T4 Pro
Programmable Thermostat
TH4110U2005, TH4210U2002
User Guide
Package Includes:
• T4 Pro Thermostat
• UWP™ Mounting System
• Decorative Cover Plate
• Screws and Anchors
• 2 AA Batteries
• Thermostat Literature
Read before installing
Thermostat controls
• System status
information
Cool On/Heat On/Em
Heat On, Recovery,
Compressor Protection
• Actual time
• Schedule information
Following time based
schedule
• Mode
Select system mode
Heat/Off/Cool/Auto/
EM Heat (emergency
heat)
• Menu
Press to display options.
Start here to set a
program schedule
The screen will wake up by pressing any of the five buttons. If powered by the C wire, the screen stays lit for 45 seconds
after you complete changes. If powered by battery only, the screen stays lit for 8 seconds. Depending on how your
Customer assistance
For assistance with this product, please visit Honeywellhome.com/support
thermostat was installed, the screen light may always be on.
• Indoor temperature
setpoint
Press + or – to change
temperature setting
• Actual indoor
temperature
• Temperature/
Navigation buttons
Press to increase or
decrease temperature
setpoint and to
navigate menus and
menu options
• Fan
Select Fan mode
Auto/On
M37844

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TH4110U2005 and is the answer not in the manual?

Questions and answers

Nathan Moskovits
April 22, 2025

how do i reset the thermostat

1 comments:
Mr. Anderson
May 11, 2025

To reset the Honeywell Home TH4110U2005 thermostat (T4 Pro Series), press and hold the Menu button and the Plus (+) button together. This opens the ISU menu. Scroll to the option labeled "Restore Defaults" and select it to perform a factory reset.

This answer is automatically generated

Sandra Rawlins
February 26, 2025

How do you unlock the thermostat?

User image 67bea9e0e1915
1 comments:
Mr. Anderson
May 14, 2025

To unlock the Honeywell TH4110U2005 thermostat:

1. Press the center button labeled “Unlock” on the screen.
2. Use the + and - buttons to enter the PIN code (default is 1234).
3. Press “Select” to confirm.
4. If the code is incorrect, press “Back” to try again.

If you forgot the code, remove the thermostat from the wall, find the number on the back, and add 1234 to it. The result is the unlock code.

This answer is automatically generated

Tony
January 28, 2025

Need user manual for TH411OU2005 non- programmable

1 comments:
Mr. Anderson
May 14, 2025

The Honeywell TH4110U2005 is a programmable thermostat, not a non-programmable one. It comes with a user guide titled "T4 Pro Programmable Thermostat TH4110U2005, TH4210U2002 User Guide."

This answer is automatically generated

Jim
January 17, 2025

I have moved into a older condo with this thermostat using a 2 wire system. The condo has a boiler and is heated with hot water.My thermostat is connected to R and Y and I think it should be R and W. If I set the thermostat to a certain temp, it will blow through that temp and keep heating the condo. should I change it to R and W?

1 comments:
Mr. Anderson
February 3, 2025

Yes, for a 2-wire system with a boiler heating hot water, the Honeywell Home TH4110U2005 thermostat should be connected to R (24 volts hot) and W (heating signal). This setup is used for heating-only systems like boilers.

This answer is automatically generated

steven watt
July 25, 2025

When I press Menu, PROG is not displayed.

Summary of Contents for Honeywell Home TH4110U2005

  • Page 1 T4 Pro Programmable Thermostat TH4110U2005, TH4210U2002 User Guide Package Includes: • T4 Pro Thermostat • UWP™ Mounting System • Decorative Cover Plate • Screws and Anchors • 2 AA Batteries M37844 • Thermostat Literature Read before installing Thermostat controls • System status •...
  • Page 2: Fan Operation Settings

    System operation settings 1 Press the Mode button to cycle to the next available System mode. 2 Cycle through the modes until the required System mode is displayed and leave it to activate. NOTE: Available System modes vary by model and system settings.
  • Page 3: To Adjust Program Schedules

    Program Schedule You can program four time periods each day, with different settings for weekdays and weekends. We recommend the pre-sets (shown in the table below), since they can reduce your heating/cooling expenses. Heat Cool Wake - Set to the time you wake up and the °...
  • Page 4 Program schedule override (temporary) 1 Press to adjust the temperature. 2 Once at the desired setpoint temperature, no further action is needed. The new setpoint temperature will be held until the next scheduled time period begins. For more information on schedule time periods, see “Program Schedule”...
  • Page 5: Adaptive Intelligent Recovery

