Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
VS20R9042T2
Vacuum cleaner
User manual
VS20R90**** Series / VS15R85**** Series
• Before operating this unit, please read the instructions carefully.
• For indoor use only
VS9000_EN_00821L-03_UK_A5.indd 1
o cerca il tuo prodotto tra le
migliori offerte di Aspirapolvere e Pulitrici
Samsung
2020-12-08 오후 4:12:17
Advertisement
Related Manuals for Samsung VS20R9042T2
Summary of Contents for Samsung VS20R9042T2
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Samsung VS20R9042T2 o cerca il tuo prodotto tra le migliori offerte di Aspirapolvere e Pulitrici Vacuum cleaner User manual VS20R90**** Series / VS15R85**** Series • Before operating this unit, please read the instructions carefully.
- Page 2 Contents PREPARATION MAINTENANCE Safety information Maintaining the vacuum cleaner When to empty the dustbin Emptying the dustbin easily without causing INSTALLATION dust clouds Name of the parts Emptying and cleaning the dustbin Accessories Cleaning the filter Cleaning the accessories Installing the charging stand Installation guide APPENDIX OPERATION...
- Page 3 PREPARATION Safety information • Before operating the appliance, please read this manual thoroughly and retain it for your reference. • Because the following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual. Caution/Warning symbols used WARNING Indicates that a danger of death or serious injury exists.
- Page 4 Failure to meet these requirements could cause damage to the internal parts of the vacuum and void your warranty. If your appliance is fitted with a nonrewireable BS 1363 plug it must not be used unless an appropriately rated (ASTA approved to BS 1362) fuse is fitted in the carrier contained in the plug.
- Page 5 • Do not use to suction up water. • Do not immerse in water for cleaning. • Please contact Samsung or a Samsung service center for a replacement if one is needed. • For information on Samsung’s environmental commitments and product specific regulatory obligations e.g.
- Page 6 • Do not attempt to open the charging stand. Repairs should be only carried out by a qualified Samsung service center. • Do not expose the charging stand to high temperatures or allow moisture or humidity of any kind to come into contact with the charging stand.
- Page 7 Installation • If you have a problem with installing the charging stand, contact a Samsung service center. ❇ Injury or product malfunction from not installing the charging stand may not be compensated.
- Page 8 • Do not use a damaged power plug, power cord, or loose power outlet. – Otherwise, electric shock or fire may occur. • If the power cord is damaged, have a Samsung authorized service center replace the power cord with a new power cord.
- Page 9 – Otherwise, an explosion or fire may occur. • If the vacuum makes a strange sound or emits a smell or smoke, turn off the vacuum immediately, and then contact a Samsung service center. – Otherwise, electric shock or fire may occur.
- Page 10 CAUTION • Do not use the product near combustible material. Also do not use: – In a place where a burning candle or desk lamp is placed on the floor. – In an area where an unattended place heater is turned on or an area in which there are unextinguished embers in a fireplace, in an ashtray, etc.
- Page 11 • Do not step heavily on the upper part of the wet brush while using it. – Otherwise, product damage or floor damage may occur. • When using the vacuum cleaner, be careful not to hurt yourself on the moving or spinning parts. –...
- Page 12 – If water gets into the product and an error occurs, turn off the product and contact a Samsung service center. • After unplugging the product, clean the charging stand. • When cleaning the washable parts, do not use alkaline detergent, acid, industrial detergent, air freshener, acetic acid, etc.
- Page 13 INSTALLATION Name of the parts A type B type 01 Pipe (Adjustable) 11 Battery level indicator 02 Dustbin 12 Battery release button 03 Metal mesh grille filter 13 Pipe release button 04 Washable micro filter 14 Pipe length adjustment button 05 Ultra fine dust filter 15 Brush release button 06 Dustbin release button...
- Page 14 Accessories Accessories may differ depending on the models. Pipe (Adjustable) Battery User manual Screws: 2 EA / Charging stand / Screw anchors: 2 EA / Screw: 1 EA / Power cord Fixing hook: 1 EA *Flexible Tool Combination Tool Extension Crevice Tool *Brush holder *Soft Action Brush *Turbo Action Brush *Mini Motorized Tool *Wet Brush /...
- Page 15 Installing the charging stand Installation guide Assembling the charging stand 1 Assemble the stand pipe to the bottom support, and fix it with a screw (small). – Make sure the direction for the assembly 'Click' is correct and push it in firmly so that the screw hole is made correctly.
