Views of the Pro Drive
All of the connectors, switches, and security lock are located on the rear panel
of the Pro Drive and are described in the following illustration.
Rear Panel View
10
Pro Drive User Guide
Model No.: xxxx-xxxxx-xxx
Power
ON/OFF
Connect
USB OR
eSata cable
between
drive and
computer
Security
lock slot
(optional)
DC input
socket for
AC adapter