    Adjusting keypad lockout 1 Press Menu on the thermostat. to go to LOCK. Press Select. 2 Press to go to OFF, PART, or ON, and then press Select. 3 Press OFF: Unlocked, and full access allowed. PART: Partial lockout, allowing only the temperature to be changed. ON: No access allowed.
  • Page 6: Battery Replacement

    Battery replacement Batteries are optional (to provide backup power) if your thermostat was wired to run on AC power when installed. If your thermostat When the low battery warning appears, press was not wired to run on AC power, then gently to loosen the batteries are required.
  • Page 7 Air Filter Reminder 1 The alert icon appears on the Home screen. 2 Press Menu, and then press until display shows ALRT. 3 Press Select to display which alert(s) are present. 4 The message REPL (REPLACE AIR FILTER) appears. 5 The reminder can be snoozed or cleared. Resideo recommends changing the air filter before clearing the reminder.
  • Page 8: Troubleshooting

    Troubleshooting If you have difficulty with your thermostat, please try the following suggestions. Most problems can be corrected quickly and easily. Display is • Check circuit breaker and reset if necessary. blank • Make sure power switch for heating & cooling system is on. •...
  • Page 9 5-year limited warranty For warranty information go to Honeywellhome.com/support...
  • Page 10 33-00188EFS—09 M.S. Rev. 08-20 | Printed in United States © 2020 Resideo Technologies, Inc. All rights reserved. The Honeywell Home trademark is used under license from Honeywell International, Inc. This product is manu- factured by Resideo Technologies, Inc. and its affiliates.
  • Page 11: Guide De L'utilisateur

    T4 Pro Thermostat Programmable TH4110U2005, TH4210U2002 Guide de l’utilisateur La boîte comprend : • Thermostat T4 Pro • Système de montage UWP™ • Plaque de couvercle décorative • Vis et chevilles • 2 piles AA M37844 • Documentation du thermostat Lire avant l’installation...
  • Page 12 Réglages pour le fonctionnement du système 1 Appuyez sur le bouton Mode pour passer au prochain mode de système disponible. 2 Faites défiler les modes jusqu’à ce que le mode de système requis soit affiché, et laissez-le s’activer. REMARQUE : Les modes de système disponibles varient en fonction du modèle et des paramètres du système.
  • Page 13 Programmation Vous pouvez programmer quatre périodes de temps par jour, avec des réglages différents pour les jours de la semaine et les fins de semaine. Nous recommandons les paramètres prédéfinis (illustrés dans le tableau ci-dessous), car ils permettent de réduire vos frais de chauffage/refroidissement.
  • Page 14: Dérogation (Temporaire) Au Programme

    Dérogation (temporaire) au programme 1 Appuyez sur pour régler la température. 2 Une fois la température de consigne souhaitée obtenue, aucune autre action n’est requise. La nouvelle température de consigne est utilisée jusqu’à ce que la prochaine période commence. Pour plus d’informations sur les périodes du programme, consultez la section Programmation à...
  • Page 15: Protection Intégrée Du Compresseur

    Réglage du verrouillage du clavier 1 Appuyez sur Menu sur le thermostat. pour aller à LOCK (Verrouillage). Appuyez sur Select. 2 Appuyez sur 3 Appuyer pour se rendre à OFF (arrêt), PART (partiel), ou ON (marche), et puis appuyer sur Select (sélectionner). OFF (arrêt) : Déverrouillé...
  • Page 16: Remplacement Des Piles

    Remplacement des piles Les piles sont facultatives (pour fournir une alimentation de secours) si le thermostat a été câblé sur le courant secteur lors de Lorsque l’avertissement de charge faible des l’installation. Si ce n’est pas le cas, les piles piles s’affiche, appuyez sont requises.
  • Page 17 Rappel de remplacement du filtre à air 1 L’icône d’alerte s’affiche sur l’écran d’accueil. 2 Appuyez sur Menu, puis appuyez sur jusqu’à ce que l’affichage montre ALRT (alerte). 3 Appuyer sur Select (Sélectionner), pour afficher l’/les alerte(s) présente(nt). 4 Le message REPL (Remplacer le filtre à air) s’affiche.
  • Page 18: Dépannage

    Dépannage En cas de difficultés avec le thermostat, essayez les suggestions suivantes. La plupart des problèmes peuvent être réglés rapidement et facilement. Rien n’apparaît • Vérifiez le disjoncteur et réinitialisez-le si nécessaire. à l’écran • Assurez-vous que l’interrupteur de marche-arrêt du système de chauffage et de refroidissement est sur marche.
  • Page 19: Garantie Limitée De 5 Ans

