- Page 1 Assembly and operating instructions Electronic speed control units Version 5.1...
-
Page 2: Table Of Contents
Content 1. General information 1.1. Note symbols 2. Important safety instructions 2.1. Personnel 2.2. Safety rules for working in and on electrical systems 3. Warranty 4. Delivery, transport, storage 5. Description 5.1. Speed controller type DSE 5.2. Speed controller type FE 6. -
Page 3: General Information
1. General information 1.1. Note symbols Danger Caution Immediate hazard Low-risk hazard Failure to observe the warning will result in immedi- Failure to observe the warning may result in ate death or serious injury. moderate injury. Important Warning Danger with risk of property damage Potential hazard Failure to observe the warning may result in Failure to observe the warning may result in death or... -
Page 4: Safety Rules For Working In And On Electrical Systems
The operator must ensure that the personnel have been instructed in the operation and have understood the operating instructions. If anything is unclear, please contact Walpol or our representatives. 2.2. Safety rules for working in and on electrical systems 1Disconnect (disconnect all poles 2. -
Page 5: Description
Multiple fans can be connected as long as the current limit is not exceeded. Type Voltage Current Dimensions Weight (height x width x depth) DSE-1 230 V 1.0 A 82 x 82 x 65 mm 0,26 DSE-2 230 V 2.0 A 82 x 82 x 65 mm 0.26... -
Page 6: Installation
6. Installation Note This is not a ready-to-plug-in unit. After installation as intended, this is a component in a system. The system as a whole must be installed in accordance with the relevant regulations. The VDE and EVU regulations must be observed. If necessary, the installer must coordinate the effect of this unit on the function of a ventilation and heating system with the system designer and the system operator. -
Page 7: Mounting Fe (Surface Mounting)
(e.g. DIN EN 50110 or DIN EN 60204) ! e Montage beginnen der MT Controller lesen Sie sorgfältig die • Connection diagram only for Walpol products if other controllers/fans from other companies are used, the connection nd Vorsichtsmaßnahmen“. Weiter mit den folgenden Montageschritte: may vary! •... -
Page 8: Connection Diagram And Function Of Speed Controller Type Fe
The unit and the transport packaging consist mainly of recyclable raw materials. Spare parts • Only use original spare parts from Walpol! • When ordering spare parts, state the serial number of the speed controller. This is indicated on the type plate. -
Page 9: Eu Declaration Of Conformity
EU Declaration of Conformity... - Page 10 ww. .eu...
