSED and SECRET. Therefore, if just a few “bits” are changed, the ENTIRE procedure becomes simpler because less manipulation of the DIP switches is required. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 100 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 101 EVENT LOGGING DATA MESSAGE REPORT GENERATION (IXM5-2 OR –4) OPTION The IXM5 option is installed on the Transmission Module when shipped from Digitize, Inc. Reports are generated to the local printer in the SECURED AREA via the Keypad. Specific operation of the keypad to generate is described earlier in Section 2.12.
  • Page 102 Figure D.O Transmission Module (TM5-13) to Local Printer (PTR5) Interfacing Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 103 The above example shows the Transmission Module loop #1, points 1-4, loop #2 point 1, and loop #4 point 3 alarm contacts on the ACCESS/SECURABLE ALARM LOOP opening, and then returning to the closed SECURE state. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 104 If a valid 2 Digit ID# and 5 digit PIN is entered on the Keypad, the following message will be printed. 04/04/90 12:12:16 KEYPAD ID#01 ZONE XX The above example shows keypad access for keypad PIN #01. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 105 04/04/90 15:21:23 SYNC ID#XX where XX is a byte and bit (start/end type) indicator NOTE: The “SYNC ID#” message is used for system troubleshooting and will typically be of no value to the user. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 106 When a PIN is defined as a user (LIMITED) service (TEST) or master PIN (see Section 2.9) the following will be printed: 04/04/94 16:30:11 REQUEST ID#XX CANCEL PIN REQUEST When a PIN is CANCELLED (see Section 2.7) the following will be printed: 04/04/94 16:35:35 CANCEL ID#XX Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 107 If the Transmission Module is configured with the IXM5-4 option and an SE access control subsystem is installed, the event recording of the SE subsystem via the Transmission Module printer will produce the printed message as detailed in APPENDIX “H”. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 108 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 109 3. Insert the DES KEY/PURGE JUMPER (Figure 1.0) across the two (2) J1 connector posts on the Transmission Module. 4. Re-insert the Transmission Module TB1 barrier strip first section into its connector on the CU5-32 motherboard. 5. The STATUS INDICATOR LED should be pulsating RED/GREEN. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 110 Enter a 2 digit day (01-31) Enter a 2 digit year (00-99) Enter a 2 digit hour (00-23) Enter a 2 digit minute (00-59) Enter a 2 digit seconds (00-59) Press the “#” (ENTER) key Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 111 NOTE: Just after the “#” is pushed, the Receiver Module to Transmission Module will momentarily re- synchronize. The effect observed will be the COMM STATUS LED on the Receiver Module will flicker for a moment. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 112 7. Press the “#” (ENTER) key twice. The transmission module will store the data for PIN #74 just entered (and the PIN # can now be used if needed) and the LCD will return to the idle state. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 113 APPENDIX G TRANSMISSION MODULE (TM5-32) ADDRESSING DIP SWITCH CONFIGURATION The DESPLEX 32 Series Transmission Module must be configured during installation so that when the system is on-line, the accompanying Receiver Module can determine which Transmission Module it is communicating with any given time during the DESPLEX polling cycle. The Receiver Module can communicate with up to 10 Transmission Module’s on the same pair of wires (see Figure G.0) and each Transmission Module must have a...
  • Page 114 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 115 APPENDIX H NOT DEFINED Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 116 Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 117 Also, included is a KEY TRANSFER cable that connects to the module 9 pin connectors when they are BOTH mounted on 2 DIGITIZE model EB5 or EB20 extender board (see Figure I.0) As mentioned above, an extender board must also be used when automated key loading is utilized. The RECEIVER MODULE generates the DES keys and then it must transfer the SAME keys to up to 9 TRANSMISSION MODULES and a SINGLE REMOTE PANEL.
