External USB All-in-One Multi-Card Reader (STI-UMC600) User Guide
Index
Introduction
Package Contents & System Requirements
Installation & Using the Reader for Windows
Installation & Using the Reader for Mac OS
Troubleshooting
Specifications
1. Introduction
1.1. Features
Thank you for purchasing SimpleTech's USB Multi-Card Reader. The USB Card Reader is the most powerful
and multi-functional device among all the available readers, since it is able to access most of the storage cards
and read/write four different types of cards at the same time.
USB Card Reader utilizes the most useful and popular USB interface and is Mass Storage Compliant, bringing
you convenient and high-speed access to a variety of storage cards.
USB Card Reader supports almost all the available storage cards including: 3.3V SmartMedia Card, Type I/II
CompactFlash Card, IBM Microdrive, Memory Stick, Secure Digital Card, and MultiMedia Card.
Primary features of the USB Card Reader include:
USB 1.1 interface; Access speed up to 12 Mbits/second.
USB bus powered. Hence, AC power adapter is not required.
Supports Hot-Swapping and Mass Storage Class Drive; no drivers needed under Windows ME/XP.
Includes POWER and ACCESS LED indicators.
Different sockets can be used at the same time.
Supports the following storage cards:
o 3.3V SM/Type I&II CF/IBM Microdrive/SD/MMC/MS
Supports the following operating systems:
o Windows 98/98SE/ME/2000/XP
o Mac OS 8.6+, 9.x+, 10.x Operating Systems
1.2. Package Contents
In the package of USB Card Reader, you will find following items. Please contact your local dealer if there are
any items missing.
USB Card Reader
Setup CD Disc
USB Cable
www.simpletech.com
1 of 7
Document Number: 61600-00049-001
Advertisement
Table of Contents
Related Manuals for SimpleTech STI-UMC600
Summary of Contents for SimpleTech STI-UMC600
- Page 1 1. Introduction 1.1. Features Thank you for purchasing SimpleTech’s USB Multi-Card Reader. The USB Card Reader is the most powerful and multi-functional device among all the available readers, since it is able to access most of the storage cards and read/write four different types of cards at the same time.
- Page 2 WARNING! Do not insert or extract storage cards while the Red LED is flashing which indicates that the reader is being accessed by the computer. www.simpletech.com (Insert with Gold contacts facing Up) (Insert with Label facing Up) (Insert with Label facing Up)
-
Page 3: Installation Procedure
“CF”, SD”, “SM” and MS” to help you distinguish the cards on your computer. The installation of your USB Card Reader is now complete. www.simpletech.com and then reinstall the USB driver. Alternately, when you format the cards, 3 of 7... - Page 4 The contents of Read Me file appears. Click on Continue to proceed. You can also find this file in the Setup Disc if you want to view it later on. www.simpletech.com 4 of 7 Document Number: 61600-00049-001...
- Page 5 USB Card Reader to the available USB port on your Macintosh computer and insert the flash card into the USB Card Reader. Now you may enjoy the ease of use and high speed access of the USB Card Reader on your Macintosh. www.simpletech.com 5 of 7 Document Number: 61600-00049-001...
- Page 6 Uninstall in the pop-up menu. Click Uninstall to remove driver files. During the uninstallation, a warning indicating that Some files /folder could not be deleted may appear. Please click OK ignoring this message. www.simpletech.com 6 of 7 Document Number: 61600-00049-001...
-
Page 7: Troubleshooting
Supported Cards 3.3V SM/Type I&II CF/IBM Microdrive/SD/MMC/MS Interface External USB 1.1 device Power DC+5.0V directly from USB port Environment Operating temperature: 0 Storage temperature: -40 Humidity: 90% RH (max. without condensing) www.simpletech.com C~70 C~70 7 of 7 Document Number: 61600-00049-001...
