- Page 1 StreetBox-60 Battery-powered Speaker...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 29.08.2022, ID: 469240 (V3)
-
Page 3: Table Of Contents
1.3 Symbols and signal words....................... 7 Safety instructions............................. 9 Features............................... 12 Installation and starting up........................ 13 4.1 Battery operation..........................13 4.2 Connection options......................... 15 Connections and controls........................16 Technical specifications........................20 Plug and connection assignment....................22 Protecting the environment......................25 StreetBox-60 Battery-powered Speaker... - Page 4 StreetBox-60 Battery-powered Speaker...
-
Page 5: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. StreetBox-60 Battery-powered Speaker... -
Page 6: Further Information
Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. 1.2 Notational conventions This manual uses the following notational conventions: StreetBox-60 Battery-powered Speaker... -
Page 7: Symbols And Signal Words
Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. StreetBox-60 Battery-powered Speaker... - Page 8 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – danger zone. StreetBox-60 Battery-powered Speaker...
-
Page 9: Safety Instructions
Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. StreetBox-60 Battery-powered Speaker... - Page 10 (for example after transport at low outside temperatures). Dust and dirt inside can damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by qualified service personnel at regular intervals to prevent overheating and other malfunction. StreetBox-60 Battery-powered Speaker...
- Page 11 The plasticiser contained in the rubber feet of this product may possibly react with the coating of your surface and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the surface and use a suitable underlay if neces‐ sary, i.e. felt pads or similar. StreetBox-60 Battery-powered Speaker...
-
Page 12: Features
Instrument input, designed as 1/4" jack socket – Amp in and output, designed as 3.5 mm jack socket Guitar / Microphone, Bass, Mid, Treble, Reverb and Master Volume controls Built-in compressor to protect speakers and prevent distortion Plug-in power supply and gigbag included StreetBox-60 Battery-powered Speaker... -
Page 13: Installation And Starting Up
4.1 Battery operation You can also operate the device independently of the mains power supply via the built-in rechargeable lithium battery (lithium-ion accumulator 18.5 V, 2.2 Ah). StreetBox-60 Battery-powered Speaker... - Page 14 Before disposing of the device remove the lithium batteries. Protect used lithium batteries against potential short circuits, e.g. by covering the poles with adhesive tape. StreetBox-60 Battery-powered Speaker...
-
Page 15: Connection Options
Installation and starting up Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning lithium battery. 4.2 Connection options StreetBox-60 Battery-powered Speaker... -
Page 16: Connections And Controls
Connections and controls Connections and controls ö & StreetBox-60 Battery-powered Speaker... - Page 17 [IN] | input, designed as 3.5 mm jack socket (stereo) [OUT] | output, designed as 3.5 mm jack socket (stereo) 6 Connector for the supplied power adapter for power supply StreetBox-60 Battery-powered Speaker...
- Page 18 The LED lights up solid blue. 10 [MASTER] | master volume control 11 Instrument / microphone input, designed as 1/4" jack socket (mono) 12 [Mode Select] | switch for the sensitivity of the instrument / microphone input Pressed: Instrument Not pressed: Microphone StreetBox-60 Battery-powered Speaker...
- Page 19 [REVERB] | control for echo and reverb effect intensity 14 Microphone input, designed as XLR / ¼" jack combo 15 [MICROPHONE] | control for the microphone input [BASS] | bass control [MIDDLE] | mids control [TREBLE] | treble control [VOLUME] | volume control StreetBox-60 Battery-powered Speaker...
-
Page 20: Technical Specifications
2.400 GHz … 2.4835 GHz Max. transmission power 10 mW Power supply External power adapter, 100 - 240 V 50/60 Hz Operating voltage 24 V / 1500 mA, centre positive Battery / rechargeable Battery type Lithium-ion battery Voltage 18.5 V StreetBox-60 Battery-powered Speaker... - Page 21 375 mm × 195 mm × 185 mm Weight 4.0 kg Ambient conditions Temperature range –20 °C…60 °C Relative humidity 20 %…80 % (non-condensing) Further information Channels Reverb Effects processor External effects loop Line input Headphone connection StreetBox-60 Battery-powered Speaker...
-
Page 22: Plug And Connection Assignment
‘Ground’ and ‘Signal’, in a balanced transmission a second core is added. This also transfers the signal, but phase-shifted by 180°. Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. StreetBox-60 Battery-powered Speaker... - Page 23 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding StreetBox-60 Battery-powered Speaker...
- Page 24 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) StreetBox-60 Battery-powered Speaker...
-
Page 25: Protecting The Environment
Protect used lithium batteries against short circuits, for example by covering the poles with adhesive tape. Permanently built-in lithium batteries must be disposed of together with the device. Please inquire about an appropriate collection point. StreetBox-60 Battery-powered Speaker... - Page 26 Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. StreetBox-60 Battery-powered Speaker...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
