- Page 1 PC Series [230V] POWER LINE CONDITIONERS FOR USE WITH AUDIO-VIDEO EQUIPMENT Instruction Manual Edition 03-2022...
- Page 3 This “dirty” electricity can have a negative effect on performance of your audio-video system. TAGA Harmony power line conditioner is a next level, effective and reliable protection against voltage fluctuations and line disturbances (noises) which can negatively impact your audio-video system.
- Page 4 Contents Safety Instructions Controls and display Hooking Up the Conditioner and Operation Kit Content...
- Page 5 Safety Instructions IMPORTANT READ THIS SECTION CAREFULLY BEFORE PROCEEDING! WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The triangle containing a lightning symbol is intended to alert the user to the presence of uninsulated dangerous voltages within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 6 Safety Instructions 1. Read Instructions - All the safety and operating instructions 13. Overloading - Do not overload wall outlets, extension cords or should be read before the product is operated. integral convenience receptacles as this can result in a risk of fire 2.
- Page 7 Controls and Displays FLOOR-STANDING MODELS SHELF MODELS Note! The drawings are only for the reference. The appearance, certain design and marking elements, and a number of Power Sockets may vary on model.
- Page 8 Controls and Displays 1. Power Switch of the Switched Power Sockets [ON (I) and OFF (0)] 2. Phase LED Indicator 3. Voltage Indicator Display 4. Power Cable Input and Fuse Box 5. Fuse Box Blown fuses should be only exchanged for the same types as indicated on the rear conditioner panel above the Power Cable Input and above the Fuse Box.
- Page 9 Hooking Up the Conditioner and Operation Group I Digital devices Power cable e.g. DAC, Music Streamer, Media Player, BT receiver etc. Group II Power cable Sound sources e.g. CD / DVD / Blu-ray Player, Turntable, Radio Tuner. Group III Power cable Preamplifiers/accessories e.g.
- Page 10 Hooking Up the Conditioner and Operation Phase Detection A. Make sure that the Polarity Switch is set on 1 (default). It determines the polarity in the female contacts in the Power Sockets: • floor-standing models - according to the L and N marking on the top panel. •...
- Page 11 Hooking Up the Conditioner and Operation RECOMMENDATIONS FOR CONNECTING EQUIPMENT TO THE POWER SOCKETS SWITCHED POWER SOCKETS UNSWITCHED POWER SOCKETS active with the Power Switch in always active when connected to an position 1 (ON) electrical outlet Power socket GROUP I GROUP II GROUP III GROUP IV...
- Page 12 Hooking Up the Conditioner and Operation IMPORTANT SAFETY REMARKS! • This unit requires a single-phase 3-conductor electrical outlet. • We recommend to use Schuko plugs in all power cables. • Make sure not to overload the power line conditioner and individual groups of Power Sockets.
- Page 13 We strongly advise to contact a professional installer or dealer in order to install TAGA Harmony products. We recommend using high quality TAGA Harmony cables and other installation accessories. Kit Content: Power Line Conditioner Power Cable Instruction Manual EU declaration of conformity Your product is marked with the symbol shown on the left.
- Page 14 Notes...
- Page 15 Notes...
