NRS Healthcare M48787 User Instructions

M48787 Shower Seat with Legs
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1.

INTENDED USE

For use in a shower to provide a stable, seated support, where a user is unable to stand for long periods
(i.e. during showering). It can be folded up against the wall when not in use.
M48787
2.

SAFETY

This Shower Seat should be correctly installed by a
suitably qualified, competent person.
Only install the product in an area where the mounting
surface is structurally
modifications to the fixing surface may be required).
This product must be secured to the wall using
fasteners which are appropriate to the structural
base material.
DO NOT install
enclosures with insufficient stiffness and strength.
The maximum user weight for this product is 160 kg
(25 st) based on the product being fitted to a suitable
surface using appropriate fixings and fitted by a
competent person.
Waterproofing is recommended, and all fixings used
should be non-rusting. Sealant should be applied
around wall contact points to avoid water ingress.
Inspect the product at regular intervals for wear and
damage, do not use if unstable or the rubber feet are
damaged.
WALL MOUNTED FOLDING SHOWER SEAT
M53552
sound. (Strengthening
in fibreglass/acrylic
USER INSTRUCTIONS
M53552
3.

UNPACKING

Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
4.

ASSEMBLY/INSTALLATION

4.1 Fitting and Height Adjustment
1. Identify the correct height and position for the
seat within the shower.
Warning: When choosing the position, check there
are no concealed electrical cables or pipe work near
to where the fixing holes are to be drilled.
2. Using the e-clips and external leg holes, adjust
the leg extension tubes to the correct height for
the client. For finer adjustment, the legs may be
adjusted individually by unscrewing the threaded
feet and locking into position by tightening the
nut.
3. With the seat in the down position, 90 degrees
to the wall, and the legs vertical, with the feet flat
and secure to the shower base, mark the fixing
hole positions for the wall mounting bracket on
the wall.
4. Using appropriate, non-rusting screws and
fixings, secure the mounting bracket to the wall.
shower
5. Check the seat can be raised and lowered
without interference, and that the feet are
securely in contact with the shower base.
6. Check seat is firm and secure.
5.

IN USE

• Before using, test with both hands, to check the
seat is securely fastened to the wall.
• To lower; pull down on the seat edge.
• Ensure both legs are level and in contact with
the shower floor before sitting.
1
Shower Seat with Legs & Padded Seat
Maximum User Weight
25st
160kg
