- Page 1 SonicPRO Ultrasonic Protection System INSTALLATION MANUAL Transducer and plastic mounting ring installation onto flat surfaces of GRP, Carbon Fibre, Steel and Aluminium. Manual ref: 01-06-2019...
- Page 2 Maintenance and Routine Checks.………………………………………………………………….. page 5 IMPORTANT INFORMATION The ultrasonic transducers are fitted on the inside of the hull or inboard surfaces of the sea chest box or box cooler, therefore it is not necessary to penetrate these structures. The system can be installed with the vessel in or out of the water.
- Page 3 TRANSDUCER POSITIONING When positioning transducers, consideration should be made for the length of cable supplied that connects the transducers to the control unit. Extension cables are available if required in 4, 8 and 10m lengths. Custom lengths by special order. PLEASE NOTE: The total combined transducer cable length in the system must not exceed 75m.
- Page 4 TRANSDUCER INSTALLATION Preparing the Hull, Sea Chest Box or Box Cooler for transducer mounting ring. Stage 1 Stage 1 - Preparing the surface. image: prepared GRP surface Carefully prepare the location of the transducer using an 80grit sand paper and sanding block. An electric sander can also be used.
- Page 5 image: Mounting ring bonded onto GRP. The inner contact area is free of debris and excess epoxy. ___________________________________________________________ Fitting the transducer into the mounting ring. Check for any debris or excess epoxy inside image: silicone grease is applied to the transducer face.
- Page 6 Check the transducer is screwed in tight. Check the transducer cable is secure and any excess cable has not been coiled up. MAINTENANCE / ROUTINE CHECKS The SonicPRO system does not require any maintenance, but it is recommended transducers are inspected from time to time. •...
- Page 7 NOTES...
- Page 8 Ultrasonic Antifouling Ltd Arena Business Centre, Holyrood Close, Poole, Dorset, BH17 7FJ. England +44 (0) 1202 606 185 info@ultrasonic-antifouling.com www.ultrasonic-antifouling.com...
