OPERATOR'S MANUAL
21" Self-Propelled Rotary Mower — Model Series 500
IMPORTANT:
READ SAFETY RULES AND INSTRUCTIONS
CAREFULLY BEFORE OPERATING EQUIPMENT.
769-02894C
MTD Products Ltd., P. O. Box 1386, KITCHENER, ONTARIO N2G
12/21/09
PRINTED IN U.S.A.
Advertisement
Table of Contents
Related Manuals for MTD YARD-MAN 500 Series
Summary of Contents for MTD YARD-MAN 500 Series
- Page 1 Safety • Set-Up • Operation • Adjustments • Maintenance • Troubleshooting • Parts Lists • Warranty OPERATOR’S MANUAL 21” Self-Propelled Rotary Mower — Model Series 500 IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATING EQUIPMENT. 769-02894C MTD Products Ltd., P. O. Box 1386, KITCHENER, ONTARIO N2G 12/21/09 PRINTED IN U.S.A.
-
Page 2: Table Of Contents
This Operator’s Manual is an important part of your new equipment. It will help you assemble, prepare and maintain the unit for best performance. Please read and understand what it says. Table of Contents Slope Gauge............3 Maintenance............12 Safe Operation Practices ........4 Off-Season Storage .......... -
Page 3: Slope Gauge
Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower on such slopes. Slope Gauge WARNING Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). -
Page 4: Safe Operation Practices
WARNING: Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. DANGER: This machine was built to be operated according to the rules for safe operation in this manual. As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. - Page 5 Children 22. Shut the engine off and wait until the blade comes to a complete stop before removing the grass catcher or ragic accidents can occur if the operator is not alert to unclogging the chute. The cutting blade continues to the presence of children.
- Page 6 9. Never over fill fuel tank. Fill tank to no more than ½ 8. Never attempt to make a wheel or cutting height inch below bottom of filler neck to provide for fuel adjustment while the engine is running. expansion. 9.
-
Page 7: Safety Symbols
This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before Safety attempting to assemble and operate Symbols... -
Page 8: Set-Up & Adjustments
NOTE: The units illustrated may vary slightly from your unit. 1. Remove loose parts and any packing material which may be between upper and lower handles. Pull up and back on the upper handle to raise the handle from position A into the operating position B. - Page 9 7. Attaching Grass Catcher to Mower a. Lift the rear discharge door on the mower, and place the grass catcher on the pivot rod. Let go of discharge door so that it rests on the grass catcher. See Figure 4-5. WARNING: Never operate mower unless the hooks on the grass catcher are firmly seated on the pivot rod, and the rear discharge door rests firmly against top of the grass catcher.
-
Page 10: Operation
Know Your Lawn Mower Operating Your Lawn Mower WARNING Read, understand, and follow all instruc- tions and warnings on the machine and in this manual before operating. Figure 5-1 This blade control mechanism is a Blade Control Handle Cutting Height Adjustment Levers safety device. - Page 11 WARNING: If you strike a foreign object, stop the engine. Remove wire from the spark plug, thor- oughly inspect the mower for any damage, and repair the damage before restarting and operating the mower. Extensive vibration Operating of the mower during operation is Your Lawn an indication of damage.
-
Page 12: Maintenance
The deck may be cleaned by tilting the mower and scrap- ing clean with a suitable tool (make certain the spark plug wire is disconnected). Replacing Rear Flap The rear flap is attached to the back of the mower deck. If the rear flap becomes damaged, replace it by cutting off Maintenance the flat end of the wire rod which secures it to the deck... -
Page 13: Off-Season Storage
the blade with the side marked “bottom” (or with part number) facing away from the adapter. Align the blade bell support over the blade with the tabs in the holes of the blade and insert the hex bolt. 8. Tighten the hex bolt to the torque listed below: Blade Mounting Torque Maintenance Center Bolt 450 in. -
Page 14: Trouble Shooting
Problem Cause Remedy 1. Engage blade control handle. Engine fails to start 1. Blade control handle disengaged. 2. Spark plug wire disconnected. 2. Connect wire to spark plug. 3. Fuel tank empty or stale fuel. 3. Fill tank with clean, fresh gasoline. 4. -
Page 15: Warranty
How to Obtain Service: Warranty service is available, with proof of purchase, through your local MTD Authorized Service Dealer. If you do not know the dealer in your area, please write to the Service Department of MTD PRODUCTS LIMITED, P.O. BOX 1386, KITCHENER, ONTARIO N2G 4J1. -
Page 16: Illustrated Parts Lists
12” Wheel Treads Zag Tread S-WaveTread... - Page 17 PART N° DE N° DE RÉF PIÈCE DE SCRIP TION DE SCRIP TION 712-04063 Flanged Lock Nut 5/16-18 Gr. F Ny lon Écrou à embase 5/16-18 Qual. F ny lon 756-04338 Pul ley 2.5 OD Poulie 2,5 DE 710-04329 Torx Screw Vis torx Parts List 707-04567A...
- Page 19 Sac à herbe - WOP 664-04011 Grass Bag -Troybilt Sac à herbe - Troybilt 664-04068 Grass Bag (MTD Gold) Sac à herbe (MTD Gold) 664-04027 Grass Bag Yard-man Sac à herbe (Yard-man 747-04080A Grass Bag Frame Bâti de sac à herbe...
