Summary of Contents for RecPro RP-CT-122B-BL
- Page 1 INSTRUCTION MANUAL 2 Burner Gas Cooktop Models: RP-CT-122B-BL RP-CT-122B-SS...
- Page 2 Thank you for your purchase of the RecPro 2 Burner Gas Cooktop! Before the use of your new cooktop, please review this user manual carefully. This manual contains useful information pertaining to safety, maintenance/upkeep, installation, functions, features, and warranty. Please do not discard this manual as you may need to refer to it in...
- Page 3 WARNING WARNING: This symbol indicates a safety alert, it will alert you to possible hazards that can cause serious bodily harm, property damage, or even death. The safety symbol will precede important messages about safety. WARNING: If one does not follow the instructions in this guide exactly, an explosion or fire may occur resulting in personal injury, property damage, or even death.
- Page 4 CAUTION: Hazards or unsafe practices can result in personal injury or harm. Read the following instructions carefully before attempting the following application to prevent the potential risk of electric shock, fire or damage to the cooktop, or personal injury. Please use appliance only for its intended purpose as described by this manual.
- Page 5 WARNING • Do NOT use this cooktop as a space heater to warm a room, as this may cause carbon monoxide poisoning and overheating of the cooktop. • Never cover the rack completely with materials like aluminum foil or any other flammable objects. Doing this can cause an air flow block;...
- Page 6 Gas leaks may occur in the system and result in dangerous conditions. In some situations, a gas leak may not be detectable by smell. Gas suppliers recommend you purchase and install a UL approved gas detector. These detectors should be installed in accordance to the manufacturer instructions.
- Page 7 Instructions for cooktop usage: • Using the correct flame size: Flame should be adjusted so that it does not exceed beyond the edge of your utensils such as a pot or pan. Undersized utensils may expose a portion of the burner and flame, which may result in the combustion of fabric or clothing if they make contact with the flame.
-
Page 8: Installing Your Appliance
RV’s (NFPA 1192/ANSl) WARNING When installing this cooktop, you must adhere to the written instructions in this guide. No representative, agent, or employee of the manufacturer RECPRO or any other person(s) has authorization to do any kind of modifications, provisions/edits, or changes. -
Page 9: Cabinet Specifications
CABINET SPECIFICATIONS: To ensure proper operation of your cooktop, suitable cabinets must be used. Cabinet specification information: • There must be a ventilation hole in the cabinet for air circulation. A gap at the bottom of the cooktop, with a minimum of 3/8”, will also provide proper air circulation. -
Page 10: Cooktop Installation
CABINET/COUNTER CUTOUT MODEL RP-CT 19⅝″ 10⅝″ 4⅛″ ⅞" 1½″ 2″ 122B Above is the minimum cutout size Cooktop Installation Once the cabinet has been prepared according to the dimensions provided FIG. 1 and the gas line is in place: 1. Remove packing material, tape, and any temporary labels from your cooktop. -
Page 11: Electrical Connection
4. Connect a gas supply line with a shut-off valve and 5/8-18UNF connection to the cooktop through the gas cavity on the upper-left rear corner of the cabinet. Connect a 12V, not 110V, power supply wire to the appliance from the upper right-rear FIG. - Page 12 Igniting Gas Cooktop Electronically: 1. Ensure all control knobs are in their OFF positions. 2. Ensure the main gas tank valve FIG. 9 is OPEN. 3. Turn the desired control knob counterclockwise to HI setting, DO NOT LIGHT more than one burner simultaneously. 4.
- Page 13 ALWAYS PERFORM A GAS LEAK CHECK BEFORE USING GAS COOKTOP! Before operating the gas cooktop, always perform an analysis or check for a gas leak. DO NOT use gas cooktop until the leak test is preformed and confirmed there are no gas leak indications. - If there is a gas leak detected, replace the defective part recommended by the manufacturer or tighten the loose joint properly.
-
Page 14: Cooktop Features
• DO NOT USE pans that exceeds 1 inch larger than the burner grate. If oversized cookware is used, this may cause extreme heat build-up and may result in damage to the burner grate, burner, and/ or cooktop (maximum pan size= 10 inches). •... -
Page 15: Product Troubleshooting
Product Troubleshooting PROBLEM/SYMPTOM POSSIBLE CAUSE/SOLUTION Problem / Symptom Possible Cause / Solution Area surface burners will not Surface control knob has ignite OR area surface burners not fully turned to the LIGHT do not ignite uniformly. position. Check if your propane valve is open. - Page 16 Sanitation & Upkeep • Ensure all control knobs are in OFF position before cleaning. Ensure the cook-top and all components relating to the gas Cooktop are cooled off before touching or cleaning. • When cleaning the cooktop, only use a cleaner specifically designed for cooktops.
- Page 17 • DO NOT BLOCK air vents • DO NOT STORE flammable liquids or vapors (such as gasoline) or any other combustible equipment or materials near, at, or around the gas cooktop. • DO NOT USE any metallic or wire brush to clean any components relating to the cooktop.
-
Page 18: Product Warranty Information
Your RecPro appliance is covered by a one-year limited warranty. For one year from your original date of purchase of the original purchaser, RecPro will replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used, and maintained in accordance with the provided instructions. - Page 19 RecPro shall not be liable for consequential or incidental damages such as property damage and incidental expenses resulting from any breach of this written limited warranty or any implied warranties.
