6 Drawer Chest
109 L WD
Thank you for choosing this furniture.
BEFORE YOU START ASSEMBLY please store the carton at room temperature for 48 hours or more so the contents can acclimatise.
PLEASE RETAIN PACKAGING UNTIL YOU HAVE COMPLETED ASSEMBLY.
Information about your furniture.
Our furniture ranges have been carefully crafted from solid wood and natural wood veneers. Each piece of furniture has unique
characteristics such as knots, variances and graning. These are part of the natural character of the furniture itself.
Caring for your furniture.
Extreme temperature can cause slight movements in the wood itself so please avoid placing your furniture close to radiators or other direct
sources of heat. Humidity should also be avoided. Please avoid exposing your furniture to continued bright sunlight as it can affect the colour.
Any fluid should be removed as quickly as possible. Always lift your furniture when moving, as dragging can cause damage to your furniture or
flooring. Extreme changes in temperature & humidity during transit may result in a powder residue forming so silica gel bags have been included
to alleviate this natural occurrence. This residue is harmless and can easily be removed before assembly with a damp cloth and mild detergent.
After care.
Wipe the surfaces with a dry cloth and an occasional use of normal household polish. We also recommend you use household spray
polish occasionally on the drawer grooves and runners as this will aid use. Please do not use detergents or chemicals on your furniture.
Before you start assembly.
Please check that you have all the correct parts and fittings as detailed above. In the unlikely event of a part being damaged or
missing please mark the component or part on the diagrams above and email to
Please provide the following information so that your request can be dealt with ASAP
* Name * Address * Post Code * Tel number * Batch number (to be found at the bottom left of this page or on the outer box)
Additional parts - only applied to model with skirting board
Batch No.
arisesunltd@gmail.com
70 min
A = x36
Dowel
B = x22
40mm Screw
C = x117
25mm Screw
D = x30
Nail
E = x6
Handle
F= x12
Bolt
B = x4
40mm Screw
N = x2
60mm Screw