    Garantie limitée de 5 ans Pour obtenir des renseignements à propos de la garantie, visitez Honeywellhome.com/support...
  • Page 20 33-00188EFS—09 M.S. Rev. 08-20 | Imprimé aux États-Unis © 2020 Resideo Technologies, Inc. All rights reserved. The Honeywell Home trademark is used under license from Honeywell International, Inc. This product is manu- factured by Resideo Technologies, Inc. and its affiliates.
  • Page 21: Asistencia Al Cliente

    T4 Pro Termostato Programable TH4110U2005, TH4210U2002 Guía del usuario El paquete incluye: • Termostato T4 Pro • Sistema de montaje UWP™ • Placa de cubierta decorativa • Tornillos y tarugos • 2 baterías AA • Material de lectura sobre el...
  • Page 22 Configuraciones de funcionamiento del sistema 1 Presione el botón Mode para pasar al siguiente modo disponible del sistema. 2 Avance a través de los modos hasta que se muestre el modo requerido del sistema y déjelo para activarlo. NOTA: Los modos disponibles del sistema varían según el modelo y las configuraciones del sistema.
  • Page 23: Para Ajustar Los Cronogramas Del Programa

    Cronograma del programa Puede programar cuatro períodos de tiempo por día, con diferentes configuraciones para los días de semana y los fines de semana. Recomendamos las configuraciones preestablecidas (que se muestran en el cuadro a continuación), debido a que estas reducen los gastos de calefacción y refrigeración.
  • Page 24 Anulación del cronograma del programa (temporal) 1 Presione para regular la temperatura. 2 Una vez que se encuentre en la temperatura del punto de referencia deseado, no necesita hacer nada más. El nuevo punto de referencia de la temperatura se mantendrá hasta que comience el siguiente período.
  • Page 25 Ajuste del bloqueo del teclado 1 Presione Menu (menú) en su termostato. para ir a LOCK (bloqueo). Presione Select (seleccionar). 2 Presione 3 Presione para ir a OFF (apagado), PART (parcial) u ON (encendido) y seguidamente presione Select (seleccionar). OFF (apagado): Desbloqueado y permite el acceso total. PART (parcial): Bloqueo parcial, permitiendo solo el cambio de la temperatura.
  • Page 26: Reemplazo De Las Baterías

    Reemplazo de las baterías Las baterías son opcionales (para ofrecer suministro de energía de respaldo) si su termostato fue cableado para funcionar con Cuando aparezca la advertencia de batería corriente CA cuando fue instalado. Si su con poca carga, presione termostato no fue cableado para funcionar suavemente para aflojar el con suministro de energía CA, necesita...
  • Page 27 Recordatorio del filtro de aire 1 Aparece el icono de aviso en la pantalla de inicio. 2 Presione Menú, y después pulse hasta que la pantalla muestra ALRT. 3 Presione Select (seleccionar) para mostrar cuál(es) alerta(s) está(n) presente(s). 4 Aparece el mensaje REPL (reemplace el filtro de aire).
  • Page 28: Localización Y Solución De Problemas

    Localización y solución de problemas Si tiene dificultades con el termostato, intente seguir las sugerencias que se indican a continuación. La mayoría de los problemas pueden solucionarse de manera fácil y rápida. La pantalla está • Revise el interruptor de circuito y, si es necesario, reinícielo. en blanco •...
  • Page 29: Poliza De Garantia

    Poliza de garantia IMPORTADO EN MEXICO POR: INSTROMET MEXICANA S DE R L DE C V Avenida Insurgentes 2453, Piso 6, Tizapan, Alvaro Obregon, Ciudad de Mexico, CP 01090 Telefono: 01 (55) 800 00423 Instromet Mexicana S. de R.L. de C.V. garantiza que éste producto está libre de defectos en su mano de obra y materiales contra cualquier defecto de fabricación y funcionamiento, bajo uso normal, por el término de 5 años a partir de la fecha de la compra por el consumidor.
  • Page 32 33-00188EFS—09 M.S. Rev. 08-20 | Impreso en EE. UU. © 2020 Resideo Technologies, Inc. All rights reserved. The Honeywell Home trademark is used under license from Honeywell International, Inc. This product is manu- factured by Resideo Technologies, Inc. and its affiliates.