  • Page 118 12. When the 5 seconds has elapsed, the key generation procedure is complete, and the RECEIVER MODULE COMM STATUS LED will return to a RED and GREEN Pulsating state. 13. Configure the RECEIVER MODULE DIP switches as shown below: 2 3 4 5 6 7 8 Digitize, Inc 700815-0001 Rev. A 08/02...

  • Page 119: Receiver Module/Remote Panel Maintenance Procedure

    22. Repeat steps 19-22 for all remaining REMOTE PANELS. When complete, remove the RECEIVER MODULE and return the 8 DIP switches to their positions from Step 1. Also, repeat Step 18 for the RECEIVER MODULE. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 120 FIGURE I.0 AUTOMATED DES KEY GENERATION/TRANSFER CONFIGURATION FOR RECEIVER MODULE & REMOTE PANEL Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 121 IXM5 option is configured. Also, included is a KEY TRANSFER cable that connects to the Receiver Module and Transmission Module 9 pin connectors when they are BOTH mounted on the Digitize model EB20 extender board. The extender board is used for automated DES key loading in addition to being utilized in checking out the Receiver Module and Transmission Module while at the receiver rack.
  • Page 122 The Receiver Module COMM STATUS LED will be pulsating RED and GREEN. The receiver rack AUDIBLE may or may not come on, either way, it is irrelevant to the key setup procedure and should be ignored. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 123 16. When the up to 2 minutes have elapsed, the Receiver Module COMM LED will return to the RED & GREEN pulsating state. 17. Remove the key transfer cable from the Transmission Module. 18. Perform Steps 20, 23-25 and repeat Steps 4-6, 15-18 until all Transmission Module’s have DES keys transferred to them. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 124 24. Remove the Transmission Module DES KEY/PURGE JUMPER and store the JUMPER on either jumper post, just as was done for the Receiver Module. 25. Re-install the Transmission Module(s) as described in the appropriate installation manual. Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 125 <8 DIGIT (0/1) DELAY> EXIT <1 DIGIT (1-8) Loop#> DELAY <“2”> REQUEST YY REQUEST TIMER YY DIGITIZE DESPLEX _______________________________________________________________________________________ SHUNT <ID#, PIN#73> REQUEST KEYPAD ID#XX POINT REQUEST SHUNT <01-06> DIGITIZE DESPLEX REQUEST SHUNT YY _______________________________________________________________________________________ Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 126 <5 DIGIT DATA> TEST ID# 74 REQUEST ID#74 DIGITIZE DESPLEX _______________________________________________________________________________________ POWERUP <master ID#, PIN> REQUEST KEYPAD ID#XX ALARM REQUEST POINT POINT <8 DIGIT (0/1) DATA> DEFINITION REQUEST YY REQUEST POINT YY DIGITIZE DESPLEX Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 127 REQUEST 06 <BUFFER MODE CHANGES DIGITIZE DESPLEX TRANSACTIONS> ******************* _______________________________________________________________________________________ PRINTER <master ID#, PIN> REQUEST KEYPAD ID#XX REPORT REQUEST REPORT (BUFFERED KEYPAD <01-74> TRANSACTION # REQUEST 05 BY ID# DIGITIZE DESPLEX <BUFFER KEYPAD TRANSACTIONS> ******************** Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 128 <master ID#, PIN> REQUEST KEYPAD ID#XX ALARM REQUEST TEXT TEXT <01-06 point number> SETUP <16 DIGIT TEXT DATA> DIGITIZE DESPLEX REQUEST TEXT _______________________________________________________________________________________ SHUTDOWN <master PIN> REQUEST KEYPAD ID#XX MEMORY **************** PRIOR TO ***************** POWERDOWN Digitize, Inc 700815-0001 Rev. A 08/02...
  • Page 129 12 months within 15 months after shipment by Digitize. Buyer must pass along to its initial customer or user ("Customer") a minimum of 12 months’ coverage within the 15-month warranty period, provided the Buyer gives Digitize prompt notice of any defect and satisfactory proof thereof.
