- Page 1 J121NSH J121NWH Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/register J121NSH-02994K_EN.indd 1 2011-5-31 14:59:52...
- Page 2 You can save energy without compromising on time or performance. • Outdoor Care Using a Samsung washing machine with Eco Bubble allows you to wash waterproof clothing with greater comfort, in the knowledge that your washer provides excellent care for your outdoor clothes. The Foam Cushion created by Eco Bubble protects against impact and abrasion damage to the water proofing layer, minimizing damage to outdoor clothing, and also protecting other forms of delicate fabrics.
- Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
- Page 4 Congratulations on your new Samsung washer. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many benefits and features.
- Page 5 For washing machines with ventilation openings in the base, ensure that the opening is not obstructed by carpet or any other obstacles. Use the new hose-sets and old hose-sets should not be reused. safety information _5 J121NSH-02994K_EN.indd 5 2011-5-31 14:59:55...
- Page 6 Do not use a damaged power plug, damaged power cord or loose wall socket. - This may result in electric shock or fire. Do not pull or excessively bend the power cord. Do not twist or tie the power cord. 6_ safety information J121NSH-02994K_EN.indd 6 2011-5-31 14:59:55...
- Page 7 - If trapped inside, the child may become trapped and suffocate to death. Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the washer before using it. safety information _7 J121NSH-02994K_EN.indd 7 2011-5-31 14:59:55...
- Page 8 Unplug the power plug when the appliance is not being used for long periods of time or during a thunder/lightning storm. - Failure to do so may result in electric shock or fire. 8_ safety information J121NSH-02994K_EN.indd 8 2011-5-31 14:59:55...
- Page 9 Open the Water Tap and check if the water supply hose connector is firmly tightened and that there is no water leaking before using the product. - If the screws or the water supply hose connector are loose, it may result in water leakage. safety information _9 J121NSH-02994K_EN.indd 9 2011-5-31 14:59:55...
- Page 10 - This may result in spontaneous combustion or ignition due to the heat of the oxidation of the oil. Do not use hot water from water cooling/heating devices. - This may result in problems with the washer. 10_ safety information J121NSH-02994K_EN.indd 10 2011-5-31 14:59:56...
- Page 11 - This may result in discolouration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failure to do so may result in electric shock or fire. safety information _11 J121NSH-02994K_EN.indd 11 2011-5-31 14:59:56...
-
Page 12: Table Of Contents
Repairing a frozen washing machine Storing your washing machine TROUBLESHOOTING AND Check these points if your washing machine... INFORMATION CODES Information codes CYCLE CHART Cycle chart APPENDIX Fabric care chart Protecting the environment Declaration of conformity Specifications 12_ contents J121NSH-02994K_EN.indd 12 2011-5-31 14:59:56... -
Page 13: Setting Up Your Washing Machine
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Release lever... -
Page 14: Electrical Supply And Grounding
You can reduce the risk of leaks and water damage by: • Making water taps easily accessible. • Turning off taps when the washing machine is not in use. • Periodically checking for leaks at water inlet hose fittings. Before using your washing machine for the first time, check all connections at the water valve and taps for leaks. WARNING 14_ setting up your washing machine J121NSH-02994K_EN.indd 14 2011-5-31 14:59:58... -
Page 15: Drain
Drain Samsung recommends a standpipe height of 65cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory. - Page 16 4. Store the shipping bolts away safely in case you have to move the washing machine in the future. Packaging materials can be dangerous to children; keep all packaging material (plastic bags, polystyrene, etc.) well out of the reach of children. WARNING 16_ setting up your washing machine J121NSH-02994K_EN.indd 16 2011-5-31 14:59:58...
- Page 17 2. Connect the other end of the hot water supply hose to your sink’s hot water tap and tighten it by hand. 3. Use a Y-piece if you only want to use cold water. setting up your washing machine _17 J121NSH-02994K_EN.indd 17 2011-5-31 15:00:00...
- Page 18 5. Connect the other end of the water supply hose to the inlet water valve at the rear of the washing machine. Screw the Option hose clockwise all the way in. 18_ setting up your washing machine J121NSH-02994K_EN.indd 18 2011-5-31 15:00:01...
- Page 19 It is attached to the water supply hose and automatically cuts off the water flow if the hose is damaged. It also displays a warning indicator. • Connect the water supply hose to the tap as shown. setting up your washing machine _19 J121NSH-02994K_EN.indd 19 2011-5-31 15:00:02...
- Page 20 Plug the power cord into a wall sockets, an AC 220-240V / 50Hz approved electrical outlet protected by a fuse or circuit breaker. (For more information on electrical and grounding requirements, see page 14.) 20_ setting up your washing machine J121NSH-02994K_EN.indd 20 2011-5-31 15:00:04...
-
Page 21: Washing A Load Of Laundry
With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WASHING FOR THE FIRST TIME Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry). -
Page 22: Using The Control Panel
Fabrics include functional technology finishes and fibers such as spandex, stretch, and micro-fiber. Baby Care - High temperature wash and extra rinses ensure that no washing powder remains to mark your thin clothes. 22_ washing a load of laundry J121NSH-02994K_EN.indd 22 2011-5-31 15:00:05... - Page 23 Press this button to add additional rinse cycles. The maximum number of rinse cycles is five. BUTTON Press the button repeatedly to cycle through the available speeds for the spin cycle. J121NSH / J121NWH , 400, 800, 1000, 1200 rpm SPIN SELECTION BUTTON “No spin ”...
- Page 24 Press it once to turn your washing machine on, press it again to turn your washing machine off. POWER BUTTON If the washing machine is left on for more than 10 minutes without any buttons being touched, the power automatically turns off. 24_ washing a load of laundry J121NSH-02994K_EN.indd 24 2011-5-31 15:00:07...
