UV TREATMENT SYSTEM
EN
SYSTÈME DE TRAITEMENT UV
FR
SISTEMA DE TRATAMIENTO UV
ES
SISTEMA DI TRATTAMENTO UV
IT
UV-BEHANDLUNG-SYSTEM
DE
SISTEMA DE TRATAMENTO UV
PT
EN
INSTALLATION AND MAINTENANCE MANUAL
FR
MANUEL D'INSTALLATION ET D'ENTRETIEN
ES
MANUAL DE INSTALACION Y MANTENIMIENTO
IT
MANUALE DI INSTALLAZIONE E MANUTENZIONE
DE
EINBAU-UND BETRIEBSANLEITUNG
PT
MANUAL DE INSTRUÇOES E MANUTENÇAO
Heliox UV
PE
Model.
63135 Heliox LP P95
63136 Heliox LP P140
64347 Heliox LP P180
64348 Heliox LP P220
64349 Heliox LP P260
63137 Heliox LP P300
EN
Advertisement
Table of Contents
Related Manuals for Astralpool Heliox UV Series
Summary of Contents for Astralpool Heliox UV Series
- Page 1 UV TREATMENT SYSTEM SYSTÈME DE TRAITEMENT UV SISTEMA DE TRATAMIENTO UV SISTEMA DI TRATTAMENTO UV UV-BEHANDLUNG-SYSTEM Heliox UV SISTEMA DE TRATAMENTO UV Model. 63135 Heliox LP P95 63136 Heliox LP P140 64347 Heliox LP P180 64348 Heliox LP P220 64349 Heliox LP P260 63137 Heliox LP P300 INSTALLATION AND MAINTENANCE MANUAL MANUEL D’INSTALLATION ET D’ENTRETIEN...
- Page 3 ENGLISH __________________________________________________________________ IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be implemented for installation and start-up. Therefore, the installer as well as the user must read the instructions before beginning installation and start-up. Keep this manual for future reference.
- Page 4 3. CERTIFICATIONS: ___________________________________________________________________________________ The HELIOX UV LP range of systems are certified for pool and spa end use: Certified products: PE versions: 63135 Heliox UV LP P95 63136 Heliox UV LP P140 64347 Heliox UV LP P180 64348 Heliox UV LP P220 64349 Heliox UV LP P260 63137...
-
Page 5: Important Safety Instructions
Prior to the installation or replacement of any system component make sure it has been previously disconnected from the mains, and there is no water flow through it. Use only spare parts supplied by AstralPool. Never remove the lock nut of the quartz sleeve when the water is recirculating through the UV reactor as it could be expelled and causing damage. - Page 6 The UV light generated by this equipment can cause serious damage if the eyes or skin are exposed directly to the lamp. Never connect the system when the lamp is out of the reactor. Do not handle the UV lamps until completely cold. Always handle the UV lamp with gloves, as fat and other impurities deposited on the surface may reduce its performance and durability.
-
Page 7: System Description
4. SYSTEM DESCRIPTION Fig. 1 1.- Control panel. 7.- Inputs for sensor cables. 2.- Touchscreen. 8.- UV chamber. 3.- Main switch. 9.- Cover. 4.- Power cable input. 10.-.Stands. 5.- Output for UV reactor Ground cable. 11.- D200 inlet/outlet flanges. 6.- Outputs for lamp power cables 12.- Flow-switch (FS-1). - Page 8 Prior to the installation or replacement of any system component make sure it has been previously disconnected from the mains, and there is no water flow through it. Use only spare parts supplied by AstralPool. One bonding lug marked are provided on the head of the UV chamber suitable for No. 8 AWG (US) and No.
- Page 9 The control panel base has a series of cable glands for the correct fixation of the power cables and sensors. In any case the length or section thereof should be amended, without first consulting an AstralPool authorized technician.
- Page 10 CONTROL PANEL: FIELD WIRING DIAGRAM LP P95 Model T.block Control Panel Input Wire Wire description GROUND POWER 230 VAC / 50-60 Hz. / 1-PHASE LINE NEUTRAL UV REACTOR BONDING GROUND LAMP UV-1/1 BLACK “1” LAMP UV-1/2 BLACK “2” LAMP 1 LP-0410/1 LAMP UV-1/3 BLACK “3”...
-
Page 11: Potential-Free Contact
LP P180 Model T.block Control Panel Input Wire Wire description GROUND POWER 230 VAC / 50-60 Hz. / 1-PHASE LINE NEUTRAL UV REACTOR BONDING GROUND LAMP UV-1/1 BLACK “1” LAMP UV-1/2 BLACK “2” LAMP 1 LP-0410/1 LAMP UV-1/3 BLACK “3” LAMP UV-1/4 BLACK “4”... -
Page 12: Alarm Output
LP P260 Model T.block Control Panel Input Wire Wire description GROUND POWER 230 VAC / 50-60 Hz. / 1-PHASE LINE NEUTRAL UV REACTOR BONDING GROUND LAMP UV-1/1 BLACK “1” LAMP UV-1/2 BLACK “2” LAMP 1 LP-0410/1 LAMP UV-1/3 BLACK “3” LAMP UV-1/4 BLACK “4”... - Page 13 LP P300 Model T.block Control Panel Input Wire Wire description GROUND POWER 230 VAC / 50-60 Hz. / 1-PHASE LINE NEUTRAL UV REACTOR BONDING GROUND LAMP UV-1/1 BLACK “1” LAMP UV-1/2 BLACK “2” LAMP 1 LP-0410/1 LAMP UV-1/3 BLACK “3” LAMP UV-1/4 BLACK “4”...
