OWNER'S MANUAL
DC Multi Outdoor Type (R32 & R410A)
R32
KAM2-52 DR7
KAM3-78 DR7
KAM4-105 DR7
KAM5-120 DR7
IMPORTANT NOTE:
Read this manual carefully before installing or operating your new air conditioning unit.
Make sure to save this manual for future reference.
This manual only describes the outdoor unit of user's. When using the indoor unit,
refer to the user's manual of indoor unit.
R410A
KAM2-42 DN8
KAM2-52 DN7
KAM3-62 DN7
KAM3-78 DN7
KAM4-80 DN7
KAM4-105 DN7
KAM5-120 DN7

Advertisement

loading
Need help?

Need help?

Do you have a question about the KAM2-52 DR7 and is the answer not in the manual?

Questions and answers

Related Manuals for Kaysun KAM2-52 DR7

Summary of Contents for Kaysun KAM2-52 DR7

  • Page 1 OWNER’S MANUAL DC Multi Outdoor Type (R32 & R410A) R410A KAM2-52 DR7 KAM2-42 DN8 KAM3-78 DR7 KAM2-52 DN7 KAM4-105 DR7 KAM3-62 DN7 KAM5-120 DR7 KAM3-78 DN7 KAM4-80 DN7 KAM4-105 DN7 KAM5-120 DN7 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit.
  • Page 2 Table of Contents Owner’s Manual Safety Precautions ............04 SAFETY FIRST Unit Parts and Major Functions ......06 Manual Operation and Maintenance ....10...
  • Page 3 Troubleshooting ......... 11 a. Common Problems ......... 11 b. Troubleshooting Tips ....... 12 European Disposal Guidelines .............. 13 ƒ „ Page 3...
  • Page 4 Safety Precautions Thank you for purchasing this air conditioner. This manual will provide you with information on how to operate, maintain, and troubleshoot your air conditioner. Following the instructions will ensure the proper function and extended lifespan of your unit. Please pay attention to the following signs: Failure to observe a warning may result in serious injuries.
  • Page 5 This appliance can be used by children • CAUTION aged from 8 years and above and persons DO NOT touch the air outlet while the swing with reduced physical, sensory or mental • flap is in motion. Fingers might get caught capabilities or lack of experience and or the unit may break down.
  • Page 6 Unit Parts And Major Functions Unit Parts Duct / Ceiling type Wall-mounted type Fig. 2.1 Indoor unit 1. Panel frame 2. Rear air intake grille Fig. 2.2 3. Front panel Indoor unit 4. Air purifying filter & Air filter(behind) 1. Air outlet 5.
  • Page 7 Floor and standing type(console) Compact four-way cassette type Fig. 2.4 Fig. 2.3 Indoor unit 1. Drain pump(drain water from indoor unit) Indoor unit 2. Drain hose 1. Air flow louver (at air outlet) 3. Air outlet 2. Air inlet (containing air filter) 4.
  • Page 8 NOTE: For multi-split type air conditioners, one outdoor unit can be matched to different types of indoor units. All of the pictures in this manual are for demonstration purposes only. Your air conditioner may be slightly different, if similar in shape. The following pages introduce several kinds of indoor units that can be matched with the outdoor units.
  • Page 9 The air conditioner turns to FAN ONLY Heating mode (For cooling and heating mode from COOL or HEAT (for cooling and models only) heating models only) mode. The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit When the indoor temperature reaches the set temperature setting, the compressor will stop during heating.
  • Page 10 Manual Operations And Maintenance Operation mode selection Optimal operation While two or more indoor units are To achieve optimal performance, please note the simultaneously operating, make sure the modes following: do not conflict with each other. The heat mode • Adjust the direction of the air flow so that it is claims precedence over all other modes.

  • Page 11: Troubleshooting

    Troubleshooting CAUTIONS If one of the following conditions occurs, switch off the power supply immediately and contact your dealer for further assistance. The operation light continues to flash rapidly after the unit has been restarted. • The remote control buttons do not work. •...

  • Page 12: Troubleshooting Tips

    Problem Possible Causes Dust is emitted from The unit may accumulate dust during extended periods of non-use, which either the indoor or will be emitted when the unit is turned on. This can be mitigated by covering outdoor unit the unit during long periods of inactivity. The unit may absorb odors from the environment (such as furniture, cooking, The unit emits a cigarettes, etc.) which will be emitted during operations.

  • Page 13: European Disposal Guidelines

    European Disposal Guidelines Users in European Countries may be required to properly dispose of this unit. This appliance contains refrigerant and other potentially hazardous materials. When disposing of this appliance, the law requires special collection and treatment. DO NOT dispose of this product as household waste or unsorted municipal waste.
  • Page 14 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. ƒ Page 14 „...
  • Page 15 ƒ „ Page 15...
