Working Mode - AsReader ASR-P35U User Manual

◆ The ASR-P35U has two working modes: HID mode and Serial mode.
⚫
HID mode
HID (Human Interface Device) mode: When this product is connected to a mobile
device (or a PC) in HID mode, this product is recognized as a keyboard, and the
data read by this product is sent to the mobile device (or the PC) "as is," displayed
as a text input tool. Therefore, there is no need to use an App that uses a dedicated
SDK. HID mode supports Android and Windows devices.
⚫
Serial mode
This mode enables real-time data transfer between ASR-P35U and the App that
uses a dedicated SDK.
There are dedicated SDKs for Android and Windows.
◆ How to change modes?
Switch between Serial mode and HID mode by switching Dip Switch 2's ON/OFF
switch (see FIG. 1-3-2⑥) of the ASR-P35U.
Serial mode: 2-ON
If it is powered on, the mode switching is completed after two buzzes.
ASTERISK INC.
DESKTOP-Type Mini User Manual
FIG. 3-1 Change mode
11
3

Working mode

HID mode: 2-OFF
