microQDVP
Pressure Scanner
Acquisition System
Valve Module
INSTALLATION
AND
OPERATING MANUAL
info@chell.co.uk
e-mail:-
Visit the Chell website at:
http://www.chell.co.uk
Chell Instruments Ltd
Folgate House
Folgate Road
North Walsham
Norfolk NR28 0AJ
ENGLAND
Tel:
01692 500555
Fax:
01692 500088
900169-1.0
Advertisement
Related Manuals for Chell microQDVP
Summary of Contents for Chell microQDVP
- Page 1 Chell Instruments Ltd Folgate House Folgate Road North Walsham Norfolk NR28 0AJ ENGLAND Tel: 01692 500555 Fax: 01692 500088 microQDVP Pressure Scanner Acquisition System Valve Module INSTALLATION OPERATING MANUAL info@chell.co.uk e-mail:- Visit the Chell website at: http://www.chell.co.uk 900169-1.0...
- Page 2 Chell Document No. : 900169 Issue 1.0 Date: 22 October 2012 Chell’s policy of continuously updating and improving products means that this manual may contain minor differences in specification, components and circuit design from the actual instrument supplied. Page 1...
-
Page 3: Table Of Contents
CONTENTS Description Specification Interface Details Installation of the instrument Operation of the instrument Service and Calibration Page 2... -
Page 4: Description
1 Description 1.1 General The microQDVP valve module is a compact accessory to the microDAQ range of acquisition devices. The module contains two solenoid valves designed to control the shuttle of Pressure System ™ ESP pressure scanners. There is also an electrical drive to allow a solenoid valve to control purge gas. -
Page 5: Specification
Specification 2.1 Mechanical: Package: 107 x 70 x 31mm Weight: 326g 2.2 Power Supply: Line voltage: 8-25 VDC. Consumption(QD-VP only): Max 5VA 2.3 CAN specifications: CAN type 2.0B CAN baudrate Configurable (by internal switch) from 1M, 500K, 125K and 100K. Programmable variables: Address 0x?nn Most significant programmable device ID... -
Page 6: Interface Details
Interface Details. 3.1 Connector – Mating connector: DEUTSCH ASDD606-09SN-HE Pin Number Designation +8~25V SUPPLY CAN_H CAN_L 3.2 USB Connector – Mating connector: Micro B Pin Number Designation +5v USB transceiver supply USBDM USBDP 3.3 Lemo Conector – Mating connector: FGG.0B.302.CLAD52Z Pin Number Designation +12v... -
Page 7: Installation Of The Instrument
The power for the microQDVP comes from a standard microDAQ power cable Pneumatic Interconnection The SMC™ pneumatic fittings on the back of the microQDVP accept standard 4mm OD polyurethane tubing. To connect to these: 1, Remove the knurled collar from the fitting. - Page 8 The microQDVP is controlled from one of three possible communications channels – RS232, Ethernet or CAN. If Ethernet or CAN are used then the microQDVP should be setup with an appropriate IP address and.or CANId and message protocol (in the same manner as the microDAQ).
- Page 9 The microQDVPSetup program is used in the same way as the main setup program for the microDAQ and is provided purely to set the necessary TCP and CAN parameters to enable a client program to connect with the microQDVP in run mode and issue user commands to control the unit accordingly.
- Page 10 CAN peripheral clock runs at 60Mhz. All register values should be calculated based on that clock frequency. 'CAN Base Message ID’ The microQDVP uses standard CAN message arbitration id's, and the unit is assigned the most significant 2 digits of the Hex base address. ‘CAN RX ID Offset’...
-
Page 11: Service And Calibration
6. Service and Calibration 6.1 Service There are no user serviceable parts inside the instruments. Should any difficulties be encountered in the use of the microQDVP, it is recommended that you contact Chell Instruments Ltd for advice and instructions. 6.2 Calibration This device does not require calibration.
