- Page 1 PC Series [230V] POWER LINE CONDITIONER FOR USE WITH AUDIO-VIDEO EQUIPMENT Instruction Manual Edition 03-2020...
- Page 2 This “dirty” electricity can have a negative effect on performance of your audio-video system. TAGA Harmony power line conditioner is a next level, effective and reliable protection against voltage fluctuations and line disturbances (noises) which can negatively impact your audio-video system.
- Page 3 Contents Safety Instructions Controls and display Hooking Up the Conditioner and Operation Kit Content...
- Page 4 Safety Instructions IMPORTANT READ THIS SECTION CAREFULLY BEFORE PROCEEDING! WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The triangle containing a lightning symbol is intended to alert the user to the presence of uninsulated dangerous voltages within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 5 Safety Instructions 1. Read Instructions - All the safety and operating instructions 13. Overloading - Do not overload wall outlets, extension cords or should be read before the product is operated. integral convenience receptacles as this can result in a risk of fire 2.
- Page 6 Controls and Displays /PC-5000 model shown/ FRONT 1. Power Switch (ON and OFF) 2. Power Indicator 3. Phase Indicator 4. Voltage Meter Display REAR 5. Power Cable Input and Fuse Box A blown fuse should be only exchanged for exactly the same type as indicated on the rear amplifier panel above the Power Cable Input.
- Page 7 Hooking Up the Conditioner and Operation Switched Power Sockets Group I recommended for digital equipment. Group II recommended for sound sources. 10. Unswitched Power Sockets Group III recommended for preamplifiers / accessories. Group IV recommended for amplifiers. 1. Phase Detection A.
- Page 8 Hooking Up the Conditioner and Operation Group I Digital Equipment Power cable DAC, Music Streamer, Media Player, BT receiver Group II Power cable Sound Sources CD/DVD/Blu-ray Player, Turntable, Radio Tuner Group III Power cable Preamplifiers & Accessories Preamplifier, Phono Stage, Headphone Amplifier Group IV Power cable...
- Page 9 Hooking Up the Conditioner and Operation 2. Make sure the conditioner is turned off (the Power Switch is in the down OFF position and the Power Cable is removed). 3. Using power cables (only a power cable for the conditioner is supplied with this product) connect your audio-video equipment to the Power Sockets following the Phase Detection recommendations.
- Page 10 Hooking Up the Conditioner and Operation IMPORTANT SAFETY REMARKS! • This unit requires a single-phase 3-conductor electrical outlet. • We recommend to use Schuko plugs in all power cables. • Make sure not to overload the power line conditioner and individual groups of Power Sockets.
- Page 11 We strongly advise to contact a professional installer or dealer in order to install TAGA Harmony products. We recommend using high quality TAGA Harmony cables and other installation accessories. Kit Content: Powe Line Conditioner Power Cable Instruction Manual Your product is marked with the symbol as showed on the left.
- Page 12 Note...
