- Page 1 INDUSTRIAL VENTILATING FAN MODEL : APK30-4 APK38-4 APK45-4 APK60-4 INSTRUCTION MANUAL Please read instruction carefully before operation...
- Page 2 INDUSTRIAL VENTILATING FAN “SHUANGDIE” INDUSTRIAL VENTILATING FAN is an electric fan installed in an opening in the wall, exchanging air from indoor to outdoor. It is the ideal ventilating fan for industrial, commercial applications and other public places. Special features include: 1.
- Page 3 III. PARTS DIAGRAM...
-
Page 4: Operating Instructions
7. Dimension(mm) MODEL φ9.0 APK30-4 344±1.0 φ9.0 APK38-4 431±1.0 φ10.5 APK45-4 514±1.0 φ13 APK60-4 685±1.0 Ⅳ.OPERATING INSTRUCTIONS 1. Power source: Before operating, check if the country’s power comply with the rated power. 2. The fan should be installed at place over 2.3meters above the ground.
