- Page 1 INSTRUCTION MANUAL GAS COOKTOP RP-CT-173B-BL RP-CT-173B-SS...
-
Page 2: Table Of Contents
Table of Contents Product Introduction ................... 3 Safeguard Measures .................. 3 Instructions For Safety ................5 Installing Your Appliance ................8 Function ....................12 Cooktop Features ..................16 Product Troubleshooting ................18 Sanitation & Upkeep................19 Exploded-View Drawing ................20 Product Warranty Information ..............22 Page... -
Page 3: Product Introduction
Product Introduction Thank you for your purchase of the RecPro Gas Cooktop! Before the use of your new RecPro Gas Cooktop, please review this user manual carefully. This user and instruction guide contains useful information pertaining to safety, maintenance/upkeep, installation, functions, features, and warranty. - Page 4 IN THE EVENT THAT A GAS SMELL IS PRESENT: • Do NOT attempt to ignite or light ANY appliance or incendiary device. Do NOT touch ANY electrical switch. • Do NOT use any phone or electrical device in your • recreational vehicle.
-
Page 5: Instructions For Safety
The warning and important safety instructions appearing in this guide are not meant to cover every condition and possible situation that may occur. Caution, common sense, and care must be practiced when maintaining, operating, or installing your appliance. One should always contact the manufacturer about conditions or problems you do not understand. - Page 6 During and after use, do NOT touch or allow flammable materials, objects, or clothing to touch or come into contact with these areas until they have cooled down. Burners may be hot even though flames are not visible. These burners may still be hot enough to inflict burns or injuries.
- Page 7 CAUTION: Never attempt to utilize the cooktop during a power failure. During the event the power fails during use, always shut off the cooktop, as your appliance may turn on unsupervised as the power restores. Instructions for cooktop usage: • Using the correct flame size: Flame should be adjusted so that it does not reach beyond the edge of utensils such as a pot or pan.
-
Page 8: Installing Your Appliance
When installing this cooktop, you must adhere to the written instructions in this guide. No representative, agent, or employee of the manufacturer of RECPRO or any other person(s) has authorization to do any kind of modifications, provisions/edits, or changes to the instructions mentioned in this users manual. - Page 9 CABINET SPECIFICATIONS To ensure proper operation of your cooktop, suitable cabinets must be used. Cabinet specification information: • There must be a ventilation hole in the cabinet for air circulation. A gap at the bottom of the cooktop, with a minimum of 3/8", will also provide proper air circulation.
- Page 10 How to Install Gas Cooktop: Once the gas line is in place and the cabinet has been prepared in accordance to the dimensions previously provided: 1. Remove packing material, tape, and any temporary labels from your cooktop. (Fig. 1) 2. Push back the top glass cover assembly a little and lift up to remove it from the cooktop.
- Page 11 5. Use four self-tapping screws on both left and right to secure the cooktop (Fig. 5) 6. Check the pipe fittings for leaks using a soapy solution. NEVER TEST FOR LEAKS WITH OPEN FLAMES! Push to insert the top glass assembly. (Fig. 6 & 7) 8.
-
Page 12: Function
Electrical Connection Model with LED light: Connect the light wires to a 12V DC circuit with a fuse protected and a max rating of no more than 5 amps. Wiring Diagram Function How To Light Top Burners &WARNING Top cover must be open when main burner is in operation. Based on safety considerations, the top burner flame size should be adjusted so it does not extend beyond the edge of the cooking utensil. - Page 13 4. PROMPTLY position an extended lit wooden match or use an extended butane lighter through the grate spaces, nearest the burner port, to light the burner. Repeat steps 4 & 5 to light desired burners. (Fig. 10) 5. To adjust to the desired flame, push and rotate the burner control knob.
- Page 14 "ill t;3000 Fig.12 Turning the gas cooktop flame OFF: To turn the burner flame off, push and turn the control knob clockwise until the knob is in the "OFF" position. If you travel and need to refuel your gas tank, ALWAYS turn the tank valve off.
- Page 15 ALWAYS PREFORM A GAS LEAK CHECK BEFORE USING GAS COOKTOP! Before operating the gas cooktop, always preform an analysis or check for a gas leak. DO NOT use gas cooktop until the leak test is preformed and confirms there are no gas leak indications. Test for leaks by using between 11-13.8 WC pressure.
-
Page 16: Cooktop Features
• DO NOT USE any cooking pan, griddle, or any cooking instrument that covers more than one burner at any time. Maximum pan size is a 10 inch skillet. Any cooking instrument larger than 10 inches is strictly prohibited. If this instruction is not followed, results may cause large amounts of heat that could result in damage of the item or could result in... - Page 17 This appliance conforms to the directive: ANSI Z21.57-2010 Recreational Vehicle Cooking Gas Appliances, ANSI Z21.57a-2012 Addenda to Recreational Vehicle Cooking Gas Appliances, CAN1-1.16-M79 (reaffirmed 2016) Propane Cooking Appliance For Recreational Vehicles. Glass Cover Grill Ignition Knob Top Burner Control Knob Backlight Burner 17 I...
-
Page 18: Product Troubleshooting
Product Troubleshooting PROBLEM/SYMPTOM POSSIBLE CAUSE/SOLUTION Surface control knob has not been fully rotated to the LIGHT position. Check to see if gas valve is open. If not, open it. Burners are clogged. Make sure burner is off. Use a small wire, toothbrush, or Area surface burners needle to clean burner... -
Page 19: Sanitation & Upkeep
Sanitation & Upkeep • Ensure all control knobs are in OFF position before cleaning. Ensure the cooktop and all components relating to the gas cooktop are cooled off before touching or cleaning. • When cleaning the cooktop, only use a cooktop cleaner specifically designed for cooktops. -
Page 20: Exploded-View Drawing
• DO NOT STORE flammable liquids or vapors ( such as gasoline) or any other combustible equipment or materials near, at , or around the gas cooktop . DO NOT USE any metallic or wire brush to clean any • components relating th the cooktop. - Page 21 Lamp Switch Knob Fire Distributor LED PCB Front Burner Ignition Igniter Knob Mica Sheet Decoration Ring Left Burner Pipe Knob Base Rear Plate Front Burner Valve Burner Cover Rear Burner Rear Burner Valve Igniter Ignition Grill Silicon Control Panel Burner Holder Control Panel Holder (Right)
-
Page 22: Product Warranty Information
Product Warranty Information Your RECPRO appliance is covered by a one-year limited warranty. For one year from your original date of purchase of the original purchaser, RECPRO will pay costs for repairing or replacing any parts of this appliance that prove... - Page 23 RECPRO shall not be liable for consequential or incidental damages such as property damage and incidental expenses resulting...
- Page 24 RECPRD ® For further information, please contact: ICON DIRECT INC 806 S. DIVISION ST. BRISTOL, IN 46507, USA...