- Page 14 5.4. UV lamp connection Connect the UV lamp(s) installed within the UV reactor to the corresponding terminals on the control panel using the Wires supplied with the unit (LP-0XX/n) (see page 8-11). To do this, remove the cover on the top of the UV reactor, and connect the wires to the corresponding terminals: Fig .5 1.- LP-0410 lamp power Wires (black wires labelled “1”...
- Page 15 5.5. Installation of the external flow detector Vertically install the FS-1 flow detector (flow switch) supplied with the unit using a ¾” male threaded saddle (Fig. 7a). There is an arrow on the head of the flow detector. Make sure that this arrow is parallel to the pipe shaft and pointing in the direction that the water flows (Fig.
- Page 16 a) pH must be in the range 7.2-7.6 b) Alkalinity must be in the range 60-120 ppm. 4. Check that all hydraulic connections are properly assembled and that there are no leaks in any of them. 5. Let recirculate the water at least for a few minutes to evacuate air and any dirt that might be inside the UV reactor. 6.
-
Page 17: Lamp Status
6. OPERATION:___________________________________________________________________________________________________ 6.1. System main screen Once the firmware is loaded, the main control screen of the system appears. This screen is divided into different areas of information. 6.2. System initialization This icon will remain rotating whenever the UV system is in operation. LAMP HOUR COUNTER This indicator shows the hours of operation of the lamps. - Page 18 FLOW Whenever the installed sensor detects an insufficient or null water flow inside the UV reactor, the system disconnects the UV lamps and the “Flow” indication of the screen will flash. WARNING: Once restored the water flow, the system automatically resets and becomes operative again.
- Page 19 Prior to the installation or replacement of any system component make sure it has been previously disconnected from the mains, and there is no water flow through it. Use only spare parts supplied by AstralPool. Do not handle the UV lamp until completely cold.
- Page 20 7.- Insert the new lamp, always holding it from the ceramic ends, and maintaining its verticality, to about 3/4 of its total length. 8.- Holding the lamp with a hand from its ceramic end, carefully connect again the power connector. 9.- Completely enter the lamp into the quartz sleeve.
- Page 21 3.- Insert your thumb into the sleeve and carefully slide it until the O-ring is released. 4.- Completely remove the quartz sleeve trying to maintain their verticality so that it does not suffer any torsion. 5.- Carefully remove the O-ring from the sleeve. 6.- If it appears that the sleeve is completely transparent, place in its housing again as described below.
- Page 22 7.3. Replacing seal in contact with the quartz sleeve FREQUENCY: Replace the seal in contact with the quartz sleeve EACH TIME YOU REPLACE THE LAMP. PROCEDURE: To replace the seal of the quartz sleeve, proceed according to the procedure described in section 7.2. 7.4.
- Page 23 8. TECHNICAL SPECIFICATIONS:____________________________________________________________________________________ HELIOX LP–P Series HELIOX LP P95 HELIOX LP P140 HELIOX LP P180 63135 63136 64347 418 gpm 616 gpm 792 gpm Flow (@ 40 mJ/cm 95 m 140 m 180 m 264 gpm 396 gpm 506 gpm Flow (@ 60 mJ/cm 60 m...
- Page 24 Dimensions LP 95 Model 19.7 27.6 51.2 1300 25.8 12.4 D200 23.8 inch / mm LP P140 | LP P180 Models 23.6 31.5 51.2 1300 25.8 12.4 D200 23.8 inch / mm...
- Page 25 LP P220 | LP P260 Models 31.5 31.5 51.2 1300 25.8 12.4 D200 23.8 inch / mm LP P300 Models 39.4 1000 31.5 51.2 1300 25.8 12.4 D200 23.8 inch / mm...
-
Page 26: General Aspects
9. WARRANTY CONDITIONS: _______________________________________________________________________________________ 9.1. GENERAL ASPECTS 9.1.1. According to these provisions, the seller guarantees that the guaranteed product is in perfect condition upon delivery. 9.1.2. The Total Warranty Period is 2 YEARS. 9.1.3. The Warranty period will be calculated as of delivery to the purchaser. 9.1.4. - Page 28 Made in Spain 6313E102-21 NIF ES-B03731908 We reserve to change all or part of the articles or contents of this document, without prior notice Nous nous reservons le droit de modifier totalment oru en partie les caracteristiques de nos articles ou le contenu de ce document sans pré avis Nos reservamos el derecho de cambiar total o parcialmente las características de nuestros artículos o el contenido de eeste documento sin previo aviso Ci riservamo il dritto di cambiare totalemente o parzialmente le caratteristiche technique dei nostri prodotti ed il cotenuto di questo docuemntosenza nessum preavviso Wir behalten uns das recht vor die eigenschatten unserer produkte oder den inhalt dieses prospektes teilweise oder vollstanding, ohne vorherige benachichtigung zu andern...
