Sony Xplod CDX-GT430IP Specifications

CDX-GT430IP

Key Features

Jump Mode: Should you wish to listen
to a particular group or genre of
songs, select Jump Mode by pressing
the AMS button. You can then decide
how much of the list you want to play
and relax along your journey
knowing the Sony® Xplod® CDX-
GT430IP is playing what you want to
hear.
Passenger Control: The integrated
flexible Passenger Control lets your
co-pilot control your iPod® via
connected wire. As your passenger
scans through the set lists, artist and
album information displays on the
receiver to let everyone know what
song is playing.

Specifications

Audio Features
Level Control: -8dB ∼ +18dB
Convenience Features
CD Text Display: Yes
Illumination: Blue
On-Screen Clock: 12H
Video Features
Display Technology: LCD
General
Color: '07 Gun Metallic
Audio
S/N Ratio: CES2006 S/N 82 dB
Frequency Response: 10-20,000Hz
Wow and Flutter: Below Measurable Limit
Station Preset(s): FM18/AM12
Digital-to-Analog Converter: 24bit
Tuner Frequency Range: FM:Tuner
Frequency Range(MHz): 87.5-107.9,
AM:Tuner Frequency Range(kHz): 530-
1710
Signal-to-Noise Ratio: 70 dB
Tone Control(s): Low: +/-10 dB at 60Hz
(XPLOD)
Mid: +/-10dB at 1kHz (XPLOD)
High: +/-10dB at 10kHz (XPLOD)
Tuner Type: SSIR-EXA
Front Auxiliary Input: Sony has made
it easier than ever to connect almost
any portable audio device to your
car system. One little cable is all it
takes to listen to your iPod® or other
portable music player, through your
Sony® Xplod® system. No need to
mess around with FM modulators to
listen to your MP3 player in the car.
The auxiliary input is built right into the
face of the head unit. All you need to
do is plug and play.
MP3/WMA Playback: Play CDs, CD-
Rs, and CD-RWs, including discs
loaded with MP3s and WMA files3.
HD Radio1 ready: HD Radio ready
capability lets you receive digital
audio broadcasts when used with an
optional HD Radio tuner.
CD Playback: Wow and flutter-Below
measurable limit
Sensitivity (db): FM:Usable sensitivity (75)
(dBf): 10
Convenience
Tilt Range: 45°
Tuner
FM Usable Sensitivity: 10 dBf
Power
Power Consumption (in Operation): 45W
Output Power: 52W x4 High Power - 17
watts per channel minimum
continuous average power into 4
Ohms, 4 channels driven from 20 Hz to
20 kHz with no more than 5% total
harmonic distortion.
Input Power: 12 V DC car battery
(negative ground (earth))
CD Receiver Head Unit
Inputs and Outputs
Digital Audio Input(s): This unit can be
connected to the following iPods.
Update your iPod to the latest software
before you use it.
-iPod Mini*
-iPod Nano 1st generation*
-iPod Nano 2nd generation
(aluminum)
-iPod Nano 3rd generation (video)
-iPod 4th generation*
-iPod 4th generation (color display)*
-iPod 5th generation (video)*
-iPod Classic
-iPod Touch
* When you connect iPod Mini or the
4th generation of iPod, Passenger
Control is not available.
For customers in the USA, please visit
the following site for further
information:
http://www.xplodsony.com
If you have any questions or problems
concerning your unit that are not
covered in this manual, consult your
nearest Sony dealer.
Input(s): iPod® signal input terminal (30-
pin), Front Aux in,
BUS audio input terminal
Antenna Terminal(s): Aerial Input
Terminal
Audio Out (Variable/Fixed): Speaker
outputs (sure seal connectors)
Output(s): Power amplifier control
terminal
Infrared Port: Remote Controller Input
Terminal
Analog Audio Input(s) (Total): Front Aux-
In
Dimensions
Weight: 1.3Kg
Measurements: 178 x 50 x 179mm
Supplied Accessories
Parts for installation and connections (1
set)
Card remote commander: RM-X151
Optional Accessories
HD Radio™ tuner: XT-100HD
iPod® interface adaptor: XA-120IP
AUX-IN Selector: XA-300
