Rohm BH1730FVC-TR Technical Notes

Digital 16bit serial output type ambient light sensor ic

Advertisement

Quick Links

Ambient Light Sensor ICs
Digital 16bit Serial Output Type
Ambient Light Sensor IC
BH1730FVC
●Descriptions
BH1730FVC is a digital Ambient Light Sensor IC for I
data for adjusting LCD backlight power of TV, mobile phone. It is possible to detect very wide range light intensity. (0.008 -
65535 lx ).
●Features
2
1) I
C bus Interface ( f / s Mode Support, Slave address "0101001". )
2) There are two outputs that peaks of a spectrum response are in visible light (Type0) and in infrared light (Type1).
3) Illuminance to Digital Converter
4) Very wide range and High resolution. ( 0.008 - 65535 lx )
5) Low Current by power down function
6) 50Hz / 60Hz light noise reject-function
7) Correspond to 1.8V logic input interface
8) Light source dependency is little by calculating with Type0 and Type1.
( ex. Incandescent Lamp. Fluorescent Lamp. Halogen Lamp. White LED. Sun Light )
9) Interrupt function is available.
10) Adjustable measurement result for influence of optical window
( It is possible to detect min. 0.001 lx, max. 100000 lx by using this function. )
11) Small measurement variation (+/- 15%)
12) Built in power on reset circuit.
●Applications
LCD TV, Mobile phone, NOTE PC, Portable game machine, Digital camera, Digital video camera, PDA, LCD display
●Absolute Maximum Ratings
Parameter
Supply Voltage
INT , SDA, DVI, SCL, Terminal Voltage
Operating Temperature
Storage Temperature
SDA, INT Sink Current
Power Dissipation
※ 70mm × 70mm × 1.6mm glass epoxy board. Derating in done at 3.47mW/℃ for operating above Ta=25℃.
●Operating Conditions
Parameter
VCC Voltage
2
I
C Reference Voltage
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
2
C bus interface. This IC is the most suitable to obtain the ambient light
Symbol
V
max
CC
V
max, V
max, V
max, V
INT
SDA
DVI
Topr
Tstg
Imax
Pd
Symbol
Min.
Vcc
2.4
V
1.65
DVI
1/20
BH1730FVC
Limits
Units
4.5
max
7
SCL
-40~70
-40~100
7
mA
260
mW
Typ.
Max.
Units
3.0
3.6
-
V
CC
2012.02 - Rev.A
No.11046EAT13
V
V
V
V

Advertisement

loading
Need help?

Need help?

Do you have a question about the BH1730FVC-TR and is the answer not in the manual?