-
Page 25: Child Lock
If you want to activate or deactivate the Sound Off function, press the Spin and Option buttons at the same time for 3 seconds. The “Sound Off ” will be lit when this feature is activated. 3 SEC. washing a load of laundry _25 J121NSH-02994K_EN.indd 25 2011-5-31 15:00:08... -
Page 26: Delay End
Baby Care, Wool, Hand Wash Eco Drum Clean Not available • A different bubble function may be applied depending the course. Eco Bubble selection is default. Press it once to deselect bubble option, press it again to select bubble option. 26_ washing a load of laundry J121NSH-02994K_EN.indd 26 2011-5-31 15:00:09... - Page 27 • Once a washing machine operation begins, you cannot add or select the bubble function. • Enough bubbles are generated with the specified amount of detergent. • Please clean the Debris filter frequently. Periodic cleaning helps generate sufficient bubbles. • Depending on the detergent and the laundry, the bubbles may be absorbed and seem like a small quantity. • Although bubbles are generated once the wash begins, it may take several minutes for users to see them. washing a load of laundry _27 J121NSH-02994K_EN.indd 27 2011-5-31 15:00:09...
-
Page 28: Washing Clothes Using The Cycle Selector
Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. 1. Turn on your sink’s water tap. -
Page 29: Washing Clothes Manually
Your new washing machine, combined with modern detergents, will give perfect washing results, thus saving energy, time, water and detergent. However, if your cotton is particularly dirty, prewash with a protein-based detergent. washing a load of laundry _29 J121NSH-02994K_EN.indd 29 2011-5-31 15:00:10... -
Page 30: Detergent And Additives Information
Do not overload the washing machine or your laundry may not wash properly. Use the chart below to determine the load capacity for the type of laundry you are washing. Fabric Type Load Capacity Model J121NSH/ J121NWH Cotton - average/lightly soiled 7.0 kg - heavily soiled 2.5 kg... -
Page 31: Detergent Drawer
(prevents the overflow from becoming blocked). Be careful that the fabric softener does not overflow, when you close the detergent drawer after adding fabric softener into the rinse detergent compartment. washing a load of laundry _31 J121NSH-02994K_EN.indd 31 2011-5-31 15:00:11... -
Page 32: Cleaning And Maintaining Your Washing Machine
• Powder-type cleansing agent: Use a [powder-type bleaching agent] or a [cleansing agent for drum cleaning only]. • Liquid-type cleansing agent: Use a [liquid-type oxygen bleaching agent] or a [cleansing agent for drum cleaning only]. 32_ cleaning and maintaining your washing machine J121NSH-02994K_EN.indd 32 2011-5-31 15:00:12... - Page 33 5. Allow all the water to flow into a bowl. Remain water maybe more than you expected. Prepare larger bowl. 6. Reinsert the emergency drain cap and the drain tube. 7. Replace the filter-cover. cleaning and maintaining your washing machine _33 J121NSH-02994K_EN.indd 33 2011-5-31 15:00:13...
-
Page 34: Cleaning The Debris Filter
1. Wipe the washing machine surfaces, including the control panel, with a soft cloth using a nonabrasive household detergent. 2. Use a soft cloth to dry the surfaces. 3. Do not pour water onto the washing machine. 34_ cleaning and maintaining your washing machine J121NSH-02994K_EN.indd 34 2011-5-31 15:00:14... -
Page 35: Cleaning The Detergent Drawer And Drawer Recess
5. Replace the liquid detergent divider by pushing it firmly into the drawer. 6. Push the drawer back into place. 7. To remove any remaining detergent, perform a rinse cycle without any laundry in the drum. cleaning and maintaining your washing machine _35 J121NSH-02994K_EN.indd 35 2011-5-31 15:00:15... -
Page 36: Cleaning The Water Hose Mesh Filter
If your washing machine has been stored in below-freezing temperatures, allow time for any leftover water in your washing machine to thaw out before using it. 36_ cleaning and maintaining your washing machine J121NSH-02994K_EN.indd 36 2011-5-31 15:00:15... -
Page 37: Troubleshooting And Information Codes
• Make sure the door lock light is off. Door lock light will off after drained. • Check if filter is jamed by cloth crumbs,please clear filter in time to Pump drain noise avoid noise. If the problem persists, contact your local Samsung Customer Service. troubleshooting and information codes _37 J121NSH-02994K_EN.indd 37 2011-5-31 15:00:15... - Page 38 • If the correct voltage is supplied, the cycle will resume automatically. For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer.
-
Page 39: Cycle Chart
4. Course time in individual homes may differ from the values given in the table due to variations in the pressure and temperature of the water supply, the load and the type of laundry. 5. When the Intensive Wash function is selected, the cycle time is increased for each cycle. cycle chart _39 J121NSH-02994K_EN.indd 39 2011-5-31 15:00:16... -
Page 40: Appendix 40 Fabric Care Chart
• Use stain removal products and bleaches before the wash cycle only when strictly necessary. • Save water and electricity by only washing full loads (the exact amount depends upon the program used). DECLARATION OF CONFORMITY This appliance complies with European safety standards, EC directive 93/68 and EN Standard 60335. 40_ appendix J121NSH-02994K_EN.indd 40 2011-5-31 15:00:20... -
Page 41: Specifications
SPECIFICATIONS TYPE FRONT LOADING WASHING MACHINE J121NSH / J121NWH DIMENSIONS W598mm X D610mm X H845mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME ℓ J121NSH / J121NWH NET WEIGHT 60 kg WASH AND SPIN CAPACITY 7.0 kg MODEL J121NSH / J121NWH 220 V 150 W... - Page 42 J121NSH-02994K_EN.indd 42 2011-5-31 15:00:21...
