- Page 1 CYLINDERICAL TYPE AXIAL-FLOWFAN (ENERGY-SAVING) MODEL : SD-B2.5 SD-B3 SD-B4 SD-B5 INSTRUCTION MANUAL Please read instruction carefully before operation...
- Page 2 Ⅱ.SPECIFICATIONS AND TECHNICAL DATA (See Table 1) Model Size Phase Input Power Noise (mm) (dB) SD-B2.5 SD-B3 SD-B4 SD-B5 Table 1 Note: Technical date air based on 220V / 50Hz and 380V / 50Hz. Ⅲ.ELECTRIC SCHEMATIC DIAGRAM (See Figure 1 & 2) Single Phase Induction Motor...
- Page 3 Ⅳ.INSTALLING DIMENSIONS (See Figure 3 for installing dimension and Table 2 for relevant data) Figure 3 Size Model (mm) (mm) (mm) (mm) (mm) Ф260 Ф295 Ф295 SD-B2.5 250mm Ф310 Ф350±5 Ф350 SD-B3 300mm Ф410 Ф470±5 Ф470 SD-B4 400mm Ф510 Ф570±5 Ф580...
- Page 4 1. Before installing, check if the voltage and frequency on the data plate are applicable to local power supply, turn the blade with hand to see if the motor shaft runs smoothly. 2. The FAN should be installed at a place over 2.3 metres above the ground and fixed on the wall or a special frame with nuts.
