- Page 1 Washing Machine Owner’s Instructions J1045A(V/S) J845A(V/S)
-
Page 2: Safety Precautions
Safety Precautions Congratulations on your purchase of this Samsung washing machine. These Owner's Instructions contain valuable information on the installation, use, and care of this appliance. Please take the time to read these instructions so that you can take full advantage of the washing machine's features and enjoy this appliance for many years to come. -
Page 3: Table Of Contents
Problems and solutions ------------------------------------------------------------ 15 Understanding error messages --------------------------------------------------- 15 Programme chart ------------------------------------------------------------- Appendix ------------------------------------------------------------------------------ Fabric care chart --------------------------------------------------------------------- 18 Electrical warnings ------------------------------------------------------------------ 18 Protecting the environment ------------------------------------------------------- 19 Declaration of conformity --------------------------------------------------------- 19 Specification -------------------------------------------------------------------------- 19 SAMSUNG Washing Machine Owner’s Instructions... -
Page 4: Lnstalling The Washing Machine
Unpack your washing machine and inspect it for shipping damage. Also make sure that you have received all of the items shown below. If the washing machine was damaged during shipping or you do not have all of the items, contact your Samsung dealer immediately. -
Page 5: Selecting A Location
After completing connection, if water leaks from the hose, then repeat the same steps. Use the most conventional type of faucet for water supply. In case the faucet is square or too big, remove the spacing ring before inserting the faucet into the adaptor. SAMSUNG Washing Machine Owner’s Instructions... -
Page 6: Connecting The Water Supply Hose
The drain pipe branch must be above the sink siphon so that the end of the hose is at least 60 cm above the ground. ln a drain pipe Samsung recommends that you use a 65 cm high vertical pipe; it must be no shorter than 60 cm and no longer than 90 cm. SAMSUNG Washing Machine Owner’s Instructions... -
Page 7: Plugging In The Machine
SAMSUNG Washing Machine Owner’s Instructions... -
Page 8: Washing A Load Of Laundry
Before the laundry can be unloaded, either “Drain” or the “Spin” program must be run. Delay Start selection button Press the button repeatedly to cycle through the available delayed start options (from 3 hour to 24 hours in one hour increments). Displayed hours means the time of finished washing-cycle. SAMSUNG Washing Machine Owner’s Instructions... - Page 9 Press once to turn the washing machine on, press again to turn the washing machine off. If the washing machine power is left on for longer than 10 minutes without any buttons being touched, the power automatically turns off. SAMSUNG Washing Machine Owner’s Instructions...
-
Page 10: Washing For The First Time
4. Add prewash detergent into compartment (if you desire). Caution : Concentrated or thick fabric softener and conditioner must be diluted with a little water before being poured into the dispenser (prevents the overflow from becoming blocked.) SAMSUNG Washing Machine Owner’s Instructions... -
Page 11: Washing Clothes Using Fuzzy Logic
Washing a Load of Laundry Washing clothes using Fuzzy Logic Your new washing machine makes washing clothes easy, using Samsung's "Fuzzy Logic" automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. -
Page 12: Washing Clothes Manually
3. Press the Start/Pause button. The Delay Start indicator will light, and the clock will begin counting down until it reaches your finish time. 4. To cancel Delay Start, press the (On/Off) button, then turn the washing machine on again. SAMSUNG Washing Machine Owner’s Instructions... -
Page 13: Washing Tips And Hints
If you do not know how hard your water is, ask your water authority. Keep detergents and additives in a safe, dry place out of the reach of children. Note: SAMSUNG Washing Machine Owner’s Instructions... -
Page 14: Maintaining The Washing Machine
Cleaning the exterior Wipe the washing machine surfaces, including the control panel, with a soft cloth and non-abrasive household detergents. Use a soft cloth to dry the surfaces. Do not pour water on the washing machine. SAMSUNG Washing Machine Owner’s Instructions... -
Page 15: Cleaning The Detergent Drawer And Recess
3. Unscrew the filter cap and take it out. 4. Wash any dirt or other material from the filter. Make sure the drain pump propeller behind the filter is not blocked. Replace the filter cap. 5. Replace the filter-cover. SAMSUNG Washing Machine Owner’s Instructions... -
Page 16: Cleaning The Water Hose Mesh Filter
Also clean the inside and outside of the threaded connector. 4. Push the filter back into place. 5. Screw the hose back onto the washing machine. 6. Turn on the faucet and make sure the connections are watertight. SAMSUNG Washing Machine Owner’s Instructions... -
Page 17: Troubleshooting
Before contacting After-Sales service: 1. Try to remedy the problem (See "Troubleshooting" on this page). 2. Restart the programme to see if the fault is repeated. 3. If the malfunction persists, call after-sales service and describe the problem. SAMSUNG Washing Machine Owner’s Instructions... -
Page 18: Programme Chart
Standard IEC 456. 3. Consumption in individual homes may differ from the values given in the table due to variations in the pressure and temperature of the water supply, the load and the type of laundry. SAMSUNG Washing Machine Owner’s Instructions... - Page 19 Towel Pile weave cotton towels, bath towel, bath gown Bedding Cotton bedding, bed lined, bed sheet, duvet cover, pillow cover etc. Duvet Cotton bedding with filling, duvet, pillow, blanket, sofa cover with light filling SAMSUNG Washing Machine Owner’s Instructions...
-
Page 20: Appendix
Pay particular attention to cords at plugs, convenience receptacles, and the point where they exit from the unit. Do not overload the wall outlet or extension cords. Overloading can result in fire or electric shock. SAMSUNG Washing Machine Owner’s Instructions... -
Page 21: Protecting The Environment
NET WEIGHT 78kg WASH and SPIN CAPACITY 7.0 (DRY LAUNDRY) MODEL J1045A(V/S) J845A(V/S) 220V/2000W 220V/2000W WASHING AND HEATING POWER 240V/2400W 240V/2400W CONSUMPTION MODEL J1045A(V/S) J845A(V/S) SPIN 230V 500W 430W PUMPING MODEL J1045A(V/S) J845A(V/S) SPIN REVOLUTION 1000 SAMSUNG Washing Machine Owner’s Instructions... - Page 22 IN CASE THE NEED FOR SERVICING ARISES -Don't hesitate to call any AS center nearby with your name, address, telephone number, model number and serial number of your machine when anything wrong with your product occurs. Code No.: DC68-01999D-AUS...
