Operator's Manual
CP6130, CP6240
Impact Wrench
WARNING
To reduce risk of injury, everyone using, installing, repairing, maintaining,
changing accessories on, or working near this tool must read and
understand these instructions, as well as separately provided safety
instructions part number 6159948710, before performing any such task.
Advertisement
Table of Contents
Related Manuals for Chicago Pneumatic CP6240
Summary of Contents for Chicago Pneumatic CP6240
- Page 1 Operator’s Manual CP6130, CP6240 Impact Wrench WARNING To reduce risk of injury, everyone using, installing, repairing, maintaining, changing accessories on, or working near this tool must read and understand these instructions, as well as separately provided safety instructions part number 6159948710, before performing any such task.
-
Page 2: Air Diagram
[m/s²] [m/s²] [Nm] [Nm] [kg] [mm] [mm] [Nl/s] [Nl/s] 2433.8-5199.4 6195.8 72.6 3/4” 16.8 67.2 33.8*7.5*19.7 CP6130-T70 1-1/2” 4000 1” 3300-7050 8400 33.0 31.7 858*190*500 3761.3-9145.0 10326.4 132.0 3/4” 18.6 74.2 35.8*10.6*24 CP6240-T120 2-1/2” 3000 1” 5100-12400 14000 60.0 908*270*610... -
Page 3: Impact Wrench
We, CHICAGO PNEUMATIC TOOLS , cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual exposu- re, in an individual risk assessment in a work place situation over which we have no control. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS DO NOT DISCARD - GIVE TO USER • Our goal is to produce tools that help you work safely and efficiently. Note: So-called “click” torque wrenches do not check for potentially The most important safety device for this or any tool is YOU. Your care dangerous over-torque conditions. - Page 5 protective equipment when working with materials which produce Your risk from these exposures varies, depending on how often you do airborne particles. this type of work. To reduce your exposure to these chemicals: work in a • Some dust created by power sanding, sawing, grinding, drilling and well ventilated area, and work with approved safety equipment, such as other construction activities contains chemicals known to the State of dust masks that are specially designed to filter out microscopic particles.
-
Page 6: Declaration Of Conformity
Machine type(s) : Serial No: CP6130-T70 CP6240-T120 From 00001 to 99999 Origin of the product : JAPAN is in conformity with the requirements of the council Directives on the approximation of the laws of the Member States relating : to "Machinery"... - Page 7 CP6130-T70 Impact Wrench Spare parts without part number are not sold separately ‐ High wear parts underlined...
- Page 8 CP6130-T70 Impact Wrench Index No. Part No. Description Qty. Index No. Part No. Description Qty. 5412103180 Clutch Housing 8940171022 Screw Kit 5412103178 Housing Cover Spring Washer 5412103240 Throttle Valve Handle Cap Screw 5412103179 Housing Cap Screw 5412056661 Rotor Hexagon Nut 8940171030 Rotor Blade (Set of 6pcs) Half‐Cut Head Bolt 5412056663 Cylinder 8940171023 Clutch Housing Cover Kit 8940171031 Hammer Clutch (Set of 2pcs) Clutch Housing Cover 8940171032 Clutch Pin (Set of 2pcs) Spacer ( B ) 5412056675 Clutch Frame Ball Bearing...
