Summary of Contents for AirTechnic AHB 18 B

  • Page 1 INFRARED HEATER V. 4...
  • Page 2 Infrared Heater AHB Infrared Heater AHB This manual provides you with important information needed for setup, operate and maintain your ABH radiant heater. Failure to follow these instructions may damage and/or impair its operation and void the warranty.

  • Page 3: Performance Features

    Do not connect ground wires to gas pipes, water pipes, lightning rods or telephone ground wiring. Rated Current Voltage Cable length Power Model [mm] AHB 18 B 1.800 220 ÷ 240 2.000 AHB 24 B 2.400 10,4 220 ÷ 240 2.000...

  • Page 4: Installation Instructions

    Infrared Heater AHB 5. INSTALLATION INSTRUCTIONS (min) (min) Model A [mm] B [mm] C [mm] AHB 18 B 1.000 AHB 24 B 1.500 1.200 AHB 32 B 2.000 1.700...
  • Page 5 Infrared Heater AHB Step 1 Remove packing of both ends of heater. PACKING MATERIAL Step 2 Connect adjusted bracket to sliding bracket. ADJUSTING BRACKET SLIDING BRACKET SCREW + FLAT WASHER + SPRING WASHER + NUT (Spec.: M6)
  • Page 6 Infrared Heater AHB Step 3 Installation of sliding bracket & heater, as arrow points. Step 4 Fix adjusting bracket into the wall by expansion screws. EXPANSION SCREWS ADJUSTING BRACKET...

  • Page 7: Installation Diagram

    Infrared Heater AHB Step 5 Installation of two adjusting brackets; make sure lock brackets tight by butterfly hand screw. SCREW + FLAT WASHER + SPRING WASHER + NUT (Spec.: M5) BUTTERFLY HAND SCREW 6. INSTALLATION DIAGRAM 45° 140 mm 45° Ceiling 140 mm 75 mm...

  • Page 8: Internal Wire Diagram

    Infrared Heater AHB 7. INTERNAL WIRE DIAGRAM 8. WIRE DIAGRAM Follow wiring instruction as follows : 1. One unit control 2. Several units control Wire 120 150 185 240 diameter [mm Current [A] 105 124 160 201 235 275 323 381 Air swicth [A] 100 125 125 160 250 250 500 400 400...

  • Page 9: Remote Control Operation

    Infrared Heater AHB 9. REMOTE CONTROL OPERATION Temperature controller parts 1 2 3 4 5 1 2 3 4 5 1 - 4 : Indicator light Heater LED indicator lights. There are 4 indicator lights on the temperature controller parts (above image). These 4 lights show the heater’s operation level.
  • Page 10 Infrared Heater AHB Power levels 1 indicator light has two color states, “red” and “green”. RED color : N 2 to N 4 lights show in power settings. GREEN color : N 2 to N 4 lights show in clock settings (time settings). Power level 25% Operation without timer settings.
  • Page 11 Infrared Heater AHB “LEVEL” button Press LEVEL button to adjust the power when the heater is on (as shown in picture 3-1). “FAST-HOT” button Press FAST-HOT button to turn on / off the fast-hot function. Fast-hot function runs the heater at full power for a certain time, to achieve rapid heating. “TIMER ON”...
  • Page 12 Infrared Heater AHB “TIMER OFF” button 1. Press the “TIMER OFF” button and the symbol “OFF” will appear (as shown in picture 6-1). 2. Press “up” or “down” button to adjust the hour (as shown in picture 6-2). 3. Press the “Timer OFF” button again and the minutes flash. Press “up” or “down” button to adjust the minutes (as shown in picture 6-3).

  • Page 13: General Safety Notes

    GROSS WEIGHT MODEL [mm] [mm] [Kg] [Kg] AHB 18 B 1.095 x 189 x 67 1.190 x 250 x 145 AHB 24 B 1.595 x 189 x 67 1.690 x 250 x 145 11,2 AHB 32 B 2.095 x 189 x 67 2.190 x 250 x 145...
