- Page 1 SonicPRO Ultrasonic Protection System INSTALLATION MANUAL Transducer and radius bracket installation for onto curved surface i.e. Seawater Strainer and Pipework. Manual ref: 01-06-2019...
- Page 2 IMPORTANT INFORMATION BEFORE INSTALLATION OF THE TRANSDUCER RADIUS BRACKET…. You are looking to make 100% contact between the curved underside surface of the bracket and the surface of the strainer housing or pipe. The better you prepare the surface the better the effect. EPOXY MIXTURE….
- Page 3 TRANSDUCER POSITIONING GUIDE Positioning of the transducer(s) is critical because incorrect positioning can make the system less effective. Strainer / Filter Housing A central position (or nearest too) on the vertical length between the lid and lower flange (base of cylinder) is preferred to allow even dissipation of the sound waves into the inner flooded space surrounding the isolated strainer / filter.
- Page 4 RADIUS BRACKET INSTALLATION 1. Preparing the surface It is vital that the surface to which the bracket is to be attached to, is totally smooth, dry and free from grease and dust when the epoxy is applied for bonding. Carefully prepare the location of the transducer bracket using an 80 - 120grit sand paper, preparing a smooth surface removing any high spots in the coating.
-
Page 5: Transducer Installation
TRANSDUCER INSTALLATION 1. Check for any debris or excess epoxy on the flat (transducer contact) surface of the bracket that would prevent the transducer making 100% flat contact. 2. Apply a small amount of Surface must be free of silicone grease to the thread of dust and debris the lug for lubrication. -
Page 6: Technical Support
TECHNICAL SUPPORT Contact the technical support team: Telephone: +44 (0) 1202 606 185 Email: info@ultrasonic-antifouling.com... - Page 7 NOTES...
- Page 8 Ultrasonic Antifouling Ltd Arena Business Centre, Holyrood Close, Poole, Dorset, BH17 7FJ. England +44 (0) 1202 606 185 info@ultrasonic-antifouling.com www.ultrasonic-antifouling.com...
