- Page 1 ELECTRICAL WATER HEATER USER MANUAL ATE51...
- Page 2 ASPES product. Aspiring to present products above and beyond your expectations, which is manufactured meticulously at ASPES’ s modern plants and rigorously quality-controlled, into your use. This operating manual will guide you through the use of your appliance. You will see that your appliance is equipped with the most advanced technological solutions and quite easy to use.
-
Page 3: Table Of Contents
Contents Safety Warnings ................4 Safety Information on the Installation of the Appliance ��������������4 Safety Information on the Use of the Appliance ��������������������������5 Safety Information to Take into Consideration During Cleaning and Maintenance ������������������������������������������������������������������������������8 Safety Information to Take into Consideration During Handling and Transportation ����������������������������������������������������������������������������9 Installation ..................9 Choosing the Mounting Position ���������������������������������������������������9... -
Page 4: Safety Warnings
WARNING: If the power ca- plug. Manufacturing company ble is damaged, it should be shall not be responsible for replaced by the ASPES au- any damage due to operating thorized service staff in order to without grounding. avoid a dangerous situation. -
Page 5: Safety Information On The Use Of The Appliance
not be held responsible of stalled on to the cold water in- any damage due to opera- let of the water heater. This will tions conducted by unau- prevent the draining of the wa- thorized persons. ter inside in case of a water cut. WARNING: Your water heat- CAUTION: The following er has been manufactured for... - Page 6 ronments are compensated appliance is discharged and by the user. the appliance stays empty • In order to prevent overload- for a long time, the reservoir ing of the electrical circuit, should not stay water-free do not operate any other for a long time.
- Page 7 • In case that the mains op- authorized service. erating pressure exceeds • A damaged appliance or 8 bars, a pressure reducer damaged parts of the appli- should be connected to the ance may cause severe inju- cold water line before safety ries and fire.
-
Page 8: Safety Information To Take Into Consideration During Cleaning
• All above-mentioned proce- dures should be performed Safety Information to Take by ASPES Authorized Ser- into Consideration During vice. Cleaning and Maintenance • Hot water, ammoniac and • To prevent risk of electric... -
Page 9: Safety Information To Take Into Consideration During Handling
Installation Liability Limitation WARNING:The water heater All technical information, in- should be installed by ASPES structions for use, operating and Authorized Service according maintenance of the appliance to “Installation Instructions”. included in this manual are the... -
Page 10: Technical Specifications
Technical Specifications Model ATE51 Capacity Water Temperature Setting Range °C 25-75 Voltage 220-240 Current Resistance Power 2000 The Highest Operating Pressure of Bar 10 (-0.5, +0 ) Safety Valve Water Connection Inch 1/2 Protection Class IP24 Enameled Interior Drum Anti-Corrosive System... -
Page 11: Electrical Connections
The distances specified in the chart below should be applied in the installation of the appliance. Min 50mm Min 50mm Min 1100mm Electrical Connections BROWN BROWN GRAY BLUE INPUT YELLOW/GREEN BLUE/RED BLUE :LIMIT THERMOSTAT :THERMOSTAT :RESISTANCE :SIGNAL LAMP :BOILER FLANGE... -
Page 12: General View
General View The images in the user manual are for informational purposes only about the parts of the device. Parts may differ depending on the device model. Pictures are representative. 1. ON/OFF and temperature setting button 2. Status indicators Controls and Indicators 1. -
Page 13: Functions And Features Of The Water Heater
Functions and Features Switch should be installed by an author- ized service technician only� of the water heater Safety Valve Strength against corrosion Safety valve is installed on to the cold The inner drum of your water heater, in- water inlet of the water heater. A kind of cluding the water input and output pipes safety, this valve will prevent the draining are enamel plated following the welding... -
Page 14: Practical And Useful Information
using the up and down arrows found will cause a drop at the efficiency of next to the display. After setting the heat transfer. Also the water piping temperature resistance is activated should be isolated. and the resistance indicator on the •... -
Page 15: Recommendations On Energy Saving
• To get the optimum performance from your electrical water heater, li- mescale that my form on the resist- ance due to the water hardness and the high temperatures should be re- moved regularly by the Authorized Service. Recommendations on Energy Saving •... -
Page 16: Troubleshooting
Call the authorized service. limescale in the product. comes out). Connect the provided hose Water drips from the from the valve to water This is normal. safety valve. drainage. www.aspes.es aspes@sareteknika.es; 902 99 69 01 / 944 04 14 08... - Page 20 52423656...
