- Page 1 GSC 9124 Dishwasher Instruction Manual...
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY 5 OPERATING THE PRODUCT 21 Starting your machine .......21 AND ENVIRONMENT Half Load function ......23 General safety ........4 How to cancel the washing Intended use ..........4 Programme ......... 23 Children’s safety ........5 Salt indicator........23 Disposing of packaging material ..5 Rinse Aid indicator ...... -
Page 4: Instructions For Safety And Environment
InstructIons for safety and envIronment This section contains safety electric shock! instructions that will help to Never touch the plug with • give protection from risk of wet hands! Never unplug by personal injury or property pulling on the cable, always damage. -
Page 5: Children's Safety
InstructIons for safety and envIronment It must be used to do the Store all detergents and • • domestic type dishes only. additives in a safe place This appliance is intended away from the reach of the • to be used in household and children. -
Page 6: Compliance With Weee Directive And Disposing Of The Waste Product
InstructIons for safety and envIronment Compliance with WEEE collection points designated by the local authorities. Directive and Disposing of the Waste Product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). -
Page 7: Dishwasher Overview
Dishwasher Overview 1. Top Cover 2. Upper impeller 3. Lower basket 4. Lower impeller 5. Filters 6. Rating Label 7. Control panel 8. Door 9. Detergent dispenser 10. Cutlery basket 11. Salt reservoir lid 12. Upper basket rail 13. Upper basket 7 / 34 EN Dishwasher / Instruction Manual... -
Page 8: Technical Specifications
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2006/95/EC, 2004/108/EC, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 9: Installation
Installation To make the product ready for use, Do not install the product at places • make sure that the electricity, tap water where temperature may fall below supply and water drainage systems are 0ºC. appropriate before calling the Authorised Place the product on a rigid floor. -
Page 10: Connection To The Drain
Installation Electrical connection Connection to the drain Before you insert the plug into the wall Water discharge hose can directly be socket make sure that the voltage and connected to the drain hole or sink’s the frequency shown in the rating label drainage. -
Page 11: Fitting A Different Plug
Installation Fitting a different plug sure that all preparations are made in accordance with the instructions in As the colours of the wires in the mains sections “Important safety instructions” lead of this appliance may not correspond and “Installation”. with the coloured markings identifying the Before using the product, fill the salt •... -
Page 12: Preparation Tips For Energy Saving
Preparation Tips for energy saving operates with the same performance continuously. Dishwasher salt is used for Following information will help you use the this purpose. product in an ecological and energy-efficient Use only special softening salts manner. produced particularly for the Wipe away any coarse food remnants on dishwashers in your machine. -
Page 13: Water Hardness & Regeneration Settings
Preparation 2. Turn the salt reservoir lid counter 4. Replace the lid and tighten it securely clockwise to open it (A, B). when the reservoir is full. 5. If you will not start a washing programme Salt reservoir will fill with water immediately after adding the salt, run the when you start the product. - Page 14 Preparation Test Strip 1 second Level 1 No Lime Level 2 Very low lime content Level 3 Low lime content Level 4 Medium lime content 1 minute Level 5 High lime content Very High lime content Level 6 Remove the Let the water Take the test strip Hold for...
-
Page 15: Detergent
Preparation If the hardness level of the water that you Do not put solvents into the use is above 80 °dF (French standard for detergent dispenser. There is water hardness) or if you are using well the risk of explosion! water, then it is recommended to use filter Put the detergent into the detergent and water purification devices. -
Page 16: Tablet Detergents
Preparation 25cm³ 5cm³ 15cm³ washing chemicals such as glass and stainless steel protectors. 25cm³ 5cm³ 15cm³ If dishes have been waiting for a long time and have dried residues, fill the 5 cm³ Tablet detergents give compartment too (5). satisfying results only under certain usage conditions. -
Page 17: Rinse Aid
Preparation Observe the instructions of the detergent manufacturer on the package when using tablet detergents. When you switch to powder detergent from tablet detergent: Make sure that salt and rinse aid reservoirs are full. 2. Set the water hardness to the highest level and perform an empty run. - Page 18 Preparation increased and if there is a blue trace Place thin, narrow pieces in the middle • after wiping them by hand, it must be sections of baskets if possible. decreased. This is set to position 4 as There are two separate baskets in •...
- Page 19 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware 19 / 34 EN Dishwasher / Instruction Manual...
