RED DRAGON ELECTRONIC PROPANE FLARE
Assembly and Operating Instructions
Failure to follow these instructions, local, state, national codes
and other instructions provided with this flare equipment may
For Models:
PF-16 LPS – 1/2" Flare – 48,300,000 BTU/hr Max
The RED DRAGON
PROPANE FLARE is
designed for the
evacuation of LP liquid
or vapor only. Its use for
the evacuation of any
other gases or
flammable liquids is
strongly discouraged
and cancels any
warranties or perceived
responsibility of FLAME
ENGINEERING, INC.
Read this manual and any other
safety-related information before
assembling, operating or maintaining
your RED DRAGON PROPANE FLARE:
Save this manual for future reference.
result in serious injury or death.
PFLPS Instruction Manual 7-2012
®
TORCHES & EQUIP.
Advertisement
Related Manuals for Red Dragon PF-16 LPS
Summary of Contents for Red Dragon PF-16 LPS
- Page 1 RED DRAGON ELECTRONIC PROPANE FLARE Assembly and Operating Instructions For Models: PF-16 LPS – 1/2" Flare – 48,300,000 BTU/hr Max The RED DRAGON PROPANE FLARE is designed for the evacuation of LP liquid or vapor only. Its use for the evacuation of any...
-
Page 2: Table Of Contents
PLEASE READ BEFORE GETTING STARTED: The purpose of the Red Dragon Electronic Propane Flare is to provide an efficient process for the evacuation of propane liquid and or vapors from an LP container. It is important to remember a Red Dragon Propane Flare will not completely empty the container. -
Page 3: Component Photos And Descriptions
COMPONENT PHOTOS & DESCRIPTIONS: Electrode Box Flare Head/Flare Hose Assembly Upper Tower Pilot Torch Handle Evacuation Flare Tube Upper Tower Flare 1/4” Pilot Torch Hose Tower w/ Female Swivel Connection Flare Head/Hose (Attached to Pilot Torch Hose) Assembly Flare Tube Hose w/ Female Swivel Connection Female Swivel... -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTIONS: BEFORE OPERATING THE RED DRAGON Handle PROPANE FLARE: Spring Lock Make sure you have selected a safe area for Guide placement and operation with approximately 40 foot radius and a Circle minimum 50 feet of vertical clearance. Eyelets 1. - Page 5 ASSEMBLY INSTRUCTIONS: 8. Arrange the tower so that the tripod leg with the hose bracket is pointing toward the tank being evacuated. Weight the tripod legs with cinder blocks or sand bags if the unit is to be operated on pavement. If the unit is to be operated on dirt or grass, stake each tripod leg down using the leg stakes included with the unit.
-
Page 6: Lighting Instructions
RED DRAGON PROPANE FLARE OPERATING INSTRUCTIONS BEFORE OPERATING THE RED DRAGON PROPANE FLARE: Make sure you have selected a safe area for placement and operation with approximately 40 foot radius and a minimum 50 feet of vertical clearance. LIGHTING PROCEDURES Before Starting, Make sure the "Main"... -
Page 7: Trouble Shooting Tips & Other Flaring Rules
Flaring in the Wind: The Red Dragon Flare can operate in winds up to 25 mph. It may be necessary to rotate the flare so the electrodes and heat sensor are situated in the pilot flame but not exposed to the fuel coming from the evacuation flare tube. - Page 8 RED DRAGON PROPANE FLARE OPERATION INSTRUCTIONS TROUBLE SHOOTING TIPS AND OTHER FLARING RULES TO REMEMBER: Lengthy Flare Jobs and the Pilot Fuel Source: Always use a separate cylinder for the pilot source and have more than one pilot cylinder available for lengthy flaring situations.
-
Page 9: Parts List
Flare Tower Retaining Pin........G-21 Pilot torch/flare tube assembly: Tripod Leg Retaining Pins ......G-21-2 (3) Control Box Receiver Plate......PF-TA For Model PF-16 LPS 1/2" Flare ........VT 3-12 PF-16 Electrode assembly: Electrode (Ignitor and Heat Sensor)..........26 Electrode Box and Cover ...............36 Pilot Torch/Flare Hi Temp Wire Insulator...............26-2... - Page 10 PFLPS Instruction Manual 7-2012 FLAME ENGINEERING, INC. • P.O. Box 577 • West Highway 4 • LaCrosse, KS 67548 800-255-2469 • 785-222-2873 • Fax 785-222-3619 • www.FlameEngineering.com...