Questions and answers

Summary of Contents for Rohm BH1730FVC-TR

  • Page 1 ※ 70mm × 70mm × 1.6mm glass epoxy board. Derating in done at 3.47mW/℃ for operating above Ta=25℃. ●Operating Conditions Parameter Symbol Min. Typ. Max. Units VCC Voltage C Reference Voltage 1.65 2012.02 - Rev.A www.rohm.com 1/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 2 C ‘H’ Period of the SCL Clock tHIGH µs - - C SDA Output ‘L’ Voltage - IOL = 3 mA ※1 White LED is used as optical source. 2012.02 - Rev.A www.rohm.com 2/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 3 Ta [ ℃ ] VCC [ V ] DVI [ V ] Fig.12 Measurement Result Fig.11 Measurement Result Fig.10 Power down ICC@0Lx DVI Dependency Temperature Dependency VCC Dependency 2012.02 - Rev.A www.rohm.com 3/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 4 Internal oscillator ( typ. 360kHz ). It is clock for internal logic. ・POR Power on reset. All register is reset after VCC is supplied. Please refer P14 (Caution of power on reset function). 2012.02 - Rev.A www.rohm.com 4/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 5 Read cycle is 00h - 01h - 02h - 03h - 04h - 05h - 06h – 07h – 12h – 14h – 15h – 16h – 17h - 00h ……… 2012.02 - Rev.A www.rohm.com 5/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 6 All registers are reset and BH1730FVC becomes power down during DVI = 'L'. Initial reset is not necessary, because power on reset function is included in this product. 2) Software reset command All registers are reset and BH1730FVC becomes power down by Software reset command. 2012.02 - Rev.A www.rohm.com 6/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 7 00001 : Interrupt output reset. 4 : 0 00010 : Stop manual integration mode. Special command 00011 : Start manual integration mode. 00100 : Software reset Don’t input other commands. 2012.02 - Rev.A www.rohm.com 7/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 8 10110110 : 74 cycle. 199.8ms. 01101100 : 148 cycle. 399.6ms. 00000001 : 255 cycle. 688.5ms. Cycle is defined 256-ITIME<7:0>. Integration time is typically cycle*2.7ms. ADC needs additional 2ms for internal calculation. 2012.02 - Rev.A www.rohm.com 8/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 9 Change ADC resolution. X00 : X1 gain mode GAIN 2 : 0 X01 : X2 gain mode X10 : X64 gain mode X11 : X128 gain mode 2012.02 - Rev.A www.rohm.com 9/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 10 Upper byte ○DATA1 (16h,17h) ADC Type1 data default value 00h Type Register Address Description DATA1 LSBs 7 : 0 Lower byte DATA1 MSBs 7 : 0 Upper byte 2012.02 - Rev.A www.rohm.com 10/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 11 If you don't use INT Pin, please connect to GND or open. INT pin pull up resister C bus pull up resister 100kohm 2.2kΩ 2.2kΩ C bus voltage source BH1730FVC 0.1µF 0.1µF Micro Controller 2012.02 - Rev.A www.rohm.com 11/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 12 L x = ( 0 . 2 7 6 * D ATA 0 - 0 . 1 3 0 * D ATA 1 ) / G a i n * 1 0 0 m s / I T I M E e l s e L x = 0 2012.02 - Rev.A www.rohm.com 12/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 13 Master writes “Interrupt output reset” command. INT Terminal persistence = 1 persistence = 2 DATA0 Interrupt threshold H level sequential measurement results Interrupt threshold L level time 2012.02 - Rev.A www.rohm.com 13/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 14 More than 1ms (VCC < 0.4V) is need to active BH1730FVC. 2.0V 0.4V BH1730FVC Don’t care active Don’t care active *”active state” is that BH1730FVC works and accept I C bus access correctly. 2012.02 - Rev.A www.rohm.com 14/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 15 Illuminant per 1count(lx / count) 1111_1111 0.247 1101_1010 0.007 0000_0001 0.001 Please take care that about 100,000lx or more cannot be measured even if decreasing the sensitivity. 2012.02 - Rev.A www.rohm.com 15/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 16 DVI terminal is pulled down by 150kOhm while DVI is set 'L' C bus Interface SCL terminal ※These values are design-value, not guaranteed. 2012.02 - Rev.A www.rohm.com 16/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 17 Please design the optical window so that light can cover at least this area . Min . 0 . 4 mm Min . 0 . 4 mm 2012.02 - Rev.A www.rohm.com 17/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 18 ② Distinguishing by die pattern ③ Distinguishing by taper part of 1-3pin side ②(by die pattern) is the easiest method to distinguish by naked eye. ② ③ Production code ① 2012.02 - Rev.A www.rohm.com 18/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 19 ) Please mount by Footprint dimensions described in the Jisso Information for WSOF6I. This pad is GND level, therefore there is a possibility that LSI malfunctions and heavy-current is generated. 2012.02 - Rev.A www.rohm.com 19/20 © 2012 ROHM Co., Ltd. All rights reserved.
  • Page 20 (1.2) 1pin 1PIN MARK 0.145±0.05 0.08 S Direction of feed 0.22±0.05 0.08 Reel ∗ (Unit : mm) Order quantity needs to be multiple of the minimum quantity. 2012.02 - Rev.A www.rohm.com 20/20 © 2012 ROHM Co., Ltd. All rights reserved.
