ControlByWeb X-432 Quick Start Manual

| Quick-Start Guide
X-432

Basic Setup Steps

1. Power the module and connect to network.
2. Set IP address on computer to be on the same network as
the module. (Example: Set computer to 192.168.1.50)
3. To configure the module, open a web browser and enter:
http://192.168.1.2/setup.html
4.
Assign permanent IP address to module, then restart module.
5. Restore computer's IP address, if necessary, and access the
module at its new IP address to finish setup.

Factory Default Settings

IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Control Page Web Address: http://192.168.1.2
Control Password: (no password set)
Setup Page Web Address: http://192.168.1.2/setup.html
Setup Username: admin
Setup Password: webrelay (all lower case)
See users manual for setup instructions:
www.ControlByWeb.com/support/
Rev 1.0