- Page 16 OPERATION Using the vacuum cleaner Using the charging stand Charging ❇ ❇ Make sure the back of the battery is correctly placed onto the vacuum charging part. ❇ ❇ Check if the battery level indicator is displayed while charging. ❇ ❇ The battery level indicator blinks while charging.
- Page 17 Charging the battery ❇ ❇ When the battery level indicator is at its lowest level and blinks( ) charge the battery. ❇ ❇ When charging the vacuum, make sure the connection part of the charging stand is correctly connected. ❇ ❇ The vacuum cleaner cannot be used while it is charging. CAUTION •...
- Page 18 Operating the vacuum cleaner When the brush clings to the floors such as a carpet, a mat, bedding, etc. or does not spin properly, change the suction power to ‘MIN’ or ‘MID’ mode. Power ( ) on / off When pressing the power button, the vacuum cleaner starts operation in ‘MID’...
- Page 19 Using the accessories If the vacuum operates with the spinning brush not working, check whether the brush gets excessive force or clogged with a foreign matter. (Please refer to the troubleshooting part of this manual.) Adjusting the pipe length Press the button at the rear of the pipe to adjust the length of the pipe in 4 steps.
- Page 20 Mini Motorized Tool Use to clean bedding. ‘Click’ Combination Tool Use to remove dust from curtains, furniture, ‘Click’ sofas, etc. Extension Crevice Tool Use to remove dust in grooves of window frames, chinks, corners, etc. ‘Click’ Flexible Tool Use to clean the places hard to reach such as ‘Click’...
- Page 21 Wet Brush Using the multi-use wet pad Multi-use Use to clean a floor with a wet pad (wood and ‘Click’ wet pad linoleum). ❇ ❇ The Wet Brush does not have a dust suction function. ❇ ❇ When attaching the wet pad, make sure the pad is in the center of the spin disk.
- Page 22 MAINTENANCE Maintaining the vacuum cleaner ❇ ❇ For detailed information, please refer to the QR code. CAUTION • Before cleaning the vacuum cleaner, turn it off. • When the dustbin or filter is filled with dust, the vacuum cleaner may stop due to the overheating prevention device of the motor.
- Page 23 Remove the dust on the metal mesh grille While pressing the button, turn the filter with the combination tool. dustbin cover and remove it from the ❇ ❇ Do not pull the rubber attached to the dustbin. metal mesh grille filter. ‘Click’...
- Page 24 Cleaning the filter • To maintain the best performance of the filter, remove the dust on the filter frequently and clean the filter with water once a month. – After cleaning, dry completely for more than 24 hours in the shade before use. –...
- Page 25 Soft Action Brush NOTE • If a cloth or other foreign matter is vacuumed up and tangled with the spinning brush (drum), the spinning brush will stop working to protect the brush motor. After cleaning the brush, turn the power off and then on again.
- Page 26 • You can charge two batteries at the same time. Additional battery is sold separately. • When you purchase a battery in a Samsung service center, check for the genuine Samsung logo on the battery ( ) and the battery name (VS20R90**** Series: VCA-SBT90 / VS15R85**** Series: VCA-SBT90E).
- Page 27 • Static electricity may occur depending on the humidity, temperature, or floor material, etc. in your home. If it happens repeatedly, contact a Samsung service center. • Please charge the battery fully: – Before using a newly purchased battery for the first time or if you haven’t used the battery for a long time.
- Page 28 • Use a genuine wet pad of Samsung Electronics for wet brush. • If the wet brush is used without a wet pad, any product malfunction will not be covered by warranty and a service fee will be charged.
- Page 29 – If there is foreign matter on the wheel of the brush which cannot be removed easily, contact a Samsung service center. • If the inner part of the wet brush is clogged with a large foreign matter, spinning speed decreases or stops.
- Page 30 Before calling for service, review the problems and solutions below. If none of the suggested solutions resolve your problem, please visit our website at www.samsung.com or call Samsung Customer Care. Note that you will be charged for any service calls in which no defects were found.
- Page 31 Problems Solutions Cleaning is finished but • After cleaning, operate the vacuum for 10 seconds or more to small dust particles come suction up the small dust particles. out of the brush. • As this product has the overheating prevention device of the motor, product will stop operation temporarily for the following conditions.
- Page 32 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Customer Care Center Web Site 0330 SAMSUNG (7267864) www.samsung.com/uk/support DJ68-00821L-03...
