●General Description ROHM’s BD48□□G/FVE and BD49□□G/FVE series are highly accurate, low current consumption reset IC series. The lineup was established with tow output types (Nch open drain and CMOS output) and detection voltages range from 2.3V to 6.0V in increments of 0.1V, so that the series may be selected according the application at hand.
Page 2
1 Use above Ta=25℃ results in a 5.4mW loss per degree. 2 Use above Ta=25℃ results in a 2.1mW loss per degree. 3 When a ROHM standard circuit board (70mm×70mm×1.6mm glass epoxy board) is mounted. ●Electrical Characteristics (Unless specified otherwise, Ta=-40℃~+105℃)
Page 3
●Reference Data (Unless specified otherwise, Ta=25℃) 【 BD4842G/FVE 】 【 BD4842G/FVE 】 【 BD4942G/FVE 】 =2.4V =8.0V =6.0V =1.2V =4.8V 9 10 DRAIN-SOURCE VOLTAGE : V DRAIN-SOURCE VOLTAGE : V SUPPLY VOLTAGE : V Fig.3 Circuit Current Fig.4 “Low” Output Current Fig.5 “High”...
Page 4
●Reference Data Examples of Leading (TPLH) and Falling (TPHL) Output Part Number TPLH (µs) TPHL (µs) BD4845G/FVE 39.5 87.8 BD4945G/FVE 32.4 52.4 VDD=4.3V→5.1V VDD=5.1V→4.3V This data is for reference only. The figures will vary with the application, so please confirm actual operating conditions before use. ●Explanation of Operation For both the open drain type (Fig.
Page 5
●Circuit Applications 1)Examples of a common power supply detection reset circuit. Application examples of BD48□□G/FVE series (Open Drain output type) and BD49□□G/FVE series (CMOS output type) are shown below. Microcontroller CASE1: the power supply of the microcontroller (VDD2) differs BD48□□□ from the power supply of the reset detection (VDD1).
Page 6
Examples of the power supply with resistor dividers In applications where the power supply input terminal (VDD) of an IC with resistor dividers, it is possible that a through current will momentarily flow into the circuit when the output logic switches, resulting in malfunctions (such as output oscillatory state). (Through-current is a current that momentarily flows from the power supply (VDD) to ground (GND) when the output level switches from “High”...
Operation Notes 1 . Absolute maximum range Absolute Maximum Ratings are those values beyond which the life of a device may be destroyed. We cannot be defined the failure mode, such as short mode or open mode. Therefore a physical security countermeasure, like fuse, is to be given when a specific mode to be beyond absolute maximum ratings is considered.
Page 8
Any data, including, but not limited to application circuit diagrams and information, described herein are intended only as illustrations of such devices and not as the specifications for such devices. ROHM CO.,LTD. disclaims any warranty that any use of such devices shall be free from infringement of any third party's intellectual property rights or other proprietary rights, and further, assumes no liability of whatsoever nature in the event of any such infringement, or arising from or connected with or related to the use of such devices.
Page 9
ROHM cannot be held responsible for any damages arising from the use of the products under conditions out of the range of the specifications or due to non-compliance with the NOTES specified in this catalog.
