- Page 1 JB-3 Installation Manual PV Junction Box for Composition/Asphalt Shingle Roofs QUICK START GUIDE WATCH INSTALL VIDEO ezsolarproducts.com info@ezsolarproducts.com 385.202.4150...
-
Page 2: Materials Included
JB-3 Installation Manual PV Junction Box for Composition/Asphalt Shingle Roofs A. MATERIALS INCLUDED B. STEP BY STEP INSTRUCTIONS ezsolarproducts.com info@ezsolarproducts.com 385.202.4150... - Page 3 C. WIRING & PROPER USE D. SYSTEM SPECIFICATIONS & RATINGS ezsolarproducts.com info@ezsolarproducts.com 385.202.4150...
- Page 4 Table 1 Typical Wire Size, Torque Loads and Ratings Torque 1 Conductor 2 Conductor Type Inch Lbs Voltage Current ABB ZS6 terminal block 10-24 awg 16-24 awg Sol/Str 0.5-0.7 6.2-8.85 600V 30 amp ABB ZS10 terminal block 6-24 awg 12-20 awg Sol/Str 1.0-1.6 8.85-14.16...
- Page 5 Lethal voltages are present during the installation, operation and service of this equipment. Proper precautions must be taken at all items to ensure the safety of the service personnel. At all times follow state and federal occupational safety and health administration (OSHA) guidelines and regulations. Utilize proper Personal Protective Equipment (PPE) as required per national and local regulations as well as for installation best practices.