-
Page 20: Height Setting With Empty Basket
Preparation Height setting with empty Upper basket height basket adjustable rack In this model, the height setting of the Use the lower and upper parts of the height upper basket may be changed using the adjustable racks in the upper basket of wheels which are mounted at two different the machine by sliding them down or up heights. -
Page 21: Operating The Product
Operating the product Programme Starting Point 5. Start / Stop key 2. Rinse Aid indicator 6. Half Load key 3. Salt indicator 7. On/Off/Programme Selection Key 4. On/Off Indicator Light & Progress Indicator Lights Starting your machine On/Off Machine will be switched on when you Open the tap. - Page 22 Operating the product /34 EN Dishwasher / Instruction Manual...
-
Page 23: Half Load Function
Operating the product Programme and auxiliary With the Half Load function you functions cannot be set/ can save both water and power changed after the programme while using the lower and upper has started. baskets of the machine. Your machine performs water Half Load function may cause softening depending on the changes in the programme... -
Page 24: End Of Programme
Operating the product End of programme When the programme you have selected comes to an end, the End progress indicator light will lights up. Open the door of the dishwasher. 2. Turn off your machine. 3. Close the tap. 4. Unplug the machine from the socket. Leave your dishes in the machine for about 15 minutes after they are washed in order... -
Page 25: Maintenance And Cleaning
Maintenance and cleaning Cleaning the filters Service life of the product extends and frequently faced problems decrease if it is Clean the filters at least once a week in cleaned at regular intervals. order for the machine operates efficiently. Unplug the product and turn off Check if food residues are left on the filters. -
Page 26: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the impellers 4. Clean all three filters under tap water by means of a brush. Clean the impellers at least once a week in 5. Replace the metal/plastic filter. order for the machine operates efficiently. 6. Place the coarse filter into the Lower impeller microfilter. -
Page 27: Upper Impeller
Maintenance and cleaning Upper impeller Check if the holes on the upper impeller (1) are clogged. If they are clogged, remove and clean the impeller. Turn its nut to left to remove the upper impeller (A, B). Make sure that the nut is tightened well when installing the upper impeller. -
Page 28: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. • Door of the machine is open. >>> Make sure that you have closed the door of the machine. • On / Off button is not pressed. >>> Make sure that you have turned on the machine by pressing the On / Off button. Dishes are not washed clean • Dishes are not placed orderly in the machine. >>> Load the dishes as described in the user manual. • Selected programme is unsuitable. >>> Select a programme with a higher temperature and cycle time. • Impellers are stuck. >>> Prior to starting the programme, turn the lower and upper impellers by hand to make sure that they rotate freely. • Impeller holes are clogged. >>> Lower and upper impeller holes might be clogged with food remnants such as lemon pips. - Page 29 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed. Slightly open the door and wait for evacuation of the steam inside for a while. Unload the dishes after the pieces cool down to a touchable level.
- Page 30 Troubleshooting machine. Since the salt granules that will remain under the lid will dissolve during prewash, causing the lid loosen, check the lid once again at the end of the programme. There is a different odour in the machine A new machine has a peculiar odour. It will fade out after a couple of washes. • Filters are clogged. >>> Check if the filter system is clean. Clean the filter system regularly as illustrated in section “Cleaning and Care”.
- Page 31 Troubleshooting Detergent remains in detergent dispenser. • Detergent dispenser was damp when adding detergent. >>> Make sure that the detergent dispenser is dried well prior to filling it with detergent. • Detergent is added long before the washing process. >>> Pay attention to add detergent shortly before start-up of the washing. • Opening of the detergent dispenser lid is prevented during washing. >>> Place the dishes in a way that will not prevent the detergent dispenser lid from opening and the water going into the machine from impellers.
- Page 32 Troubleshooting A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid. • Corrosion has occurred on glass due to soft water. >>> Measure the hardness of the supply water appropriately and check the water hardness setting.
-
Page 33: Guarantee
Instructions as a charge may be levied where no fault is found even though your product may still be under guarantee. Guarantee Details Your new BLOMBERG product is guaranteed against the cost of breakdown repairs for three years from the date of the original purchase. What is covered? • Repairs necessary as a result of faulty materials, defective components or manufacturing... - Page 34 • Repairs to products used on commercial or non-residential household premises. • Loss of frozen food in freezers or fridge/freezers. (Food loss insurance is often included within your household contents insurance policy, or may be available separately from your retailer). Important notes. • Your BLOMBERG product is designed and built for domestic household use only. • The guarantee will be void if the product is installed or used in commercial or nonresidential domestic household premises. • The product must be correctly installed, located and operated in accordance with the instructions contained in the User Instructions Booklet provided. • Professional installation by a qualified Electrical Domestic Appliance Installer is recommended for all Washing Machines, Dishwashers and Electric Cookers • Gas Cookers must only be installed by a Gas Safe (or BORD GAIS) registered Gas Installer.
