REACH INS-TOP MOUNT
Installation, Operation and Maintenance Manual
Please read this manual completely before attempting to install or operate this equipment.
Notify carrier of damage! Inspect all components immediately.
Printed 05/2020
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS!
3560 NW 56th Street
Fort Lauderdale, FL 33309
Tel.: 786.600.4687 / Toll Free: 844.218.8477
Fax.: 786.661.4100
5659 Royalmount Avenue
Montreal, Qc, Canada H4P 2P9
Tel.: 514.737.9701 / Toll Free: 888.275.4538
Fax.: 514.342.3854 / Toll Free: 877.453.8832
Advertisement
Related Manuals for MVP ikon IT28R
Summary of Contents for MVP ikon IT28R
- Page 1 REACH INS-TOP MOUNT Installation, Operation and Maintenance Manual Please read this manual completely before attempting to install or operate this equipment. Notify carrier of damage! Inspect all components immediately. IMPORTANT INFORMATION READ BEFORE USE PLEASE SAVE THESE INSTRUCTIONS! 3560 NW 56th Street 5659 Royalmount Avenue Fort Lauderdale, FL 33309 Montreal, Qc, Canada H4P 2P9...
- Page 2 3. WITHIN 48 HOURS OF RECEIPT: In the event that the exterior is not damaged, yet upon opening, there is concealed damage to the equipment, notify MVP Group immediately at 1-888-275-4538; 514-737-9701. 4. Be certain to check the compressor compartment housing and visually inspect the refrigeration package. Be sure lines are secure and base is still intact.
- Page 3 Service and Installation Manual INSTALLATION Location Units represented in this manual are intended for indoor use only. Be sure the location chosen has a floor strong enough to support the total weight of the cabinet and contents. A fully loaded unit can weigh as much as 1500 pounds.
- Page 5 Service and Installation Manual OPERATION Do not throw items into the storage area. Failure to heed these recommendations could result in damage to the interior of the cabinet. CAUTION Refrigerated cycle Refrigerators: During the refrigeration cycle, the evaporator fans will run continuously even when one or more doors are open.
- Page 6 Service and Installation Manual 1.1 Function of LEDS MODE FUNCTION Compressor enabled Flashing -Programming Phase (flashing with - Anti-short cycle delay enabled Defrost enabled Flashing - Programming Phase (flashing with - Drip time in progress Fans enabled Flashing Fans delay after defrost in progress. An temperature alarm happened 2.
- Page 7 Service and Installation Manual MAINTENANCE The unit must be turned OFF and disconnected from the power source whenever performing service, maintenance functions or cleaning the refrigerated area. DANGER Refrigerators and Freezers The interior and exterior can be cleaned using soap and warm water. If this isn't sufficient, try ammonia and water or a nonabrasive liquid cleaner.
- Page 8 Service and Installation Manual MAINTENANCE Cleaning solutions need to be alkaline based or non-chloride based. Any cleaner containing chlorides will damage the protective film of the stainless steel. Chlorides are commonly found in hard water, salts, and household and industrial cleaners. If cleaners containing chlorides are used, be sure to rinse and dry thoroughly.
- Page 9 Service and Installation Manual ELECTRICAL DIAGRAM MODEL：IT28R CONDENSER FAN MODEL：IT56R CONDENSER FAN...
- Page 10 Service and Installation Manual ELECTRICAL DIAGRAM MODEL：IT82R OVERLOAD PLUG CONTACTOR PROTECTOR LAMP CONDENSER COMPRESSOR THERMOSTAT DISPLAY CURRENT RELAY ROOM EVAP SENSOR DOOR SWITCH MODEL：IT28F OVERLOAD PROTECTOR PLUG CONTACTOR CONDENSER FAN THERMAL LAMP COMPRESSOR CUT-OFF DOOR SWITCH CURRENT THERMOSTAT DISPLAY RELAY STARTING CAPACITOR ROOM...
- Page 11 Service and Installation Manual ELECTRICAL DIAGRAM MODEL：IT56F OVERLOAD PROTECTOR PLUG CONTACTOR LAMP CONTACTOR THERMAL CONDENSER COMPRESSOR CUT-OFF CURRENT THERMOSTAT DISPLAY RELAY STARTING CAPACITOR CAPACITOR EVAP ROOM SENSOR MODEL：IT82FDV CONTACTOR OVERLOAD PROTECTOR POWER THERMAL PLUG CUT-OFF CONDENSER EVAP CONTACTOR COMPRESSOR LAMP CURRENT RELAY STARTING...
- Page 12 Service and Installation Manual ELECTRICAL DIAGRAM MODEL: IT28R...
- Page 13 Service and Installation Manual WIRING DIAGRAM MODEL: IT28F...
- Page 14 Service and Installation Manual WIRING DIAGRAM MODEL: IT 56R...
- Page 15 Service and Installation Manual WIRING DIAGRAM MODEL: IT56F...
- Page 16 Service and Installation Manual WIRING DIAGRAM MODEL: IT82R...
- Page 17 Service and Installation Manual WIRING DIAGRAM MODEL: IT 82FDV...
- Page 18 Two Year Parts & Labor Warranty MVP Group (IKON) warrants, to the original purchaser, all of its new equipment to be free from defects in material and workmanship, under normal use and maintenance service, for a period of two (2) years from the date of original purchase or 15 months after shipment date from the manufacturer, whichever occurs first.
- Page 19 Service and Installation Manual...
